- Page 1 SCOTT 2014 BIKE OWNER’S MANUAL SCOTT SPORTS SA | 17 RTE DU CROCHET | 1762 GIVISIEZ | SWITZERLAND © 2013 SCOTT SPORTS SA, ALL RIGHTS RESERVED | SCOTT-SPORTS.COM DISTRIBUTION: SSG (EUROPE) DISTRIBUTION CENTER SA P.E.D ZONE C1, RUE DU KIELL 60 | 6790 AUBANGE | BELGIUM |...
- Page 2 All adjustments should be done at the local SCOTT Set-Up Genius LT with FOX Nude Shock and FOX Float CTD ..... .P.017 dealer or following to this manual.
-
Page 3: Genius Lt Concept
GENIUS LT CONCEPT GEOMETRY/TECHNICAL DATA GENIUS LT The new Genius LT is the result of 2 years of research and development for one of the Travel 170/136/0mm lightest all-mountain bike frame set available on the market, hitting the scale at below Suspension Ratio 2.72... -
Page 4: Shock Technology
TWINLOC allows also the remote control of the front fork to shift between lock-out and open mode at the same time when you change the modes on the SCOTT rear shox. For Ride: by adding a platform on the compression damping system the shock will... -
Page 5: Assembly Of The Remote Cable
ASSEMBLY OF THE REMOTE CABLE SCOTT offers 2 different TWINLOC levers with following fork/rear shock combinations: - FOX Nude with different rolls for FOX CTD fork and RockShox DNA 3 fork (SCOTT IMPORTANT: Article number: 230097) - FOX CTD with different rolls for FOX CTD fork and RockShox DNA 3 fork (SCOTT... -
Page 6: Nude 2 Shock And Twinloc Remote Control Lever
Positive Chamber Valve Remote Control Wheel Cable Fixing Screw (hidden behind remote wheel) Shock Piston SAG Indicator (o-ring on piston) Remote Lever Release button Remote Control Cables Cable Tension Screw Fork Remote Cable Tension Screw Shock Remote BIKE OWNER’S MANUAL scott-sports.com... -
Page 7: Basic Set-Up Of The Twinloc Remote Control Of Fox Nude Shock
2. insert a new cable via lever hole and cable housing and push it into the shock as shown around the remote wheel (S6). On Genius LT alloy frames a regular outside cable routing, the outer cable housing is fixed on cable mount ports with cable zippers. - Page 8 4. Check that the handlebar lever is in the traction position. Refer to the dia- 6. push a cable end-cap on the cable until it touches the end of the cable. gram below. Fix it by squeezing it with pliers. BIKE OWNER’S MANUAL scott-sports.com...
-
Page 9: Basic Set-Up Of The Twinloc Remote Control Of Fox Ctd Shock
Make sure to balance at least this air loss when you make a check of the air cap on the valve pressure of the shock. Please also note that the indicators of shock pumps have a tolerance of max. 10%. BIKE OWNER’S MANUAL scott-sports.com... -
Page 10: Set-Up Of Rebound Fox Nude Or Fox Ctd Shock
- if the distance between the main dust wiper/seal is bigger than 18mm the air pressure of the air chamber is too low and should be increased by using the shock pump until the distance is 18mm. BIKE OWNER’S MANUAL scott-sports.com... -
Page 11: Set-Up Of Other Shock Models
SCOTT strongly recommends using only the FOX Nude (FOX CTD shock) with the Genius LT bike, as we designed both parts for a perfect matching - If it bounces more than 3 times the rebound is too fast. Turn the knob 1-2 combination with a linear suspension rate. -
Page 12: Headset Options
BOTTOM BRACKET (BB) ON GENIUS LT Genius LT features a tapered headset and fork steerer system to match with All frames of Genius LT (carbon and alloy) have a BB shell for BB92PF semi-integrated headsets of the “50-61”mm range with ID of Headtube of standard. -
Page 13: Adjustable Bb Height
ADJUSTABLE BB HEIGHT On Genius LT bikes equipped with the FOX Nude or the FOX CTD shock you can adjust the BB height above ground in 2 positions by flipping a geometry chip located on the linkage bar shock mount. -
Page 14: Chainguide
On all Genius LT frames you will find a Shimano E-type front derailleur but The Carbon as well as the alloy frames of Genius LT can be fitted with ISCG fixed directly on the swingarm without the plate that is fixed normally between chainguide systems. - Page 15 Please respect the different assembly positions for SRAM and Shimano front derailleurs. In addition to the chainblocker assembled on the Genius LT you also find a chainguide mounting port below the chainstay. Both frame options, carbon and alloy, have the same feature.
-
Page 16: Genius Lt Cable Routing
Carbon Front frames: Headtube section: BB section: The carbon frames of Genius LT have an internal shifting cable routing with cable stops on the front end of the downtube as shown in the drawing below. FD: Front derailleur RD: rear derailleur... - Page 17 In order to seal the housing ports on the frame you should use the plugs attached to the bike. 229724 Cable Clamping Set Genius alloy 2013 one size BIKE OWNER’S MANUAL scott-sports.com...
-
Page 18: Adjustment Of Seatpost-Height
Genius LT can be used with 3 different disc rotor sizes on the rear brake. In case of a change of the bearings or of the rear swingarm you should contact The rear disc brake on Genius LT is Postmount (PM) Standard on the left your local SCOTT dealer as you need special tools for disassembly and assembly. -
Page 19: Warranty
5 years for the frame shall be reduced to 3 years. Costs for maintenance and service have to be born by the owner of the SCOTT bike. Date of purchase ..................
