Fenestra Window AC

Instruction Manual

Installation and Operation Guide

Need help?

Do you have a question about the Fenestra 048-TL-W5KWDS and is the answer not in the manual?

Questions and answers

Summary of Contents for DELLA Fenestra 048-TL-W5KWDS

Page 1 Fenestra Window AC Instruction Manual Installation and Operation Guide...
Page 3 Table of Content Before Installation Care and Maintenance Warning and Safety Air Filter Name of Parts Maintenance Routine Having Problems? Installation Troubleshooting Installation Preview Disposal Guideline Installation Warranty Before Using Operation Tips Parts of the Air Conditioner Front Panel Remote Control Basic Operation Power ON / OFF Operation Modes...
Page 4 Warning and Safety • Read this guide before installation. Failure to follow the safety instructions may result in property damage, serious injury, or death. • Please Keep this manual. Danger: Indicates an IMMINENTLY hazardous situation that, if not avoided, will result in death, serious injury, or serious property damage. DANGER Warning: Indicates an POTENTIALLY hazardous situation that, if not avoided, will result in death, serious injury, or serious property damage.
Page 5 Warning and Safety About Power and Electricity • Ensure that the power voltage corresponds to that stamped on the rating plate. • Make sure this appliance is connected to a properly grounded power outlet to prevent electric shock. WARNING • Do not bend, tug, or compress the power cord during installation to prevent damaging the power cord.
Page 6 Warning and Safety Encountering Troubles • In the case of the appliance emitting smoke, burning smell, leaking water, or making unusual noise, shut down the WARNING About Handling and Maintenance • Do not attempt to disassemble, alter, or modify the appliance. •...
Page 7 Name of Parts Package Contents Window AC Top Rail Filler Panel Set Remote Control 3/4" Screws 1/2" Screws 3/8" Screws Tools Needed (Not included) • Screw Driver • Power Drill • Refrigerant Leak Detector • Measuring Tape • Thermometer • Cutter / Scissors v.20241112...
Page 8 048-TL-W5KWDS 048-TL-W6KWD Power Supply 115 V / 60 Hz / 1P 115 V / 60 Hz / 1P Rated Capacity (Btu/h) 5000 6000 Power Consumption 460 W 550 W Rated Current 4,6 A Indoor 51 - 55 dBA 51 - 55 dBA Noise Level Outdoor 55 - 60 dBA...
Page 9 Installation Preview Window Requirement The air conditioner is deisnged to be installed in a standard single-hung or double-hung window. The AC would not t in other window types. Single Hung / Double Hung Sliding Window Casement Window Awning Window Window Make sure your window has enough clearance for the window AC to be properly seated in the opening.
Page 10 Installation Preview Picking a Installation Location • Do not install the unit near a heat source, steam, or ammable gas. • Do not install unit in a location where drain water would cause inconvenience to others. • Make sure the window AC is installed in places where the power cord is long enough to reach an power outlet. •...
Page 11 Installation Attach Filler Panels Fully extend the ller panels. Filler Panels Slide the ller panels to the sides of the window AC. v.20241112...
Page 12 Installation Attach Filler Panels Insert the ller panels to the top and bottom rails of the window AC.
Page 13 Installation Install Window AC to the Window Place the AC on the window with the bottom rail rest against the corner of the sill and the stool. Center the AC and close the window sach onto the top mounting rail. The AC should be around 3° tilted towards the outside. NOTE: Tilt the AC outside to prevent condensate or rain water from back owing into the house.
Page 14 Installation Secure Window AC In Place Fully extend the ller panels to the sides of the window. Fit frame locks between the ller panels and window stool, then lock them in place with 3/4" screws. Secure the AC top rail and ller panels to the window sach with 1/2" screws. Frame Lock 3/4"...
Page 15 Installation Hold Down the Window Sach and Insulation Make sure the bottom window sach is push down all the way against the window AC, then secure it in place with sach lock and 3/4" screws. Measure and cut window sach seal to the length of your window sach width. Insert the sach seal to the gap between the bottom window sach and top window sach as additional insulation.
Page 16 Installation Power Connection Insert the power plug into a wall power socket. WARNING • The AC should only be plugged into a 3 prong wall outlet. If a 3 prong is not available, it is the customer's reponsibility to have a •...
Page 17 Before Using Operation Tips Avoid operating the air conditioner with wet hand. Avoid putting plants or objects around the air conditioner. • It may cause electric shock. • It may block air ow and lower the air conditioner e ciency or cause malfunction.
Page 18 Before Using Parts of the Air Conditioner 048-TL-W5KWDS 048-TL-W6KWD Air Outlet Air De ctor and Flap Front Panel Control Panel AIr Filter Tab...
Page 19 Before Using Control Panel 048-TL-W5KWDS 048-TL-W6KWD Display Indicate operating status, temperature or timer setting WIFI HIGH COOL Fan Speed Button Mode Button AUTO AUTO Select fan speed Select operation mode SPEED MODE -00- -00- Page 24 Page 23 MODE SPEED TEMP/TIMER Increase / Decrease Button Adjust temperature / timer setting...
Page 20 Before Using Remote Control (Insert Battery) Slide and remove the battery tray from the remote control. Place a CR2025 coin battery into the battery compartment in correct polarity. Reinstall the battery tray into the remote control. From the bac k of the remote control, push the left fastener of the battery tray to the right while holding the top of battery tray and pulling out.
Page 21 Coin Cell Battery Safety Warning: a ) Remove and immediately recycle or dispose of used batteries according to local regulations and keep away from children. Do NOT dispose of batteries in household trash or incinerate. b ) Even used batteries may cause severe injury or death. c ) Call a local poison control center for treatment information.
Page 22 Basic Operation Power ON Press on the control panel or press on the remote control. • The air conditioner will start operating. Power OFF Press on the control panel or press on the remote control. • The air conditioner will stop operating. Select Operation Mode Press on the control panel to select operation mode.
Page 23 Basic Operation Adjust Temperature Press on the control panel or remote control to adjust temperature setting. • Temperature setting will adjust by 1°F / 1°C increment for each time the button is pressed. • Temperature can only be set between 61°F - 88°F / 16°C - 31°C. Set Fan Speed Press on the control panel or press...
Page 24 Advance Function Timer Function (Shutdown Timer) Set a timer to automatically turn OFF the air conditioner. Press on the control panel or on the remote control when the air conditioner is ON. Press to set the desired turn o time. Press on the control panel or remote control again to con rm the timer setting.
Page 25 NOTE: Filter check light can only be reset on the control panel and is not accessible on the remote control. Wi-Fi Reset Press on the remote control 6 times in 4 seconds on the remote control to reset and ready for pairing with your air conditioner to the "Della+" app. v.20241112...
Page 26 Search “DELLA+” on Apple app store or Google Play, or scan the QR code below to download the application. Register an account in the app. Follow the in app instructions to add and pair your Della AC to the app and complete the Wi-Fi set up. Device QR code Scan this QR code to add device to your Della+ app.
Page 27 Care and Maintenance CAUTION • • Clean the Unit Clean the air conditioner with a soft dry cloth or a damped cloth with neutral detergent. Remove any possible debris on the vents and air outlet. Clean the Air Filter Remove the air ter from the air conditioner. Clean the air ter with soapy water.
Page 28 Care and Maintenance Maintenance Routine • Clean the air lter screen every month. • Regularly check and remove any obstacles from the air vent. Planning to Not Operate the Air Conditioner for a Long Period • Take out the batteries from the remote control and disconnect the power supply of the air conditioner. Using the Air Conditioner After a Long Idle Period •...
Page 29 Troubleshooting Before consulting repair or warranty, please check the following troubleshooting guide. In the case of an persistent problem, contact a quali ed technician for diagnosis and repair. WARNING • When encountering persisting problem, stop operation and turn o the breaker. Continue operation in an abnormal condition may cause electric shock, re, or damage to the unit.
Page 30 Troubleshooting Problem Possible Cause / Explanation / Solution This occurs when the air in the room becomes cold in cool or dry mode. This does not indicate Mist comes out from the air outlet a problem. mode. This is not a malfunction. Strange Noise In the case of plastic cracking noise - The noise may caused by the thermal expansion on plastic parts and does not indicate a...
Page 31 Disposal Guideline This appliance contains refrigerant and other potentially hazardous materials. When disposing of the appliance, follow all federal, state, and local regulations. DO NOT dispose of this product as normal household waste or unsorted municipal waste. When disposing of this appliance, you have the following options: •...
Page 32 Warranty Scan the QR code or visit our page on dellahome.com/pages/warranty to sign up for warranty coverage on your new DELLA appliance. dellahome.com/pages/warranty WARRANTY COVERAGE DELLA distributor (hereinafter “Company”) warrants this product against failure due to defect in materials or workmanship under normal use and maintenance as follows: All warranty periods begin on the date of purchase.
Page 33 Warranty LIMITED WARRANTY STATEMENT LIMITATIONS OF WARRANTIES: ALL IMPLIED WARRANTIES AND/OR CONDITIONS (INCLUDING IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE OR PURPOSE ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY. SOME STATES DO NOT ALLOW LIMITATION ON HOW LONG AN IMPLIED WARRANTY OR CONDITION LASTS, SO THE ABOVE MAY NOT APPLY TO YOU THE EXPRESS WARRANTIES MADE IN THIS WARRANTY ARE EXCLUSIVE AND MAY NOT BE ALTERED ENLARGED, OR CHANGED BY ANY DISTRIBUTOR, DEALER, OR OTHER PERSON, WHATSOEVER.
Page 34 Compliance Information Radio Frequency Interference Model: 048-TL-W5KWDS / 048-TL-W6KWD ID: 2ANDL-TYWE1S FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 35 Introduct ion to Refrigerants R32 The refrigerants used for air conditioners are environmentally friendly hydrocarbons R32. This kind of erant is combustible and odorless. Moreover, it can burn and explode under certain condition. However, there will be no risk of burning and explosion if you comply with the following table to install your air conditioner in a ropom with an appropriate area and use it correctly.

This manual is also suitable for:

Fenestra 048-tl-w6kwd
