Read all instructions before use this device.
Recommended Room Size: 300-350 sp.ft / 28-33m (048-TL-WAC8K32)
400-450 sq.ft / 37-42 m (048-TL-WAC10K32) / 450-550 sq.ft / 42-51m
(048-TL-WAC12K32)/550-700 sq.ft / 51-65 m (048-TL-WAC14K32)
Product appearance and color may vary from pictures.
Keep the manual properly for future reference.
Model#048-TL-WAC8K32/WAC10K32/WAC12K32/WAC14K32
Advertisement
Related Manuals for DELLA 048-TL-WAC8K32
Summary of Contents for DELLA 048-TL-WAC8K32
- Page 1 Model#048-TL-WAC8K32/WAC10K32/WAC12K32/WAC14K32 Read all instructions before use this device. Recommended Room Size: 300-350 sp.ft / 28-33m (048-TL-WAC8K32) 400-450 sq.ft / 37-42 m (048-TL-WAC10K32) / 450-550 sq.ft / 42-51m (048-TL-WAC12K32)/550-700 sq.ft / 51-65 m (048-TL-WAC14K32) Product appearance and color may vary from pictures.
- Page 2 INTRODUCTION IMPORTANT SAFETY INSTRUCTION ................ELECTRICAL REQUIREMENTS ................... PACKING LIST ......................INSTALLATION&ASSEMBLY INSTRUCTIONS .............. USING YOUR AIR CONDITIONER ................OPERATING YOUR AIR CONDITIONER ................ CARE AND CLEANING ....................TROUBLESHOOTING ....................
- Page 3 Unplug the air conditioner before servicing. Do not use a plug adapter. Use two or more people to move and install the air conditioner. Model Number: 048-TL-WAC8K32 048-TL-WAC10K32 048-TL-WAC12K32 048-TL-WAC14K32 Power supply(Ph-V-Hz) 1Ph, 115V~, 60Hz 1Ph, 115V~, 60Hz 1Ph, 115V~, 60Hz...
- Page 4 Please read the manual before installation, using, maintenance. Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. Do not pierce or burn the appliance. The appliance shall be stored in a room without continuously operating sources (for example: open flames, an operating ignition gas appliance or an operating electric heater.) Please contact the nearest after-sale service center when maintenance is necessary.
- Page 5 Electrical Shock Hazard (8K) 0-8 amps Plug into a grounded 3 prong outlet. (10K-14K) 0-12 amps Do not remove the ground prong. (8K) 10-amp Do not use an adapter Do not use an extension cord. (10K-14K) 15-amp Failure to follow these instructions can result in death, fire, or electrical shock...
- Page 6 (Only for E-star model)
- Page 7 FIG. 1 EXTERIOR STOOL WALL OFFSET SILL INTERIOR WALL 6. The air conditioner should be tilted about 3° for better drainage of condensate and rainwater. 10K/12K/14K FIG. 2 EXTERIOR STOOL WALL OFFSET SILL INTERIOR WALL 6. The air conditioner should be tilted about 3° for better drainage of condensate and rainwater.
- Page 8 (Only used for 6K/8K) When handling the unit, be careful to avoid cuts from the sharp metal edges and aluminum fins on the front and rear coils.
- Page 9 FIG. 3 When handling the unit, be careful to avoid cuts from the sharp metal edges and aluminum fins on the front and rear coils. FIG. 4 FIG. 5...
- Page 10 FIG. 10 (Suggest to keep a downward oblique, to let accumulated rain water to drain out, from back side of the unit bottom.) FIG. 6 FIG. 11 FIG. 7 FIG. 12 FIG. 8 FIG. 13 FIG. 9...
- Page 11 99FIG. 14...
- Page 12 INSTALLATION & ASSEMBLY INSTRUCTIONS Introduction to Refrigerants R32 Before installing the appliance, you must read the manual carefully to get the safety information and notes. When filling the combustible refrigerant, any of your rude operations may cause serious injury or injuries to human body or bodies and object or objects. A leak test must be done after the installation is completed.
- Page 13 Cool Mode: The cooling function allows the air conditioner to cool the room and at the same time reduces Air humidify. Press the MODE button to activate the cooling function. To optimize the function of the air conditioner, adjust the temperature and the speed by pressing the button indicated.
- Page 14 6. Eco Button: When the unit is in ECO mode, the Directional Louvers: To direct the airflow, light will turn on. In ECO mode, the unit will use the horizontal wheel to control the horizontal turn off once the room is cooled to the user-set direction, and use the air deflectors to control the...
- Page 15 temperature will automatically raise or decrease based on the room temperature and the duration of sleep. Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries.
- Page 16 Take off the power plug, then remove the filter by sliding it out from the front right side of the air conditioner. (See Fig .15) FIG. 15...
- Page 18 The air conditioner is under demand It is the demand response Display dr and unit response, only turn ON/OFF can be condition, you can wait for the without control actived, and the set temperature may Delay time or override it by long raise, and the compressor may stop press down button for 3s on the control panel.
