- Page 1 INSTRUCTION MANUAL Cordless Cleaner CL004G Read before use.
- Page 2 WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges and chargers may cause injury and/or fire. SPECIFICATIONS Model: CL004G Capacity 250 mL Continuous use (with battery 1 (Quiet mode) Approx. 60 min...
- Page 3 13. Do not use without dust bag and/or filters in Only for EU countries Ni-MH place. Due to the presence of hazardous com- Li-ion ponents in the equipment, waste electrical 14. Do not charge the battery outdoors. and electronic equipment, accumulators 15.
- Page 4 Avoid storing battery cartridge in a con- causing fires, personal injury and damage. It will tainer with other metal objects such as also void the Makita warranty for the Makita tool and nails, coins, etc. charger. Do not expose battery cartridge to water Tips for maintaining maximum or rain.
- Page 5 Let the appliance and battery(ies) cool down. If no improvement can be found by restoring protection system, then contact your local Makita Service Center. Indicating the remaining battery capacity Press the check button on the battery cartridge to indi- cate the remaining battery capacity.
- Page 6 Lighting up the lamp Indicator lamps Remaining capacity CAUTION: Do not look in the light or see the Lighted Blinking source of light directly. 75% to 100% To turn on the lamp, push the suction power change button. The lamp goes off in approximately 10 seconds. 50% to 75% While the cleaner is running, the lamp turns on.
- Page 7 To rotate the brushroll, place the nozzle on the floor so that the floor detection switch is activated and turn on the appliance. To stop the brushroll, turn off the appliance. NOTE: When the appliance detected the brushroll overload, the mode indicator lamp blinks in the selected mode and the brushroll stops rotating.
- Page 8 To remove the attachment, pull it off the cleaner while Installing and removing cleaner pressing and holding the release button. attachments CAUTION: After installing attachments, check if they are securely installed. If the attachments are installed imperfectly, they may come off and cause personal injury.
- Page 9 You can store the sash nozzle in the nozzle holder. Cleaning (Suction) To attach the nozzle holder, align the short arm of the nozzle holder between the lower protrusions on the Nozzle with brushroll + Extension extension wand, and then attach the long arm of the nozzle holder between the upper protrusions on the wand (Straight pipe) extension wand.
- Page 10 Discoloration, deformation or Fig.16 cracks may result. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. 10 ENGLISH...
- Page 11 Cleaner body After use Wipe off the outside (cleaner body) of the cleaner using a cloth dampened in soapy water, and clean out the CAUTION: Putting the cleaner against the suction openings. wall without any other support may cause the cleaner to fall down, resulting in personal injury or damage to the cleaner.
- Page 12 With the suction inlet pointing downwards, hold Dust off inside the cyclone unit and filter, then the cyclone unit firmly, and then detach the cyclone unit return the filter to the cyclone unit. from the cleaner body slowly and straightly while press- ing and holding the release button on cyclone unit.
- Page 13 Pinch the high performance filter and pull it out Hold the mounting end of high performance filter from the cyclone unit. and squeeze it back into the cyclone unit. Fig.26 Fig.29 ► 1. High performance filter 2. Cyclone unit ► 1. High performance filter 2. Cyclone unit Wipe and shake dust off the high performance HEPA filter filter by hand.
- Page 14 Wipe and shake dust off the high performance Hold the mounting end of HEPA filter (covered with prefilter and HEPA filter by hand. high performance prefilter) and squeeze it back into the cyclone unit. Fig.32 Fig.35 Wash the high performance prefilter and HEPA ►...
- Page 15 Nozzle vent Unlock the lock plate and remove the lower cover. Vacuum any dust that has accumulated in the nozzle vents. Fig.37 ► 1. Lock plate 2. Lower cover Remove the brushroll, and then remove the cap Fig.36 from the brushroll. ►...
- Page 16 Remove threads and hairs from the brushroll Attach the rotary shaft hole of brushroll to the using scissors and the dust from the shaft. rotary shaft and then, install the brushroll as shown in the figure. Fig.39 ► 1. Shaft Fig.42 ►...
- Page 17 Mesh filter Disassemble the mesh filter into three compo- nents: prefilter, tubular sponge filter and mesh pipe. Clean up the mesh filter placed in the cyclone unit when Squeeze the guide stoppers on top of the mesh no suggested improvement on suction performance has pipe together.
- Page 18 Wash the filters and mesh pipe in soapy water Attach the mesh filter back into the cyclone body when they are clogged with dust and dirt. Dry them out aligning the hooks on the mesh filter with the ports on thoroughly in the shade before use.
- Page 19 With the suction inlet pointing downwards, hold NOTE: Dust may fly out when the cyclone unit is the cyclone unit firmly, and then detach the cyclone unit disassembled. It is recommended to place a garbage from the cleaner body slowly and straightly while press- bag underneath the cyclone unit.
- Page 20 OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
