Novell BUSINESS CONTINUITY CLUSTERING 1.2 - ADMINISTRATION Administration Manual page 71

Single-Tree Four-Cluster Driver Set Example
Table 8-9
Cluster Resource Subscriber Node
Publisher Node Cluster One
Cluster One Not applicable
(master node)
Cluster Two CR, port 2002
Cluster Three CR, port 2003
Cluster Four CR, port 2004
You install the drivers on each cluster, with multiple instances in the driver set on Cluster One, but
only a single instance in the peer clusters, as shown in
Driver Set Summary for a Single-Tree, Four-Cluster Business Continuity Cluster
Table 8-10
Driver Set for
Driver Instance
Cluster One
Cluster Resource C1 to C2, port 2002 C2 to C1, port 2002 C3 to C1, port 2003 C4 to C1, port 2004
Cluster Resource C1 to C3, port 2003
Cluster Resource C1 to C4, port 2004
In the four-cluster business continuity cluster, you can set up the fourth node to talk to any one of the
other three, making sure to avoid a configuration that results in a synchronization loop. This might
be desirable if Cluster One and Cluster Two are in one tree (or user object partition), and Cluster
Three and Cluster Four are in a second tree (or user object partition). In this case, you could set up
channels for the Cluster Resource Synchronization driver between Cluster One and Cluster Two,
between Cluster One and Cluster Three, and between Cluster Three and Cluster Four. You must
assign a separate port for each of these channels, as shown in
instance of the User Object Synchronization driver on a different port between the two clusters that
communicate across the two trees (or across the two User object partitions).
Four-Cluster Driver Set Example with User Object Synchronization
Table 8-11
Cluster Resource Subscriber Node
Publisher Node Cluster One
Cluster One Not applicable
(master node)
Cluster Two CR, port 2002
Cluster Two Cluster Three
CR, port 2002 CR, port 2003
Not applicable No channel
No channel Not applicable
No channel No channel
Table 8-10.
Driver Set for Driver Set for
Cluster Two Cluster Three
Table
Cluster Two Cluster Three
CR, port 2002 CR, port 2003
UO, port 2001
Not applicable No channel
Configuring the Identity Manager Drivers for BCC
Cluster Four
CR, port 2004
No channel
No channel
Not applicable
Driver Set for
Cluster Four
8-11. You also need to install an
Cluster Four
No channel
No channel
