Novell BUSINESS CONTINUITY CLUSTERING 1.2 - ADMINISTRATION Administration Manual page 125

Disabling SSL communication to a specific peer cluster requires changing the BCC management
address to the peer cluster. The address is contained in the NCS:BCC Peers attribute that is stored on
the NCS Cluster object.
For example, a default NCS:BCC Peers attribute could appear similar to the following example
where https:// is assumed and is never specified explicitly:
<peer>
<cluster>chicago_cluster</cluster>
<tree>DIGITALAIRLINES_TREE</tree>
<address>10.1.1.10</address>
</peer>
To disable SSL for inter-cluster communication, you would change the <address> attribute to
specify http:// with the IP address, as shown in the following example:
<peer>
<cluster>chicago_cluster</cluster>
<tree>DIGITALAIRLINES_TREE</tree>
<address>http://10.1.1.10</address>
</peer>
The BCC management address of
communication.
The BCC management port can also be changed by modifying the NCS:BCC Peers attribute values.
The default ports for secure and non-secure inter-cluster communication are 5989 and 5988
respectively.
For example, if you want to change the secure port on which OpenWBEM listens from port 5989 to
port 1234, you would change the
<peer>
<cluster>chicago_cluster</cluster>
<tree>DIGITALAIRLINES_TREE</tree>
<address>10.1.1.10:1234</address>
</peer>
The attribute now specifies that inter-cluster communication uses HTTPS over port number 1234.
The NCS:BCC Peers attribute has a value for each peer cluster in the BCC. Attribute values are
synchronized among peer clusters by the BCC-specific Identity Manager driver, so a change to an
attribute value on one cluster causes that attribute value to be synchronized to each peer cluster in
the BCC.
The changes do not take effect until either a reboot of each cluster node, or a restart of the Business
Continuity Clustering software on each cluster node.
Table 13-4 provides an example of possible combinations of scheme and port specifier for the
tag for values of the NCS:BCC Peers attribute:
<address>
Example of Scheme and Port Specifier Values for the NCS:BCC Peers Attribute
Table 13-4
Value
10.1.1.10
now specifies non-secure HTTP
chicago_cluster
attribute value in the above examples to:
<address>
Protocol Used
HTTPS
Port Used
5989
Security Considerations 125
