MVVS 116-BOXER IRS - V1.7 Operating Instructions Manual page 6

Nr. Description Nr.
0101 Crankcase 1102
0102 Crankcase screws-set 1103
0104 Spacer sleeve 1104
0202 Front bearing 1105
0203 Rear bearing 1107
0204 Packing 0306
0205 Rear cover bearing 0307
0304 Pressure nipple 0308
0305 Pressure nipple gasket 1301
0401 Cylinder 1302
0402 Cylinder screws - set 1303
0403 Cylinder nut 1304
0404 Cylinder gasket 1305
0405 Exhaust screws - set 1306
0406 Exhaust nut 1307
0407 Exhaust flange gasket
1300
(set)
0701 Piston
0702 Piston ring
0801 Piston pin 3314B
0802 Piston pin retainer 3309
1001 Crankshaft 1405
1101 Drive washer 3228
Description
Drive washer key
Propeller nut
Propeller washer
Propeller screw
Propeller screws - set
Carburetor flange
Carb. flange gasket
Carb. flange screws - set
Reed valve case
Reed valve
Reed valve screws
Reed valve gasket-upper
Reed valve gasket-bottom
Reed valve strap
Carburetor screws
= 1301 + 1302 + 1303 + 1305 +
1306
Electronic ignition unit ICU-B
Spark plug
Ignition sensor fixing screws
Carburetor
The MVVS gas engines come with a three-year guarantee against defects in workmanship and
materials. Only original buyers of the engines are eligible warranty claimants. The warranty
cannot be transferred with a change in ownership.
This guarantee does not cover:
- any normal wear that might occur
- damage arising from accidents
- damage arising from the use of an unbalanced or damaged propeller
- damage arising from the use of a too small or a too big propeller
- damage arising from the use of low-quality fuel
- damage arising from the use of other than original spare parts and accessories
- damage arising from sucking a foreign object into the engine
- damage arising from any improper use
For further questions, please contact:
MVVS, spol. s r.o., tr. Kpt. Jarose 35, 602 00 Brno, Czech Republic
Tel. +420 545 211 683, fax: +420 545 211 418
E – mail: mvvs@mvvs.cz
Web: www.mvvs.cz
Certificate of Warranty
Date: Serial number:
Buyer's name and address:
Warranty
Dealer:
