QUICK START GUIDE
DISHWASHER - DW60U6I MODELS
For detailed information on the
features of your dishwasher
For warranty information
If you...
have any questions or comments
need a Fisher & Paykel authorized
technician to service your product
need replacement parts or accessories
want to register your product
Cutlery tray
Upper basket
Lower basket
Serial label
B
A
Controls Description
Off/On
Open/Close the door to turn the
dishwasher on or off.
A Half load selector
1/2
Touch to select
If lit: half load function is activated
B Wash modifier selector
Touch to select wash modifier (See 'Setting
wash modifiers')
see your 'User guide'
see your 'Service and warranty' booklet
see your 'Service and warranty' booklet or contact us
NZ toll-free, 24/7
AU toll-free, 24/7
www.fisherpaykel.com
PRODUCT OVERVIEW
Door seal
Detergent
and rinse aid
dispensers
CONTROLS OVERVIEW
H
Start wash or set Delay start
C
Touch and hold to enter delay start
(See 'Set Delay start')
D Wash programme selectors
Touch desired wash programme to
select.
E Display
This shows:
- the time remaining (minutes)
- the delay start time (hours)
- Fault code numbers
(see section 'If there is a fault code')
0800 372 273
1300 650 590
Make sure the installer has removed all packaging and
completed the 'Final checklist' in the Installation instructions.
Upper spray arm
Centre spray arm
Lower spray arm
Filters
D
F Rinse aid indicator
If lit: Rinse aid dispenser requires
filling.
Delay start indicator
G
If lit: start is delayed
H Remote mode (if available)
Visit www.fisherpaykel.com/connect
for more information.
Wireless indicator (if available)
I Visit www.fisherpaykel.com/connect
for more information.
J Salt indicator (if applicable)
If lit: salt reservoir is empty
NZ AU
E G I
C
F J
