Summary of Contents for Hans Grohe Metropol 14837 1 Series
- Page 1 Installation Instructions / Warranty Metropol Kitchen Mixer 14837XX1 Monsoon Kitchen Mixer...
- Page 2 Bester Service, beste Preise Ihr Online-Fachhändler für: • Kostenlose und individuelle Beratung • TOP Bewertungen • Hochwertige Produkte • Exzelenter Kundenservice • Kostenloser und schneller Versand • Über 20 Jahre Erfahrung E-Mail: info@unidomo.de Tel.: 04621 - 30 60 89 0 www.unidomo.de uniDomo GmbH &...
- Page 3 Thank you for purchasing a Monsoon kitchen faucet. It is designed to give you many years of convenience reliability. To save time and prevent aggravation, please take a few moments to read over these instructions thoroughly before removing the old faucet. Insure that you have the tools, supplies, and parts necessary to complete the installation, and that you purchase the correct items to adapt your existing water supplies.
- Page 4 Install the faucet on the sink: If the Monsoon kitchen mixer is to be used on a 3- hole kitchen sink, position the enclosed baseplate and gasket on the faucet deck. From under the sink, install the mounting flanges and tighten the mounting collars.
- Page 5 When you are satisifed that everything is first, tighten the collar nut oriented properly, finish tightening the collar nut. Tighten the tensioning screws. then tighten the tensioning screws Install the water supplies: Install your water supply hookup, carefully following the manufacturers instructions.
- Page 6 Install the hose weight: Proper installation of the hose weight will insure that the handspray hose retracts smoothly. On the handshower side of the hose, use a ruler to measure 15” down from the body of the faucet. Install the hose weight at this point.
- Page 7 Troubleshooting Information: Problem Possible Cause Solution too little water aerator clogged remove and clean aerator screen washer clogged remove and clean screen washer faucet drips debris in cartridge remove and flush cartridge o-rings damaged replace o-rings too little hot water high temperature limit stop set reset high temperature limit stop improperly...
- Page 8 Set the High Temperature Limit Stop (optional) Turn off the water at the supply stops. Close the drain or cover it with a cloth. Gently pry off the screw cover. Put it aside in a safe place. Use a 4mm hex wrench to loosen the handle screw (4 revolutions).
- Page 9 Cleaning Recommendation for Hansgrohe Products Modern faucetry and shower products utilize a combination of materials to comply with the needs of the market with regard to design and functionality. To avoid damage, it is necessary to use some caution when cleaning. Damage caused by improper treatment is not covered under the Hansgrohe warranty.
- Page 10 Limited Lifetime Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products which are purchased by a consumer in the United States after March 1, 1996, and installed in either the United States or Canada. WHO IS COVERED BY THE WARRANTY This warranty extends to the original consumer purchaser only.
- Page 11 In requesting warranty service, you will need to provide The sales receipt or other evidence of the date and place of purchase. A description of the problem. Delivery of the product or the defective part, postage prepaid and carefully packed and insured, to Hansgrohe Inc.
- Page 13 Hansgrohe Inc. 1490 Bluegrass Lakes Parkway Alpharetta GA 30004 Phone 770 360 9880 Internet www.Hansgrohe-USA.com...
