Billion BiPAC 7300N RE User Manual

3g / wireless-n adsl2+ firewall router
Hide thumbs Also See for BiPAC 7300N RE:

Advertisement

Quick Links

Download this manual
BiPAC 7300NX/N RE
(3G) / Wireless-N
ADSL2+ Firewall Router
User Manual
Version Released: 1.05 (FW: v2.02b-dj1)
Last Revised on May 24, 2011

Advertisement

loading
Need help?

Need help?

Do you have a question about the BiPAC 7300N RE and is the answer not in the manual?

Questions and answers

Related Manuals for Billion BiPAC 7300N RE

Summary of Contents for Billion BiPAC 7300N RE

  • Page 1 BiPAC 7300NX/N RE (3G) / Wireless-N ADSL2+ Firewall Router User Manual Version Released: 1.05 (FW: v2.02b-dj1) Last Revised on May 24, 2011...
  • Page 2 2.1 Important Notes ..................11 2.2 Package Contents ................12 2.3 The Front LEDs ..................13 2.4 The Rear Ports ..................14 BiPAC 7300N RE ................14 BiPAC 7300NX ..................15 2.5 Cabling ....................17 Chapter 3 ........................18 3.1 Before Configuration................18 3.2 Network Configuration ................
  • Page 3 5.3.1.3 Wireless................... 65 5.3.1.4 Wireless Security..............68 5.3.1.5 WPS ..................72 5.3.1.6 DHCP Server................85 5.3.2 WAN (Wide Area Network) ..............87 5.3.2.1 WAN Interface (BiPAC 7300NX only) ........88 5.3.2.2 WAN Profile ................90 5.3.2.3 ADSL Mode ................101 5.3.3 System ....................
  • Page 4 APPENDIX......................161...
  • Page 5 Chapter 1 Introduction 1.1 Introducing the BiPAC 7300NX/N RE The BiPAC 7300NX/N RE is an economical ADSL2+ router ideal for residential users to have an improved wireless access with a maximum operational speed of 300Mbps. It delivers the highest level of security with higher speed and better coverage of wireless-N solutions.
  • Page 6 ADSL connection when it's restored, reducing connection costs. BiPAC 7300N RE also equips its port #1 can be configured as a WAN port for connecting to ADSL, Cable, VDSL or a Fiber modem device, providing more options for users to access the Internet.
  • Page 7 • Dual-WAN approach – ADSL2+ and 3G connections (BiPAC 7300NX only) • Dual-WAN approach –ADSL2+ and Ethernet WAN for Broadband Connectivity (BiPAC 7300N RE only) • USB 2.0 port for plugging a 3G / HSDPA modem as backup (available from your service provider) (BiPAC 7300NX only) •...
  • Page 8 ADSL Compliance • Compliant with ADSL Standards - Full-rate ANSI T1.413 Issue 2 - G.dmt (ITU G.992.1) - G.lite (ITU G.992.2) - G.hs (ITU G.994.1) - ADSL over ISDN/U-R2 • Compliant with ADSL2 Standards - G.dmt.bis (ITU G.992.3) - ADSL2 Annex M (ITU G.992.3 Annex M) (available for BiPAC 7300NX/ N RE A model only) •...
  • Page 9 Firewall & Virtual Private Network(VPN) • Built-in NAT Firewall • Stateful Packet Inspection (SPI) • Prevents DoS attacks including Land Attack and Ping of Death, etc. • Remose access control for web base access • Anti probe function • Packet filtering, MAC filtering, URL content filtering •...
  • Page 10 • WLAN on/off time schedule control ATM and PPP Protocols • ATM Adaptation Layer Type 5 (AAL5) • Multiple Protocol over AAL5 (RFC 2684, formerly RFC 1483) • Bridged or routed Ethernet encapsulation • VC and LLC based multiplexing • PPP over Ethernet (PPPoE) •...
  • Page 11 Compatible 3G USB modems (BiPAC 7300NX only) 3G Brand 3G Model ONDA MF628,MF638, MDC525UP, MO825UP,MF622,MDC502HS Option ICON225 NOVATEL MC950D Zoom 4595 Vodafone K3520-Z Huawe E270,E220 Sierra AirCard 880U,875U,888 Quanta GKXQCX The list is continously updated at http://www.billion.com/compatible-3G.html...
  • Page 12 • DSL: ADSL port • Ethernet: 4-port 10/100M auto-crossover (MDI/MDI-X) switch • EWAN: Ethernet port#1 can be configured to ADSL/Cable/VDSL/Fiber mode device (BiPAC 7300N RE only) • USB 2.0 supports 3G/HSDPA modem backup (BiPAC 7300NX only) • Factory default reset button •...
  • Page 13 1.2 Applications of the devices BiPAC 7300N RE Broadband Router mode ADSL Router mode...
  • Page 14 BiPAC 7300NX...
  • Page 15 Chapter 2 Product Overview 2.1 Important Notes Do not use the router in high humidity or high temperatures. Do not use the same power source for the router as other equipment. Do not open or repair the case yourself. If the router is too hot, turn off the power immediately and have it repaired at a Warning qualified service center.
  • Page 16 2.2 Package Contents BiPAC 7300NX/N RE (3G) / Wireless-N ADSL2+ Firewall Router CD-ROM containing the on-line manual and QSG RJ-11 ADSL/telephone Cable Ethernet (RJ-45) Cable Power Adapter Quick Start Guide Two detachable antennas Splitter / Micro-filter (Optional)
  • Page 17 2.3 The Front LEDs Meaning Lit red while the flash is damage and cannot bring the system Power Lit green when the system is ready. Flashes green when the the system is rebooting or firmware upgrading. Ethernet Lit green when connected to an Ethernet device. Port 1 - 4 Blinking when data is Transmitted / Received.
  • Page 18 2.4 The Rear Ports BiPAC 7300N RE Port Description Antenna Connect the antenna to this port. ON/OFF Power ON/OFF switch. Power Connect the supplied power adapter to this jack. After the router is powered on, press this reset button using the end of paper clip or other small pointed object for 6 seconds and above to restore it to factory default settings.
  • Page 19 BiPAC 7300NX Port Description Antenna Connect the antenna to this port. ON/OFF Power ON/OFF switch. Power Connect the supplied power adapter to this jack. After the router is powered on, press this reset button using the end of paper clip or other small pointed object for 6 seconds and above to restore it to factory default settings.
  • Page 20 The detail instruction in Reset Button 1. Recovery procedures for non-working routers (e.g. after a failed firmware upgrade flash): Hold the Reset Button on the back of the modem in. Keep this button held in and turn on the modem. Once the lights on the modem have stopped flashing, release the Reset Button. modem's emergency-reflash interface...
  • Page 21 2.5 Cabling One of the most common causes of problems is because of bad cabling or ADSL line(s). Make sure that all connected devices are turned on. On the front of the product is a bank of LEDs. Verify that the LAN Link and ADSL line LEDs are lit. If they are not, verify that you are using the proper cables.
  • Page 22 Chapter 3 Installation You can configure the BiPAC 7300NX/N RE router through the convenient and user-friendly interface of a web browser. Most popular operating systems such as Linux and Windows 7/Vista/98/NT/2000/XP/Me include a web browser as a standard application. 3.1 Before Configuration PCs must have a properly installed Ethernet interface which connects to the router directly or through an external repeater hub.
  • Page 23 3.2 Network Configuration 3.2.1 Configuring a PC in Windows 7 1. Go to Start. Click on Control Panel. Then click on Network and Internet. 2. When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel.
  • Page 24 4. Select Internet Protocol Version 4 (TCP/IPv4) then click Properties. 5. In the TCP/IPv4 properties window, select the Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. 6. Click OK again in the Local Area Connection Properties window to apply...
  • Page 25 3.2.2 Configuring a PC in Windows Vista 1. Go to Start. Click on Network. 2. Then click on Network and Sharing Center at the top bar. 3. When Network Sharing Center window pops up, select and click on Manage network connections left window pane.
  • Page 26 5. Select Internet Protocol Version 4 (TCP/IPv4) then click Properties. 6. In the TCP/IPv4 properties window, select the Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. 7. Click OK again in the Local Area Connection Properties window to apply...
  • Page 27 3.2.3 Configuring a PC in Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4.
  • Page 28 3.2.4 Configuring a PC in Windows 2000 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4.
  • Page 29 3.2.5 Configuring PC in Windows 98/Me 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network choose Configuration tab. 2. Select TCP/IP ->NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC. 3.
  • Page 30 3.2.6 Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.
  • Page 31 3.3 Factory Default Settings Before configuring the router, you need to know the following default settings. Web Interface: (Username and Password) Username: admin Password: admin The default username and password are “admin” and “admin” respectively. If you ever forget the username/password to login to the router, you may press the RESET button up to 6 seconds then release it to restore the factory default settings.
  • Page 32 3.4 LAN and WAN Port Addresses The parameters of LAN and WAN ports are preset in the factory. The default values are shown below. LAN Port WAN Port IP address 192.168.1.254 PPPoE function enabled to automatically get Subnet Mask 255.255.255.0 the WAN port configuration from the ISP.
  • Page 33 3.6 Configuring with your BiPAC 7300NX/N RE 1. To configure this device, you must have IE 5.0 / Netscape 4.5 or above installed 2. You may configure the router for Internet access in two ways: (A) Easy Sign-On (EZSO) (B) Web Configuration Easy Sign On After setting up the router with appropriate cables plugged, proceed to load the internet browser to surf Internet, the EZSO WEB GUI will be popped up and request you to input...
  • Page 34 3. Show Auto scan result - Protocol information. 4. Please enter “Username” and “Password” as supplied by your ISP (Internet Service Provider) and click continue. 5. Wait for the device to be configured. 6. You’ve have completed the WAN port setup and now click “Next to Wireless” to proceed to the wireless configuration.
  • Page 35 7. Please configure the Wireless LAN setting and click Continue. 8. Save Configuration. 9. Congratulations!! You’ve completed the setup procedure and you are now ready to surf the Internet, enjoy.
  • Page 36 192.168.1.254, and click “Go”, a user name and password prompt window appears. The default username and password are “admin” and “admin” respectively. Congratulations! You have successfully logged in to your BiPAC 7300N RE Router! Congratulations! You have successfully logged in to your BiPAC 7300NX Router!
  • Page 37 Chapter 4 Basic Configuration Once you have logged on to your BiPAC 7300NX/N RE Router via your web browser, you can begin to set it up according to your requirements. On the configuration homepage, the left navigation pane links you directly to the setup pages, which include: Advanced (Switch to Advanced Configuration mode) Status Quick Start...
  • Page 38 4.1 Status ( BiPAC 7300NX for example) Device Information Model Name: Provide a name for the router for identification purposes. System Up-Time: Records system up-time. Hardware Version: Device version Software Version: Firmware version Physical Port Status Port Status: Users can look up to see if they are connected to Ethernet, ADSL, 3G (7300NX only), EWAN (7300N RE only) or Wireless.
  • Page 39 4.2 Quick Start For the exactly steps, turn to Advanced –Quick Start for help. Set Wireless configuration WLAN Service: Default setting is set to Enable. ESSID: The ESSID is the unique name of a wireless access point (AP) to be distinguished from another.
  • Page 40 4.3 WAN ADSL Main Port: Select the connection mode from the drop-down menu, here ADSL. VPI/VCI: Enter the VPI and VCI information provided by your ISP. Username: Enter the username provided by your ISP. You can input up to 128 alphanumeric characters (case sensitive).
  • Page 41 EWAN (BiPAC 7300N RE only) Main Port: Select the connection mode from the drop-down menu, here EWAN. Protocol: select the protocol used: Obtain an IP Address Automtically, Fixd IP Address or PPPoE. For detail, please turn to EWAN Profile...
  • Page 42 3G (BiPAC 7300NX only) Mode: There are 5 options of phone service standards: GSM only, UTMS only, GPRS/EDGE first, UMTS first, and Automatic. If you are uncertain what services are available to you, and then please select Automatic. APN: An APN is similar to a URL on the WWW, it is what the unit makes a GPRS / UMTS call.
  • Page 43 4.4 WLAN WLAN Service: Default setting is set to Enable. ESSID: The ESSID is the unique name of a wireless access point (AP) to be distinguished from another. For security propose, change to a unique ID name to the AP which is already built-in to the router’s wireless interface.
  • Page 44 Channel ID: Select the ID channel that you would like to use. Security Mode: You can disable or enable with WPA or WEP for protecting wireless network. The default mode of wireless security is Disable. Security Parameters WPA or WPA2 WPA and WPA2 pre-shared keys are an authentication mechanism in which users provide some form of credentials to verify that they should be allowed access to a network.
  • Page 45 this AP, failure occurs. This ESSID(AP) will be invisible to you. In this case, if you want to join this wireless network, enter the exactly ESSID manually and some security settings. Disable: When Disable is selected, the router will broadcast the ESSID to allow anybody with a wireless client to be able to identify the Access Point (AP) of your router.
  • Page 46 WPA / WPA2 Pre-Shared Key WLAN Service: Default setting is set to Enable. If you want to use wireless, you can select Enable. ESSID: The ESSID is the unique name of a wireless access point (AP) used to distinguish one from another. For security propose, change to a unique ID name which is already built into the router wireless interface.
  • Page 47 WLAN Service: Default setting is set to Enable. If you do not have any wireless, select Disable. ESSID: The ESSID is the unique name of a wireless access point (AP) used to distinguish one from another. For security propose, change to a unique ID name which is already built into the router wireless interface.
  • Page 48 Channel ID: Select the wireless connection channel ID that you would like to use. Note: Wireless performance may degrade if the selected channel ID is already being occupied Security Mode: You can disable or enable with WPA or WEP to protect wireless network. The default mode of wireless security is Disable.
  • Page 49 Chapter 5 Advanced Configuration Once you have logged on to your BiPAC 7300NX/N RE Router via your web browser, you can begin to set it up according to your requirements. On the configuration homepage, the left navigation pane links you directly to the setup pages, which include: Basic (Switch to Basic Configuration Mode) Status (ADSL Status, 3G Status (BiPAC 7300NX only), ARP Table, DHCP Table, System Log, Firewall Log, UPnP Portmap)
  • Page 50 5.1 Status ( BiPAC 7300NX for example) Device Information Host Name: Provide a name for the router for identification purposes. Host Name lets you change the router name.
  • Page 51 System Up-Time: Records system up-time. Current time: Set the current time. See the Time Zone section for more information. Hardware Version: Device version. Software Version: Firmware version. MAC Address: The LAN MAC address. Port: Name of the WAN connection. Protocol VPI/VCI: Virtual Path Identifier and Virtual Channel Identifier Operation: Current available operation.
  • Page 52 5.1.1 ADSL Status DSP Firmware Version: DSP code version DMT Status: Current DMT Status Operational Mode: To show the state when user select “AUTO” on connect mode. Click the link, the following will appear. ADSL Mode: There are four modes “Open Annex Type and Follow DSLAM’s Setting”, ”Annex A”, ”Annex L”, ”Annex M”...
  • Page 53 5.1.2 3G Status (BiPAC 7300NX only) Status: The current status of the 3G card. Click Status to go to 3G configuration page. Signal Strength: The signal strength bar indicates current 3G signal strength. Network Name: The network name that the device is connected to. Network Mode: The current operation mode in 3G card, it depends on service provider and card’s limitation.
  • Page 54 5.1.3 ARP Table This section displays the router’s ARP (Address Resolution Protocol) Table, which shows the mapping of Internet (IP) addresses to Ethernet (MAC) addresses. This is useful as a quick way of determining the MAC address of the network interface of your PCs to use with the router’s Firewall –...
  • Page 55 5.1.5 System Log Display system logs accumulated up to the present time. You can trace historical information with this function.
  • Page 56 5.1.6 Firewall Log Firewall Log displays log information of any unexpected action with your firewall settings. This page displays the router’s Firewall Log entries. The log shows log entries when you have enabled Intrusion Detection or Block WAN PING in the Configuration – Firewall section of the interface.
  • Page 57 5.1.7 UPnP Portmap The section lists all port-mapping established using UPnP (Universal Plug and Play). Please see the Advanced section of this manual for more details on UPnP and the router’s UPnP configuration options. Name: the description of this application. Protocol: the protocol used by UpnP NAT Mapping.
  • Page 58 5.2 Quick Start ADSL Step1: select ADSL connection Mode. Click Continue to go to next step. Step2: select Auto to let this device to automatically scan the VPI/VCI, go to step 3. Or select Manually to go to step 4. Step 3: wait when the ADSL is scanning.
  • Page 59 Step 4: type the username and password provided by your ISP. Click Continue to go on. Step 5: wait while the device is configured. Step 6: WAN connection configuration is successful.
  • Page 60 Step 7: Click Next to Wireless to do wireless configuration. Enter the ESSID, select the Channel ID and the Security Mode, click Continue to go on. For detail, please turn to WLAN in this manual for help. Step 8: wait while saving configuration to Flash. Step 9: success.
  • Page 61 Obtain an IP Address Automatically When connecting to the ISP, BiPAC 7300N RE also functions as a DHCP client. BiPAC 7300N RE can automatically obtain an IP address, subnet mask, gateway address, and DNS server addresses if the ISP assigns this information via DHCP.
  • Page 62 If connection is successful the following image will be shown. Fixed IP Address Select this option to set static IP information. You will need to enter in the Connection type, IP address, Netmask, and gateway address, provided to you by your ISP. Each IP address entered in the fields must be in the appropriate IP form, which is four IP octets separated by a dot (x.x.x.x).
  • Page 63 If connection is successful the following image will be shown. PPPoE PPPoE (PPP over Ethernet) provides access control in a manner similar to dial-up services using PPP. Protocol: The current ATM protocol in the device Username: Enter the username provided by your ISP. You can input up to 128 alphanumeric characters (case sensitive).
  • Page 64 Click on the Continue button and wait for your connection to be connected. If connection is successful the following image will be shown.
  • Page 65 3G (BiPAC 7300NX only) Connect Mode: 3G. TEL No.: The dial string to make a GPRS / 3G user internetworking call. Username: The username provided by your service provider. APN: An APN is similar to a URL on the WWW, it is what the unit makes a GPRS / UMTS call.
  • Page 66 Username/Password: Enter the username and password provided by your ISP. Authentication Protocol: Default is Auto. Please consult your ISP on whether to use PAP, CHAP. PIN: PIN stands for Personal Identification Number. A PIN code is a numeric value used in certain systems as a password to gain access, and authenticate.
  • Page 67 5.3 Configuration Click this item to access the following sub-items that configure the ADSL router: LAN, WAN, System, USB (BiPAC 7300NX only), Firewall, QoS, Virtual Server, Wake on LAN, Time Schedule and Advanced. These functions are described in the following sections. (BiPAC 7300NX ) 5.3.1 LAN (Local Area Network) A Local Area Network (LAN) is a shared communication system to which many computers...
  • Page 68 The router supports more than one Ethernet IP addresses in the LAN, and with distinct LAN subnets through which you can access the Internet at the same time. Users usually only have one subnet in their LAN. The default IP address for the router is 192.168.1.254. IP Address: The default IP on this router.
  • Page 69 Click Edit radio button, then the item you want to reedit will be displayed above just as showed below. Press Edit/Delete to apply your modification. Check Delete if you want to delete the item, then press Edit/Delete, the deleting prompt window will appear to remind you, do as you like.
  • Page 70 prioritization policy. Here we provide two groups of Time Schedule setting. You can flexibly set the time you want the wireless connection works. If you select Always On in group1, then the group2 is disabled. While if you select any other item from the group1 drop-down menu, the group2 will be activated.
  • Page 71 Channel ID: Select the ID channel that you would like to use. Channel Wdith: Select either 20 MHz or 20/40 MHz or 40MHZ for the channel bandwidth. The higher the bandwidth the better the performance will be. Note: This parameter appears only when you select one of the item as the following graph Tx Power Level: It is function that enhances the wireless transmitting signal strength.
  • Page 72 2. Peer WDS MAC Address: It is the second associated AP’s MAC Address. 3. Peer WDS MAC Address: It is the third associated AP’s MAC Address. 4. Peer WDS MAC Address: It is the fourth associated AP’s MAC Address. Note: For MAC Address, Semicolon ( : ) or Dash (-) must be included. 5.3.1.4 Wireless Security You can disable or enable with WPA or WEP for protecting wireless network.
  • Page 73 automatically between wireless client and Access Point (AP). Default value is 3600 seconds. If you want to enable the RADIUS service, check Enable and then do the following settings. RADIUS Server IP Address: Enter the IP address of RADIUS authentication server. RADIUS Server Port: Enter the port number of RADIUS authentication server here.
  • Page 74 The Default algorithm is AES. WPA Shared Key: The key for network authentication. The input format is in character style and key size should be in the range between 8 and 63 characters. Group Key Renewal: The period of renewal time for changing the security key automatically between wireless client and Access Point (AP).
  • Page 75 If you want to enable the RADIUS service, check Enable and then do the following settings. WEP Authentication: If you enable RADIUS/802.1x, then the default WEP Authentication is Open System. RADIUS Server IP Address: Enter the IP address of RADIUS authentication server. RADIUS Server Port: Enter the port number of RADIUS authentication server here.
  • Page 76 5.3.1.5 WPS WPS (WiFi Protected Setup) feature is a standard protocol created by Wi-Fi Alliance. This feature greatly simplifies the steps needed to create a Wi-Fi network for a residential or an office setting. WPS supports 2 types of configuration methods which are commonly known among consumers: Method &...
  • Page 77 3. Launch the wireless client’s WPS utility (eg. Ralink Utility). Set the Config Mode as Enrollee, press the WPS button on the top bar, select the AP (eg. wlan-ap) from the WPS AP List column. Then press the PIN button located on the middle left of the page to run the scan.
  • Page 78 4. The client’s SSID and security setting will now be configured to match the SSID and security setting of the registrar.
  • Page 79 PIN Method: Configure AP as Enrollee 1. In the WPS configuration page, change the Role to Enrollee. Then press Start. 2. Jot down the WPS PIN (eg. 25879810). 3. Launch the wireless client’s WPS utility (eg. Ralink Utility). Set the Config Mode as Registrar. Enter the PIN number in the PIN Code column then choose the correct AP (eg.
  • Page 80 4. The router’s (AP’s) SSID and security setting will now be configured to match the SSID and security setting of the registrar.
  • Page 81 5. Now to make sure that the setup is correctly done, cross check to see if the SSID and the security setting of the registrar setting match with the parameters found on both Wireless Configuration and Wireless Security Configuration page.
  • Page 82 The parameters on both Wireless Configuration and Wireless Security Configuration page are as follows:...
  • Page 83 PBC Method: 1. Press the PBC button of the AP. 2. Launch the wireless client’s WPS Utility (eg. Ralink Utility). Set the Config Mode as Enrollee. Then press the WPS button and choose the correct AP (eg. wlan-ap) from the WPS AP List section before pressing the PBC button to run the scan.
  • Page 84 3. When the PBC button is pushed, a wireless communication will be established between your router and the PC. The client’s SSID and security setting will now be configured to match the SSID and security setting of the router.
  • Page 85 Wi-Fi Network Setup with Windows Vista WCN: 1. Jot down the AP PIN from the Web (eg. 25879810). 2. Access the Wireless configuration of the web GUI. Enable WPS Service and set the WPS State to Unconfigured then click Apply.
  • Page 86 3. In your Vista operating system, access the Control Panel page, then select Network and Internet > View Network Computers and Devices. Double click on the BiPAC 7300NX/N RE icon and enter the AP PIN in the column provided then press Next.
  • Page 87 4. Enter the AP SSID then click Next. 5. Enter the Passphrase then click Next.
  • Page 88 6. When you have come to this step, you will have completed the Wi-Fi network setup using the built-in WCN feature in Windows Vista.
  • Page 89 5.3.1.6 DHCP Server You can disable or enable the DHCP (Dynamic Host Configuration Protocol) server or enable the router’s DHCP relay functions. The DHCP protocol allows your router to dynamically assign IP addresses to PCs on your network if they are configured to obtain IP addresses automatically.
  • Page 90 DHCP Server Mode: DHCP Server To configure the router’s DHCP Server, check DHCP Server. You can then configure parameters of the DHCP Server including the IP pool (starting IP address and ending IP address to be allocated to PCs on your network), lease time for each assigned IP address (the period of time the IP address assigned will be valid), DNS IP address and the gateway IP address.
  • Page 91 DHCP Server Mode: DHCP Relay If you check DHCP Relay and then you must enter the IP address of the DHCP server which assigns an IP address back to the DHCP client in the LAN. Use this function only if advised to do so by your network administrator or ISP.
  • Page 92 5.3.2.1 WAN Interface (BiPAC 7300NX only) ADSL WAN Connection Main Port: Select main port from the drop-down menu. Two connection ports are supported: ADSL and 3G. Failover Parameters Failover/Failback: check to determine whether to enable Failover/Failback feature. When enabled, the following parameters will be available. Backup Port: 3G.
  • Page 93 Detect Rule (either one): 1. ADSL Down 2. Ping Fail • No Ping: It will not send any ping packet to determine the connection. It means to disable the ping fail detection. • Ping Gateway: It will send ping packet to gateway and wait response from gateway in every ”Probe Cycle”.
  • Page 94 5.3.2.2 WAN Profile Main Port--ADSL PPPoE Connection (ADSL) PPPoE (PPP over Ethernet) provides access control in a manner similar to dial-up services using PPP. Description: A user-definable name for this connection. VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap.
  • Page 95 IP Address: Your WAN IP address. Leave this at 0.0.0.0 to automatically obtain an IP address from your ISP. Auth. Protocol: Default is Auto. Your ISP advises on using Chap or Pap. Obtain DNS Automatically: Select this check box to use DNS. Primary DNS/ Secondary DNS: Enter the IP addresses of the DNS servers.
  • Page 96 one provided by your ISP Username: Enter the username provided by your ISP. You can input up to 128 alphanumeric characters (case sensitive). This is in the format of “username@ispname” instead of simply “username”. Password: Enter the password provided by your ISP. You can input up to 128 alphanumeric characters (case sensitive).
  • Page 97 MPoA Connection (ADSL) Description: Your description of this connection. VPI and VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format, the default is LLC. Select the one provided by your ISP. Encap. mode: Choose whether you want the device to function as bridge mode or routing mode.
  • Page 98 Pure Bridge Connections (ADSL) Description: A user-definable name for this connection. VPI/VCI: Enter the VPI and VCI information provided by your ISP. Encap. method: Select the encapsulation format, this is provided by your ISP. PPPoE with Pass-through (ADSL) Description: A user-definable name for this connection. VPI/VCI: Enter the VPI and VCI information provided by your ISP.
  • Page 99 alphanumeric characters (case sensitive) Service Name: This item is for identification purposes. If it is required, your ISP provides you the information. Maximum input is 15 alphanumeric characters. NAT: The NAT (Network Address Translation) feature allows multiple users to access the Internet through a single ISP account, sharing a single IP address.
  • Page 100 Main Port—EWAN (BiPAC 7300N RE only) Besides using ADSL to get connected to the Internet, BiPAC 7300N RE offers its Ethernet port 1 as a WAN port to be used to connect to Cable Modems, VDSL and fibre optic lines.
  • Page 101 Fixed IP Address (EWAN) Select this option to set static IP information. You will need to enter in the Connection type, IP address, netmask, and gateway address, provided to you by your ISP. Each IP address entered in the fields must be in the appropriate IP form, which is four IP octets separated by a dot (x.x.x.x).
  • Page 102 PPPoE (EWAN) PPPoE (PPP over Ethernet) provides access control in a manner similar to dial-up services using PPP. Line Speed: Set the downstream and upstream of your connection in kilobytes per second. The connection speed is used by QoS settings. Username: Enter the username provided by your ISP.
  • Page 103 Main Port—3G (BiPAC 7300NX only) Mode: There are 5 options of phone service standards: GSM only, UTMS only, GPRS/EDGE first, UMTS first, and Automatic. If you are uncertain what services are available to you, then please select Automatic. TEL No.: The dial string to make a GPRS / 3G user internetworking call. It may provide by your mobile service provider.
  • Page 104 Connection: Always On: Check Enable to allow the router automatically reconnects the connection when ISP disconnects it. Keep Alive: Check Enable to allow the router to send message out every 30sec to prevent the connection being dropped by ISP. Connection on Demand: If you want to establish a 3G session only when there is a packet requesting access to the Internet.
  • Page 105 5.3.2.3 ADSL Mode ADSL Mode: There are four modes “Open Annex Type and Follow DSLAM’s Setting”, ”Annex A”, ”Annex L”, ”Annex M” and “Annex J” that user can select for this connection. Modulator: There are seven modes “AUTO”,”ADSL multimode”,”ADSL2”,”ADSL2+”, “G.Lite:”, “T1.413” and “G.DMT” that user can select for this connection.
  • Page 106 5.3.3 System There are five items within the System section: Time Zone, Firmware Upgrade, Backup/Restore, Restart, User Management and Mail Alert. (BiPAC 7300NX)
  • Page 107 5.3.3.1 Time Zone The router does not have a real time clock on board; instead, it uses the Simple Network Time Protocol (SNTP) to get the current time from an SNTP server outside your network. Choose your local time zone, click Enable and click the Apply button. After a successful connection to the Internet, the router retrieves the correct local time from the SNTP server you have specified.
  • Page 108 5.3.3.2 Firmware Upgrade Your router’s “firmware” is the software that allows it to operate and provides all its functionality. Think of your router as a dedicated computer, and the firmware as the software it runs. Over time this software may be improved and modified. Your router allows you to upgrade the software it runs to take advantage of these changes.
  • Page 109 5.3.3.3 Backup / Restore These functions allow you to save and backup your router’s current settings to a file on your PC, or to restore a previously saved backup. This is useful if you wish to experiment with different settings, knowing that you have a backup handy in the case of any mistakes. It is advisable to backup your router’s settings before making any significant changes to your router’s configuration.
  • Page 110 5.3.3.4 Restart Router Click Restart with option Current Settings to reboot your router and save the current configuration to device. If you wish to restart the router using the factory default settings (for example, after a firmware upgrade or if you have saved an incorrect configuration), select Factory Default Settings to reset to factory default settings.
  • Page 111 Send a log via email, if WAN IP is changed or if intruders accessing your computer without permission. BiPAC 7300N RE SMTP Server: Enter the SMTP server that you would like to use for sending emails. Username: Enter the username of your email account to be used by the SMTP server.
  • Page 112 BiPAC 7300NX SMTP Server: Enter the SMTP server that you would like to use for sending emails. Username: Enter the username of your email account to be used by the SMTP server. Password: Enter the password of your email account. Sender’s Email: Enter your email address.
  • Page 113 5.3.4 USB Besides connecting to 3G modem, USB 2.0 port can also provide storage features, and server as FTP Server and Samba Server. USB Server has integrated FTP Server feature. Through FTP Server, Samba Server user can management the account, set the authority of download and upload. There are five items within the USB section: User Management, Storage, Samba Server, FTP.
  • Page 114 Add/Delete User 1. Enter username and password (admin is the default user) 2. Click Add. The new user account will display below. 3. Choose the account which you want to edit then you can change the account’s parameters, click Edit/Delete to confirm changes. 4.
  • Page 115 In the above example, we add a user named test. And the user is granted with authority of FTP and Samba server access. User test can access the FTP server with FTP access client (first enable FTP server in FTP Server section).
  • Page 116 5.3.4.2 Storage Storage page displays the information of storage device which plugged in USB port. In the listing, all the folders in the USB device will be shown. For example, in the following diagram, you will Folder home and ytt. In this section, you can create/delete/rename the folders in the storage device.
  • Page 117 Add/Delete directory 1. Enter directory name in the directory name field and choose partition path which the directory will located. 2. Click Add. The New directory will display below.
  • Page 118 3. Choose the directory which you want to delete then click Rename/Delete to romove this directory. A message from webpage will remind you by ”Are you sure to deleter data?” before you decide to submit the command. Rename directory Choose the directory which you want to rename then enter the new name for the folder, and click Rename/Delete to rename this directory.
  • Page 119 5.3.4.3 Samba Server Samba Server Setup Samba Service: Enable or Disable Samba Server function. Workgroup: Enter the workgroup name in this field which should be same as workgroup name for PCs. NetBIOS Name: Enter NetBIOS name in this field. In Network Neighborhood, you will find this Samba server name.
  • Page 120 5.3.4.4 FTP Server Enable FTP Server feature, your device can serve as a FTP server, you can use FTP access client or windows cmd to upload/download files. Note: to give access to users, please go to USB > User Management. In User Management section, set the authority for the user.
  • Page 121 5.3.5 Firewall Firewall and Access Control Your router includes a full SPI (Stateful Packet Inspection) firewall for controlling Internet access from your LAN, as well as helping to prevent attacks from hackers. In addition to this, when using NAT (Network Address Translation) the router acts as a “natural” Internet firewall, since all PCs on your LAN use private IP addresses that cannot be directly accessed from the Internet.
  • Page 122 Firewall Security and Policy (General Settings): Inbound direction of Packet Filter rules prevent unauthorized computers or applications accessing your local network from the Internet. Intrusion Detection: Enable Intrusion Detection to detect, prevent, and log malicious attacks. MAC Filter rules: Prevents unauthorized computers accessing the Internet. URL Filter: Blocks PCs on your local network from unwanted websites.
  • Page 123 5.3.5.1 Packet Filter Packet filtering enables you to configure your router to block specified internal/external users (IP address) from Internet access, or you can disable specific service requests (Port number) to /from Internet. This configuration program allows you to set up to 6 different filter rules for different users based on their IP addresses or their network Port number.
  • Page 124 Direction: Determine whether the rule is for outgoing packets or for incoming packets. Time Schedule: It is self-defined time period. You may specify a time schedule for your prioritization policy. For setup and detail, refer to Time Schedule section. Log: Choose “log” if you wish to generate logs when the filer rule is applied to a packet. Add: Click this button to add a new packet filter rule and the added rule will appear at the bottom table.
  • Page 125 5.3.4.2 MAC Filter A MAC (Media Access Control) address is the unique network hardware identifier for each PC on your network’s interface (i.e. its Network Interface Card or Ethernet card). Using your router’s MAC Address Filter function, you can configure to block specific machines from accessing your LAN.
  • Page 126 5.3.4.3 Intrusion Detection Check Enable if you wish to detect intruders accessing your computer without permission. The router automatically detects and blocks a DoS (Denial of Service) attack if a user enables this function. This kind of attack is not to access confidential data on the network; instead, it aims to disrupt specific equipment or the entire network.
  • Page 127 For SYN Flood, ICMP Echo Storm and ICMP flood, IDS will just warn the user in the Event Log but it will not be able to protect against such attacks. Hacker attack types recognized by the IDS Type of Block Intrusion Name Detect Parameter Blacklist Drop Packet Show Log...
  • Page 128 Src IP: Source IP Src Port: Source Port Dst Port: Destination Port Dst IP: Destination IP 5.3.4.4 Block WAN PING Check Enable if you wish to exclude outside PING requests from reaching this router. 5.3.4.5 URL Filter URL (Uniform Resource Locator – e.g. an address in the form of http://www.example.com filter rules allow you to prevent users on your network from accessing particular websites from their URL.
  • Page 129 “abcde” occurs in the URL. Domains Filtering: Checks the domain name in URLs accessed against your list of domains to block or allow. If it matches, the URL request is sent (Trusted) or dropped (Forbidden). The checking procedure is: 1. Check the domain in the URL to determine if it is in the trusted list. If yes, the connection attempt is sent to the remote web server.
  • Page 130 Block Cookies: Blocks Cookies Block Proxy: Blocks Proxy Except IP Address: Time Schedule: It is self-defined time period. You may specify a time schedule for your prioritization policy. For setup and detail, refer to Time Schedule section. Log: Click “Log” if you wish to generate logs when the filer rule is applied to the URL Filter.
  • Page 131 5.3.5 QoS (Quality of Service) Quality of Service Introduction If you’ve ever found your ‘net’ speed has slowed to a crawl because another family member is using a P2P file sharing program, you’ll understand why the Quality of Service features in the routers is such a breakthrough for home users and office users.
  • Page 132 There are two settings to be provided in the Router: LAN to WAN: You want to control the traffic flow from the local network to the outside world (Upstream). You can assign the priority for the application or you can limit the rate your application used.
  • Page 133 DSCP Mapping Table ADSL2+ Router Standard DSCP Disabled None Best Effort Best Effort (000000) Premium Express Forwarding (101110) Gold service (L) Class 1, Gold (001010) Gold service (M) Class 1, Silver (001100) Gold service (H) Class 1, Bronze (001110) Silver service (L) Class 2, Gold (010010) Silver service (M) Class 2, Silver (010100)
  • Page 134 have higher priority to acquire the bandwidth. High Normal: The default is normal priority. For the sample priority assignment for different policies, it is served in a First-In-First-Out way. Internal IP Address: The IP address values for Local LAN machines you want to control. (For IP packets from LAN to WAN, it is the source IP address.
  • Page 135 QoS example for your Network Connection Diagram VoIP HTTP web Normal PCs browsing users Restricted PC ADSL Subscription Rate Upstream: 256 kbps Downstream: 2048 Mbps Example QoS Plan Application IP or Ports Control Flow Data Rate Time Schedule VoIP User 192.168.1.1 Outgoing High priority for bandwidth...
  • Page 136 Example QoS Setup VoIP application Voice is latency-sensitive application. Most VoIP devices are used SIP protocol and the port number will be assigned by SIP module automatically. Better to use fixed IP address for catching VoIP packets as high priority.
  • Page 137 5.3.6 Virtual Server In TCP and UDP networks a port is a 16-bit number used to identify which application program (usually a server) incoming connections should be delivered to. Some ports have numbers that are pre-assigned to them by the IANA (the Internet Assigned Numbers Authority), and these are referred to as “well-known ports”.
  • Page 138 designated as “well-known ports”. The registered ports are numbered from 1024 through 49151. The remaining ports, referred to as dynamic ports, or private ports, are numbered from 49152 through 65535. Examples of well-known and registered port numbers are shown below, for further information, please see IANA’s website at: http://www.iana.org/assignments/port-numbers Well-known and Registered Ports...
  • Page 139 5.3.6.1 Port Mapping Application: Select the service you wish to configure Protocol: Automatic when you choose Application from listbox or select a protocol type which you want. External Port & Internal Port: Enter the public port number & range you wish to configure.
  • Page 140 Since NAT acts as a “natural” Internet firewall, your router protects your network from access by outside users, as all incoming connection attempts point to your router unless you specifically create Virtual Server entries to forward those ports to a PC on your network. When your router needs to allow outside users to access internal servers, e.g.
  • Page 141 5.3.6.2 DMZ DMZ: The DMZ Host is a local computer exposed to the Internet. When setting a particular internal IP address as the DMZ Host, all incoming packets are checked by the Firewall and NAT algorithms, it is then passed to the DMZ host when a packet received does not use a port number in use by any other Virtual Server entries.
  • Page 142 5.3.6.3 ALG Controls enable or disable various protocols over application layer. For example, SIP ALG: Enable: When SIP phone need ALG to pass through the NAT. Disable: When SIP phone included NAT-Traversal algorithm. Turn off the SIP ALG. Using port mapping does have security implications, since outside users are able to connect to PCs on your network.
  • Page 143 5.3.7 Wake on LAN This feature provides greater flexibility for users to turn on / boot the computer of the network from a remotely site. MAC Address: Enter the MAC address of the target computer or you can select the MAC address directly from the Select drop down menu on the right.
  • Page 144 5.3.8 Time Schedule The Time Schedule supports up to 16 time slots which helps you to manage your Internet connection. In each time profile, you may schedule specific day(s) i.e. Monday through Sunday to restrict or allowing the usage of the Internet by users or applications. This Time Schedule correlates closely with router’s time, since router does not have a real time clock on board;...
  • Page 145 5.3.9 Advanced Configuration options within the Advanced section are for users who wish to take advantage of the more advanced features of the router. Users who do not understand the features should not attempt to reconfigure their router, unless advised to do so by support staff.
  • Page 146 5.3.9.1 Static Route Destination: The destination subnet IP address. Netmask: Subnet mask of the destination IP addresses based on above destination. Gateway: The gateway IP address to which packets are forwarded. Interface: Select the interface through which packets are forwarded. Cost: Represents the cost of transmission for routing purposes.
  • Page 147 Edit: Check the Edit radio button to display the parameter of the selected application, then after changing the parameters click the "Edit/Delete" button to apply the changes. Delete: To remove a static ARP entry, check the Delete box of the selected entry then click the "Edit/Delete"...
  • Page 148 Domain Name, Username and Password: Enter your registered domain name and your username and password for this service. Period: Set the time period between updates, for the Router to exchange information with the DDNS server. In addition to updating periodically as per your settings, the router will perform an update when your dynamic IP address changes.
  • Page 149 5.3.9.5 Device Management The Device Management advanced configuration settings allow you to control your router’s security options and device monitoring features. Embedded Web Server: HTTP Port: The port number of the router’s embedded web server (for web-based configuration uses. The default value is the standard HTTP port, 80. You may specify an alternative if, for example, you are running a web server on a PC within your LAN.
  • Page 150 Disable: Check to disable the router’s UPnP functionality. Enable: Check to enable the router’s UPnP functionality. UPnP Port: The Default setting is 2800. It is highly recommended you use this port value. If this value conflicts with other ports already in use you may wish to change the port. Installing UPnP in Windows Example Follow the steps below to install the UPnP in Windows Me.
  • Page 151 Step 3: In the Communications window, select the Universal Plug and Play check box in the Components selection box. Step 4: Click OK to go back to the Add/Remove Programs Properties window. Click Next. Step 5: Restart the computer when prompted. Follow the steps below to install the UPnP in Windows XP.
  • Page 152 Step 4: Select Networking Service in the Components selection box and click Details. Step 5: In the Networking Services window, select the Universal Plug and Play check box. Step 6: Click OK to go back to the Windows Optional Networking Component Wizard window and click Next.
  • Page 153 Auto-discover Your UPnP-enabled Network Device Step 1: Click start and Control Panel. Double-click Network Connections. An icon displays under Internet Gateway. Step 2: Right-click the icon and select Properties. Step 3: In the Internet Connection Properties window, click Settings to see the port mappings that were automatically created.
  • Page 154 Step 4: You may edit or delete the port mappings or click Add to manually add port mappings. Step 5: Select Show icon in notification area when connected option and click OK. An icon displays in the system tray Step 6: Double-click on the icon to display your current Internet connection status.
  • Page 155 Web Configurator Easy Access With UPnP, you can access web-based configuration for the BiPAC 7300NX/N RE without first finding out the IP address of the router. This helps if you do not know the router’s IP address. Follow the steps below to access web configuration. Step 1: Click Start and then Control Panel.
  • Page 156 5.3.9.6 IGMP IGMP, known as Internet Group Management Protocol, is used to management hosts from multicast group. IGMP Proxy: Accepting multicast packet. Default is set to Disable. IGMP Snooping: Allowing switched Ethernet / Wireless to check and make correct forwarding decisions. Default is set to Disable. 5.3.9.7 SNMP Access Control Software on a PC within the LAN is required in order to utilize this function –...
  • Page 157 view and modify the data. Trap Community: Specify a name to be identified as the Trap Community, and an IP address. This community string will be checked against the string entered in the configuration file. Once the string name is matched, users from this IP address will be sent SNMP Traps.
  • Page 158 From RFC1650 (EtherLike-MIB): dot3Stats From RFC 1493 (Bridge MIB): dot1dBase group dot1dTp group dot1dStp group (if configured as spanning tree) From RFC 1471 (PPP/LCP MIB): pppLink group pppLqr group From RFC 1472 (PPP/Security MIB): PPP Security Group) From RFC 1473 (PPP/IP MIB): PPP IP Group From RFC 1474 (PPP/Bridge MIB): PPP Bridge Group...
  • Page 159 5.3.9.8 TR-069 client TR-069 (short for Technical Report 069) is a DSL Forum (which was later renamed as Broadband Forum) technical specification entitled CPE WAN Management Protocol (CWMP). It defines an application layer protocol for remote management of end-user devices. As a bidirectional SOAP/HTTP based protocol it can provides the communication between customer premises equipment (CPE) and Auto Configuration Server (ACS).
  • Page 160 5.3.9.9 Remote Access Remote Access Control: Enable: Select Enable to allow management access from remote side (mostly from internet). Duration: Set how many minutes to allow management access from remote side. Zero means always on. Allowed Access IP Address Range: Valid: Select Valid to allow remote management from these IP ranges.
  • Page 161 5.4 Save Configuration to Flash After changing the router’s configuration settings, you must save all of the configuration parameters to FLASH to avoid losing them after turning off or resetting your router. Click “Save Config“ and click “Apply” to write your new configuration to FLASH. 5.5 Restart Click Restart with option Current Settings to reboot your router (and restore your last saved configuration).
  • Page 162 5.6 Logout To exit the router’s web interface, choose Logout. Please ensure that you have saved the configuration settings before you logout. Be aware that the router is restricted to only one PC accessing the configuration web pages at a time. Once a PC has logged into the web interface, other PCs cannot get access until the current PC has logged out of the web interface.
  • Page 163 Chapter 6 Troubleshooting If your ADSL Router is not functioning properly, you can refer first to this chapter for simple troubleshooting before contacting your service provider support. This can save you time and effort but if symptoms persist, consult your service provider. Problems starting up the router Problem Corrective Action...
  • Page 164 Frequent loss Ensure that all other devices connected to the same telephone ADSL linesync line as your router (e.g. telephones, fax machines, analogue (disconnections). modems) have a line filter connected between them and the wall socket (unless you are using a Central Splitter or Central Filter installed by a qualified and licensed electrician), and ensure that all line filters are correctly installed and the right way around.
  • Page 165 Most problems can be solved by referring to the Troubleshooting section in the User’s Manual. If you cannot resolve the problem with the Troubleshooting chapter, please contact the dealer where you purchased this product. Contact Billion WORLDWIDE http://www.billion.com MAC OS is a registered Trademark of Apple Computer, Inc.
