Introduction

This meter has been designed and tested
according to IEC 1010-1, Safety Requirements
for Electrical Equipment for Measurements,
Control, and Laboratory Use. This manual
contains information and warnings which must be
followed to ensure safe operation and retain the
meter in safe condition. If the meter is not used
as described in this manual, the safety features
of the meter might be impaired.
Read "Multimeter Safety" before using the
meter.
The Fluke 87 True RMS Multimeter (also referred to as
"the meter") is a handheld, 4000-count instrument that is
designed for use in the field, laboratory, and at home. The
meter combines the precision of a digital meter with the
speed and versatility of a high resolution analog display.
Frequencies between 0.5 Hz and 200 kHz can be
measured with up to 0.01 Hz resolution. The meter is
powered by a 9V battery and has a rugged case sealed
against dirt, dust, and moisture. A snap-on holster, with
Note
Warning
flexible stand (Flex-Stand ), protects the meter from
rough handling. The flexible stand allows the meter to be
stood or hung.
The meter also provides:
A MIN MAX Recording mode, in which the meter
"remembers" the lowest and highest readings,
calculates the true average of all readings taken over
a period as long as thirty-six hours, and displays
these values. The beeper emits a Min Max Alert
when a new minimum or maximum reading is
recorded.
A Peak MIN MAX mode that captures changes as
short as 1 millisecond.
An alternate Frequency Counter mode that measures
duty cycle and displays it as a value between 0.1 and
99.9%.
An Input Alert that causes the beeper to sound if the
test leads are plugged into the wrong input terminals
for the function being performed.
A REL mode that allows you to store a reading in
memory, and display the difference between the
stored value and subsequent readings.
1
