Fluke 83V Specifications

80 Series V Industrial
True-RMS Multimeter
with Temperature

Specifications

Function Range and resolution
DC Volts 600.0 mV, 6.000 V, 60.00 V,
600.0 V, 1000 V
AC Volts 600.0 mV, 6.000 V, 60.00 V,
600.0 V, 1000 V
DC Current 600.0 µA, 6000 µA, 60.00 mA,
600.O mA, 6.000 A, 10.00 A
AC Current 600.0 µA, 6000 µA, 60.00 mA,
600.O mA, 6.000 A, 10.00 A
Temperature -200 to 1090 °C (-328 to 1994 °F)
(excl. probe)
80BK Temperature -40 to 260 °C (-40 to 500 °F)
Probe
600.0 W, 6.000 kW, 60.00 kW,
Resistance
600.0 kW, 6.000 MW, 50.00 MW
Capacitance 10.00 nF, 100.0 nF, 1.000 µF,
10.00 µF, 100.0 µF, 9,999 µF
Frequency 199.99 Hz, 1.9999 kHz,
19.999 kHz, 199.99 kHz
Accuracy and diagnostic functions for
maximum industrial productivity
The new Fluke 87V has improved measurement functions, trouble-
shooting features, resolution and accuracy to solve more problems
on motor drives, in plant automation, power distribution, and electro-
mechanical equipment. The 87V operates very similar to the classic
87, but with more problem-solving power, safety, convenience and
impact protection.
Features for maximum productivity
•
Unique function for accurate voltage and frequency measurements
on adjustable speed motor drives and other electrically noisy
equipment (87V)
•
Built-in thermometer conveniently allows you to take temperature
readings without having to carry a separate instrument (87V)
•
Large digit display with bright, two-level backlight makes the
80 Series V significantly easier to read than older models
NEW! 87V/E2 Industrial Electrician Combo Kit makes troubleshooting
more productive with standard meter hanging accessory for hands-
free operation, soft case for protection and storage, 1.5 m
heat resistant silicone test leads and more.
Electrical safety
All inputs are protected to Category III, 1000 V and Category IV
600 V. They can withstand impulses in excess of 8,000 V and
reduce risks related to surges and spikes.
1000 V CAT III
600 V CAT IV
Basic accuracy
83V 87V
0.1 % 0.05 %
0.5 % 0.7 %
(True-rms)
0.4 % 0.2 %
1.2 % 1.0 %
(True-rms)
— 1.0 %
— 2.2 °C
or 2 %
0.4 % 0.2 %
1.0 % 1.0 %
0.005 % 0.005 %
N10140
