Fluke 1.4 MPA PPC4E Instruction Sheet

14 MPa and 1.4 MPa PPC4E Demo Kits
P/N 3934699 and P/N 3934702
Instruction Sheet
14 MPa Demo kit (P/N 3934699) contents:
DESCRIPTION
Demo Kit Transit Case
PPC4 Transit Case
SPLT, self purging liquid trap, for PPC
2000 psi digital pressure gauge
30 psi analog pressure gauge
Cable assembly, DB9M x F
36 in. test hose assembly, 2500 psi
72 in. supply hose assembly, 2500 psi
Swivel adaptor, 1/4 in x 1/8 in.
NPT female
Reducer, 1/4 in. to 1/8 in. NPT
Adaptor, 1/4 in. NPT male x 1/4 in. tube
Elbow, 1/4 in. tube
The 14 MPa PPC4E demo kit includes UUT (unit
under test) pressure gauges with ranges selected for
use with PPC4EX 14M pressure controller/calibrator.
QTY PART NO.
1 3984452
1 3338097
1 3069823
1 3984160
1 3984201
1 2758335
1 3984857
1 3984869
1 3984825
1 1811842
1 3863458
1 3867817
Figure 1: 14 MPa PPC4E Demo Kit Assembly
The demo kit connections and gauges should be
installed with the controller/calibrator and pressure
supply as illustrated below.
Pneumatic connections that will be frequently
disconnected are o-ring type quick connectors which
can be connected without thread tape, sealant or
tools. The traditional pipe thread and tube fittings in
the kit can remain connected during transport, so that
all of the connections required for a demonstration
can be quickly connected by hand. Separate adaptors
may be needed to connect to local pressure supply.
 Warning
Flexible pressure hoses in this kit have
maximum operating pressure of 17 MPa
(2500 psi).
