- Page 1 Type 0460 Operating Instructions for all variants...
- Page 2 We reserve the right to make technical changes without notice. © Bürkert Werke GmbH & Co. KG 2025 Technical documentation 2507/00_GBen_60040561_921258635_18014399430777739 / Original DE...
- Page 3 Type 0460 Table of contents Table of contents About this document 4 Document validity 4 Manufacturer 4 Symbols 4 Terms and abbreviations 6 2 Safety 7 Intended use 7 Safety instructions 7 3 Product description 10 Product structure 10 Product identification 10...
- Page 4 Type 0460 About this document About this document The document is an important part of the product and guides the user to safe installation and operation. The information and instructions in this document are binding for the use of the product.
- Page 5 Type 0460 About this document Indicates important additional information, tips and recommendations. Refers to information in this document or in other documents. ▶ Indicates a step to be carried out. Indicates a result. Menu Indicates a software user-interface text. 5 | 19...
- Page 6 Type 0460 About this document Terms and abbreviations The terms and abbreviations are used in this document to refer to following definitions. Device 5/2- pulse valve or 5/3-pneumatic valve Unit for relative pressure 6 | 19...
- Page 7 Type 0460 Safety Safety Intended use The device is designed to control the flow of media. The permissible media are listed in chapterTechnical data [} 12] Prerequisites for safe and trouble-free operation are proper transport, storage, installation, commissioning, operation and maintenance.
- Page 8 Type 0460 Safety ▶ Observe the operating instructions of the device or component used. ▶ Only use the devices in conjunction with approved devices or components. Spare parts and accessories that do not meet Bürkert’s requirements may impair the operational safety of the device and cause accidents.
- Page 9 Type 0460 Safety ▶ Ensure that the device or system cannot be switched on unintentionally. ▶ Only start the process in a controlled manner following disruptions. Observe sequence: 1. Apply supply voltage or pneumatic supply. 2. Charge the device with medium.
- Page 10 Type 0460 Product description Product description Product structure Fig. 1: Example: 5/2-way pulse valve, Type 0460 1 Electrical connection 2 5/2-way pulse valve / 5/3-way pneumatic valve 3 Manual override 3 Manual override Product identification 3.2.1 Type label Fig. 2: Type label 0460 (example)
- Page 11 Type 0460 Product description Circuit function Icon Description Circuit function L (CF L) 5/3-way solenoid valve, with manual override 5 1 3 All connections blocked in the central position Circuit function N (CF N) 5/3-way solenoid valve, with manual override...
- Page 12 Type 0460 Technical data Technical data Standards and directives This product complies with the legal requirements applicable at the time of placing on the market and has been developed and tested in accordance with the relevant European directives/regulations and harmonized standards. The conformity is documented and, if necessary, supported by evidence. The EU Declaration of Conformity can be found behind the respective type on the home page country.burkert.com...
- Page 13 Type 0460 Installation Installation Risk of injury or material damage when working on the device or system. ▶ Read and observe the chapter Safety [} 7] before working on the device or system. Preparatory work ▶ Fit a dirt trap on a dirty medium before the valve inlet (5 µm).
- Page 14 Type 0460 Installation Manual override PUSH LOCK LOCK PUSH Fig. 4: Manual override 1 A – Manual override for port 2 (A) 2 B – Manual override for port 4 (B) NOTICE! If both manual overrides are actuated simultaneously, the valve remains in a switched state. Make sure that the manual override lock is released to prevent malfunctions.
- Page 15 Type 0460 Medium port Medium port Risk of injury or material damage when working on the device or system. ▶ Read and observe the chapter Safety [} 7] before working on the device or system. X* – pilot exhaust air Fig. 5: Medium port...
- Page 16 Fig. 6: Electrical connection 1 Rectangular plug 2 Pole coil 12 controlled via bit “n+1” 3 Common pole 4 Pole coil 14 controlled via bit “n” Pin assignment Rectangular plug Tab. 3: Pin assignment 0460 16 | 19...
- Page 17 Type 0460 Start-up Start-up Risk of injury or material damage when working on the device or system. ▶ Read and observe the chapter Safety [} 7] before working on the device or system. ▶ Switch on the compressed air supply. ▶ Switch on the power supply.
- Page 18 Type 0460 Faults Faults Risk of injury or material damage when working on the device or system. ▶ Read and observe the chapter Safety [} 7] before working on the device or system. If faults occur, check whether • the device has been installed according to regulations •...
- Page 19 Type 0460 Logistics Logistics 10.1 Transport and storage ▶ Protect the device against moisture and dirt in the original packaging during transportation and storage. ▶ Avoid UV radiation and direct sunlight. ▶ Protect connections from damage with protective caps. ▶ Observe permitted storage temperature.
