Summary of Contents for FujiFilm Revoria Press EC2100S
- Page 1 Reference Guide Optional Units Revoria Press SC285S Revoria Press SC285 Revoria Press EC2100S Revoira Press EC2100 December 2024 GM1966E5-1 Edition1 FUJIFILM Business Innovation Corp.
-
Page 2: Table Of Contents
Contents High Capacity Feeder B1 Loading Paper;Paper Jams High Capacity Feeder B1-S/C3-DS/C1-DS Loading Paper;Paper Jams;Cleaning Machine Air Suction Feeder C1-DS/C1-DSXL Loading Paper Interface Decurler Module D1 Curl Correction;Paper Jams Inserter D1 Loading Paper;Paper Jams Static Eliminator D1 Setting Voltage;Paper Jams High Capacity Stacker A1 Outputting Paper;Paper Jams Crease / Two-Sided Trimmer D2... - Page 3 - Offset catch tray, Long catch tray: “Reference Guide- Main Unit” - Print / scan function-related products (Revoria Press SC285S/SC285) : “Reference Guide - Operations” - Print function-related products (Revoria Press EC2100S/EC2100) : “Reference Guide - Operations” - Print server and related products: Manual included in the product •...
-
Page 4: High Capacity Feeder B1
High Capacity Feeder B1 High Capacity Feeder Tray B1 can be used with Revoria PressSC285S/SC285. Device Components Component Function Remaining Volume Display You can check the remaining paper volume. High Capacity Tray (Paper Tray 6) Load paper here. Top Cover Open this cover to clear paper jams. -
Page 5: Loading Paper
Loading Paper After loading paper, configure the Paper Tray settings on the Home screen. Refer For details, refer to “Setup” in “Reference Guide - Operations”. Images are printed on the face side of the loaded paper. Pull out the Paper Tray toward you until it stops. Remove any paper remaining in the Paper Tray. - Page 6 Insert the protrusions under the guide into the Paper Size holes. Insert the Paper Tray protrusions into the Paper Size holes on top of the guide and tighten the screw. Pull the handle for the end guide up ( 1 ), align with the Paper Size while moving the handle along the groove ( 2 ), and lower the handle ( 3 ).
-
Page 7: Paper Jams
Paper Jams If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine. - Page 8 Inside of the Upper Cover Hold the handle and move the unit all the way to the left. Pull the handle ( ) and open the cover ( Remove the jammed paper. Close the cover. Move the unit to the right and connect it with the main unit.
-
Page 9: High Capacity Feeder B1-S/C3-Ds/C1-Ds
High Capacity Feeder B1-S/C3-DS/C1-DS High Capacity Feeder Tray B1-S can be used with Revoria Press SC285S/SC285. Device Components / Caution Labels B1-S (Revoria Press SC285S/SC285 only) C3-DS/C1-DS High Capacity Feeder B1-S/C3-DS/C1-DS... -
Page 10: Ground Fault Interrupter
Component Function Bypass Tray (Paper Tray 5) Load paper here. Error Indicator When paper jam occurs, the indicator is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. Right Cover Open this cover to clear paper jams. Remaining Volume Indicator When the Paper Tray is in operation, the top lamp is turned on. - Page 11 190 (Including a bypass tray for long paper and a large operation panel) C3-DS Revoria Press SC285S/SC285: 236 (Including a bypass tray for long paper and a large operation panel) Revoria Press EC2100S/EC2100: 232 (Including a bypass tray for long paper) C1-DS High Capacity Feeder B1-S/C3-DS/C1-DS...
- Page 12 Loading Paper After loading paper, configure the Paper Tray settings on the Home screen. Refer For details, refer to “Setup” in “Reference Guide - Operations”. Loading to High Capacity Tray Images are printed on the face side of the loaded paper. Important ...
- Page 13 Note Make sure that Paper Feed Precision Lever is set to the Normal position. If printed image is still skewed (mis- alignment of image on prints) after you load paper in Paper Tray correctly, enable switching of paper feed precision. Refer ...
-
Page 14: Loading Envelopes
Load remaining sheets with the printed side facing up, and align the paper edges in the direction of the arrow ( Adjust the short-side paper guide to the correct pa- per size ( To leave a space, pinch the paper guide grip to move. To narrow, push the paper guide to move. - Page 15 Important Do not load too many sheets on the envelope. It may cause the envelope to tilt and the machine to malfunction. Note • If envelopes are loaded with the flaps unfolded, the size will not be automatically detected as standard size. •...
- Page 16 If the accuracy of paper feeding is not improved even if 2 is performed, move the lever at the right front to the rearmost position (<I> position) to enable the changing. Note To reset the setting, move the lever to the foremost position. Push in the Paper Tray.
- Page 17 Flexible Type (for Long Paper) Loosen the 4 screws of the paper guide. Hold the center of the paper guide and adjust it to the size of loaded paper. Fan the paper well and insert it along the paper guide all the way until it touches the back, with the printed side facing up.
- Page 18 Paper Jams Note The error indicator at the top of the machine is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper.
- Page 19 ■When Indicator E6 is Turned on (B1-S), when Indicator E7 is Turned on (C3-DS/ C1-DS) Pull out the Paper Tray 6 (or 7, or 9) toward you until it stops. Note Confirm that no paper is jammed inside the Right Cover before pulling it out. Remove the jammed paper.
- Page 20 ■When Indicator E3 is Turned on Open lever [1b] to the right ( 1 ), turn knob [1c] clock- wise ( 2 ), and remove the jammed paper ( 3 ). Return lever [1b]. ■When Indicator E4 is Turned on Open lever [1a] to the right ( 1 ), turn knob [1c] clock- wise ( 2 ), and remove the jammed paper ( 3 ).
-
Page 21: Inside The Right Side Cover
Inside the Right Side Cover (Left side at continuous feed configu- ration) Open the Right Cover. Remove the jammed paper. When Indicator E1 is Turned on ....................p.21 When Indicator E2 is Turned on ....................p.21 When Indicator E3 is Turned on ....................p.22 When Indicator E4 is Turned on ....................p.22 ■When Indicator E1 is Turned on Open lever [1a] to the right ( 1 ), turn knob [1c] counter-... - Page 22 ■When Indicator E3 is Turned on Open lever [1b] to the right ( 1 ), turn knob [1c] counter- clockwise ( 2 ), and remove the jammed paper ( 3 ). Return lever [1b]. ■When Indicator E4 is Turned on Open lever [1d] downward ( 1 ) and turn knob [1c] counterclockwise ( 2 ).
- Page 23 Paper Feeding Unit (Right side at continuous feed configuration) ■When Indicator E5 is Turned on Pull out the top cover toward you until it stops. Note Before pulling out the Tray, make sure no paper is jammed inside the right side cover. Open lever [2a] to the right ( 1 ) and lever [2b] upward ( 2 ), and remove jammed papers ( 3 ).
-
Page 24: Cleaning Inside The Machine
Cleaning Machine • When you clean machine products, use the cleaning materials designated in every step. • To wipe with a wet cloth, use the soft cloth tightly wrung out of water. If the parts are not com- pletely dry, the machine may malfunction. •... - Page 25 Wipe the surface of roller 1 with the soft cloth tightly wrung out of water. Reinstall roller 1. Note Make sure that roller 1 is installed in the holder completely. Remove roller 2 by picking up the both ends of its pin. Wipe the surface of roller 2.
- Page 26 Cleaning the Paper Feeding Unit in the High Capacity Tray Note • Do not press a roller during the cleaning, otherwise the roller may drop off. • Non-woven dry type fabric can be used effectively for cleaning paper dust. Open the Right Cover. Open lever [1a] to the right.
- Page 27 Open lever [1d] upward. Clean behind lever [1d]. Wipe the roller surface with the soft cloth tightly wrung out of water. Lightly wipe paper dust off on the surface of the paper path. Return lever [1d]. Paper path surface Roller Close the cover.
-
Page 28: Air Suction Feeder C1-Ds/C1-Dsxl
Air Suction Feeder C1-DS/C1-DSXL Device Components / Caution Labels Component Function Bypass Tray (Tray 5) Load paper here. Error Indicator When paper jam occurs, the indicator is turned on. When the priority device indicator (top lamp) blinks, first of all erform the pa- per jam operation. -
Page 29: Ground Fault Interrupter
Ground Fault Interrupter When not using for an extended period or when moving Switch the unit, set the switch to the lower position to turn the machine power off. Note Do not operate the switch under normal circumstances because it is turned off when a current leakage is detected. -
Page 30: Loading Paper
Note Revoria Press SC285S/SC285: Including the weight of the Bypass Tray for Long Paper and the large operation panel. Revoria Press EC2100S/EC2100: Including the weight of the Bypass Tray for Long Paper. Loading Paper Important Do not load paper above the maximum fill line. It may cause paper jams or machine malfunctions. - Page 31 Loosen the screw ( ) of the bracket. Note The screw does not need to be removed. Fan the paper well and load about 100 - 500 sheets with the printed side facing up, and the paper edges aligned in the direction of the arrow ( Hold the long-side paper guide by its grip and move it to lightly contact the paper edges ( Load remaining sheets with the printed side facing...
- Page 32 Loosen the screw ( ) of the bracket. Note The screw does not need to be removed. Remove the shutters Fold the shutters. Hold the shutters up and remove them. Insert the guide A into the slit on your side ( ) and the slit on the bottom ( ), and then tighten the...
- Page 33 Load remaining sheets with the printed side facing up, and align the paper edges in the direction of the arrow ( Move the short-side paper guide to lightly contact the paper edges ( To leave a space, hold the paper guide by its grip to move. To narrow, push the paper guide to move.
- Page 34 Loading Envelopes ■Before load Check the envelopes. • Are not the envelopes curled or their edges waved? If there are envelopes strongly curl or edges waving, replace the envelopes or reform them to improve. • Are not the envelopes adhered to each other? If applicable, remove glue and the overlap of bonding parts.
- Page 35 Envelope Size Postcard Kit* Envelope Kit Other than the above sizes (portrait: 181.9 mm or less) Other than the above sizes (portrait: 182.0 mm or more) * When attach Postcard Kit (A and B), remove shutters. ■Envelope Kit Fasten the screws to the long-side paper guide on the back side to fix C.
- Page 36 ■For Using Envelope Kit Load one envelope with the printed side facing up, align the paper edges in the direction of the arrow to put it on E and F ( 1 ), and move the short-side paper guide to lightly contact the paper edges ( 2 ).
- Page 37 ■For not using Envelope Kit Load bundle of about 100 sheets with the printed side facing up, and the paper edges aligned in the direction of the arrow ( 1 ). Hold the long-side paper guide by its grip and move it to lightly contact the paper edges ( 2 ).
- Page 38 Note • Paper level indicator lamp is not correctly displayed. • If the paper empty indicator lamp when you load only the small number of envelopes, load more envelopes. ■Paper Settings • Paper Type: Uncoated • Paper Weight: two times of the indicated weight (140 g/m if 70 g/m is indicated) •...
- Page 39 If the short-side paper guide is stored, pull the short-side guide up. Open the shutter while pinching the lever. Hold the paper guide and pull it up.Pull the paper guide until it clicks to be fixed. Close the shutter while pinching the lever. Important ...
- Page 40 If the short-side paper guide is standing, store it. Open the shutter while pinching the lever. Lay the paper guide down while holding the release lever. Close the shutter while pinching the lever. Load about 100 sheets of paper with the printed side facing up, and align the paper edges in the di- rection of the arrow ( Hold the right side long-side paper guide by its grip...
- Page 41 864.1 mm or Larger Paper Up to 100 sheets (90 g/m paper) can be loaded. Unfasten the screws and remove the left side cover. Remove the paper loaded on the Bypass Tray. Open two covers. Attach the extension tray and the supporting plate. Insert the extension tray and tighten the screws to fix.
- Page 42 Turn the lever on the left of the long-side paper guide upward. Remove any paper remaining in the Tray. If the short-side paper guide is standing, store it. Open the shutter while pinching the lever. Lay the paper guide down while holding the release lever. Close the shutter while pinching the lever.
-
Page 43: Interface Decurler Module D1
Interface Decurler Module D1 Device Components Component Function Error Indicator When paper jam occurs, the indicator is turned on. When the indicator blinks, first of all perform the paper jam operation. Curl correction button Press the button to correct paper curl. This curl correction function can be used during printing. - Page 44 Curl Correction The curl correction button is used to correct paper curl caused by heat and/or pressure. The curl correction button can be operated regardless of the machine state when the machine is Note • This curl correction function can be used during printing. Fine correction according to the paper properties can be made from control panel.
- Page 45 Operations and Functions of Curl Correction Press the AUTO button to enter the [AUTO] mode. Indicator Mode Function AUTO Curl correction is automatically performed. It is recommended to use this mode basically. Optimum curl correction is per- formed according to the paper size and output direction.
-
Page 46: Paper Jams
Paper Jams Note The error indicator at the top of the machine is turned on. When the indicator blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper. -
Page 47: Inserter D1
Inserter D1 Device Components Component Function Error Indicator When paper jam occurs, the indicator is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. Curl correction button Use this button when curl cannot be corrected even if the highest correction (or lowest correction) of Interface Decurler Module is performed. - Page 48 Main Specifications Item Specification Paper size Standard size A3, 11 x 17" Note Can be used by inputting the size. Custom size (mm) Width 182 to 330 Length 148 to 488 Paper weight (g/m 52 to 350 Note If Saddle stitch / Single fold is used for the following papers, folding displacement and/or paper wrinkles occur.
- Page 49 Loading Paper Load paper (blank paper or printed paper) to be used as an interleaf or cover. Inserter Tray is used to load paper used as an interleaf or cover, and print cannot be performed. Note • After removing all the paper from the Tray, and then load the paper again together with the paper you want to add.
- Page 50 Paper Jams Note The error indicator at the top of the machine is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper.
- Page 51 If you have difficulty in removing the papers, open lever [1c] to the right ( 1 ), turn knob [1b] counterclockwise ( 2 ), and remove the jammed paper ( 3 ). Return lever [1c]. Close the cover. ■When Indicator E3 is Turned on Open the Cover.
-
Page 52: Static Eliminator D1
Static Eliminator D1 Device Components Component Function Error Indicator When paper jam occurs, the indicator is turned on. When the indicator blinks, first of all perform the paper jam operation. Applied voltage count Set applied voltage according to the media to feed. Set “00”... -
Page 53: Setting Voltage
Setting Voltage Enter a value according to the media to use. Humidity Media Standard value Upper limit to 90 Low humidity (15% or less) Surface layer: Resin to 99 Inner layer: Paper to 70 Normal humidity (16 to 55%) Surface layer: Resin to 99 Inner layer: Paper to 60... - Page 54 Paper Jams Note The error indicator at the top of the machine is turned on. When the indicator blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper.
-
Page 55: High Capacity Stacker A1
• The High Capacity Stacker can be only attached to the Interface Decurler Module. • The 2nd High Capacity Stacker can be installed on "Revoria Press EC2100S/EC2100" only. • The installed first and second High Capacity Stackers are the same one. (Revoria Press EC2100S/EC2100" only) - Page 56 Ground Fault Interrupter When not using for an extended period or when moving the unit, set the switch to the lower position to turn the Switch machine power off. Note Do not operate the switch under normal circumstances because it is turned off when a current leakage is detected.
-
Page 57: Outputting Paper
Item Specification Weight (kg) 155 + 2 (Banner Print Extension Kit)+4 (with Transport Module) Note Includes weight of the Stacker cart. Outputting Paper Top Output Tray Banner Print Extension Kit Long paper can be loaded without its lead edge sticking out. Paper size (mm) Tray capacity (sheets) Width: 210 to 330... - Page 58 Install the wires on the U-shaped bar. Note As holding the U-shaped bar with a hand, insert the fixing devices firmly, and check that the wires will not come off from the U-shaped bar. Adjust the wire positions according to the size of paper to be output.
- Page 59 Paper Jams Note The error indicator at the top of the machine is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper.
-
Page 60: When Indicator E4 Is Turned On
■When Indicator E3 is Turned on Open the front upper cover. Open lever [1b] upward ( 1 ), turn knob [1a] counter- clockwise ( 2 ), and remove the jammed paper ( 3 ). Return lever [1b]. Open lever [2b] upward ( 1 ), turn knob [2c] counter- clockwise ( 2 ), and remove the jammed paper ( 3 ). -
Page 61: When Indicator E6 Is Turned On
■When Indicator E6 is Turned on Press the paper eject button. When lock is released, open the front lower cover. Pull out the stacker cart slowly and remove the jammed paper. Return the stacker cart slowly. Close the cover. ■When Indicator E7 is Turned on Remove the jammed paper that sticks out from the exit of the Top Output Tray. -
Page 62: When Indicator E8 Is Turned On
■When Indicator E8 is Turned on Open the front upper cover. Open lever [3b] upward ( 1 ), turn knob [3a] clockwise ( 2 ), and remove the jammed paper ( 3 ). Return lever [3b]. Close the cover. Check the curl direction of the jammed paper and correct the curl. Refer ... -
Page 63: Crease / Two-Sided Trimmer D2
Crease / Two-Sided Trimmer D2 Device Components / Caution Labels 28279 Component Function Error Indicator When paper jam occurs, the indicator is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. Waste full indicator When cut pieces need to be disposed, the indicator is turned on. - Page 64 Main Specifications Item Specification Two-sided Trim Paper size Standard size A3, 11 x 17" A4, Letter (8.5 x 11") Custom size Width 194 to 330 (mm) Length 210 to 488 Paper weight (g/m Uncoated 52 to 350 Coated 64 to 350 Cutting requirement 6 to 25 (mm)
- Page 65 Cutting and Crease Area 210 to 488 mm 386 mm or less (trim and crease) 194 to 330 mm (trim) Trim 182 to 330 mm (crease) Feed direction a: 12 mm or more A=B: 6 to 25 mm b - e: 25 mm or more Crease Printing is not possible when less than 45 mm from the front edge.
-
Page 66: Waste Container
Waste Container When cut pieces need to be disposed, the waste full indicator is turned on. When it is turned on, dispose cut pieces. Note • Cut pieces can be disposed even during printing. • When cut pieces in the waste container become full, the waste full indicator changes from ON to blinking. Open the lower cover. - Page 67 Paper Jams Note The error indicator at the top of the machine is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper.
-
Page 68: When Indicator E2 Is Turned On
■When Indicator E2 is Turned on Turn knob [2] counterclockwise and align the marks. Open lever [1a] downward ( 1 ) and open lever [1b] downward ( 2 ). Turn knob [1c] clockwise ( 1 ) and remove the jammed paper ( 2 ). -
Page 69: When Indicator E3 Is Turned On
■When Indicator E3 is Turned on Turn knob [2] counterclockwise and align it with the mark position. Open lever [2c] downward ( 1 ) and remove the jammed paper ( 2 ). Note Jammed paper may be hidden at the upper section. Return lever [2c]. -
Page 70: When Indicator E5 Is Turned On
■When Indicator E5 is Turned on Open lever [3a] to the right ( 1 ) and open lever [3b] to the left ( 2 ). Turn knob [3c] clockwise ( 1 ) and remove the jammed paper ( 2 ). Turn knob [2f] counterclockwise ( 1 ) and remove the jammed paper ( 2 ). -
Page 71: When Indicator E7 Is Turned On
Open lever [4a] to the right ( 1 ), turn knob [2f] counter- clockwise ( 2 ), and remove the jammed paper ( 3 ). Note As holding the lever [4a] with a hand, turn knob [2f] and remove the paper. Turn knob [3c] clockwise ( 1 ) and remove the jammed paper ( 2 ). - Page 72 Open lever [3a] to the right ( 1 ) and open lever [3d] to the right ( 2 ). Collect cut pieces around the trimmer unit in the waste container using the waste collecting bar. If cut pieces cannot be collected in the waste container, move them by the waste collecting bar and remove them with hands.
-
Page 73: Folder Unit Cd2/Cd3
Folder Unit CD2/CD3 Folder Unit CD3 can be used with Revoria Press SC285S/SC285. Device Components / Caution Labels Bottom Component Function Tri-Fold Output Tray Button Press the button to remove paper from the Tri-Fold Output Tray. The Tri-Fold Output Tray is opened when the lamp stops blinking and comes on and the lock is released. - Page 74 Paper Jams Note On CD2, the error indicator at the top of the Finisher is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper.
- Page 75 ■When Indicator E11 is Turned on Open lever [2g] to the right ( 1 ), turn knob [2c] counter- clockwise ( 2 ), and remove the jammed paper ( 3 ). Return lever [2g]. ■When Indicator E12 is Turned on Pull out the Tri-Fold Output Tray [2d].
-
Page 76: Finisher C
Finisher C Finisher C can be used with Revoria Press SC285S/SC285. In this guide, “Finisher C5” and “Finisher C5 with Booklet Maker” are generally referred to as “Finisher C”. Device Components / Caution Labels Component Function Transport unit V Front Cover Open this cover to clear paper jams. - Page 77 Main Specifications Item Specification Type Top Output Tray Sort (Offset available) / Stack (Offset available) Finisher Tray Sort (Offset available) / Stack (Offset available) Booklet Tray Sort / Stack Paper size Top Output Tray Standard A3, 11 x 17" size Custom size Width 90 to 330...
- Page 78 Item Specification Staple Maximum number 50 (90 g/m or less) With staples of sheets of paper (sheets) Note Up to 65 sheets are possible if Staple Unit 65 Sheets is installed. However, the paper may shift or not be stapled correctly, depending on the paper type.
- Page 79 Item Specification Saddle stitch / Maximum number Saddle stitch 20 (90 g/m or less) Single fold of sheets of paper Single fold 5 (90 g/m or less) (sheets) Note The number of sheets varies depending on the grammage used. Depending on the paper size and paper type, the booklet may distend.
-
Page 80: Replacing Staple Cartridge
Staple Cartridge Replacing Staple Cartridge Consumables recommended by our company are manufactured under the standards suitable for this machine. Using consumables not recommended by our company may affect print quality or performance provided by the product. Use consumables that our company recommends for this machine. - Page 81 Pinch both sides of the empty staple case ( ) and remove it from the cartridge ( Important If there are still staples in the staple case, you cannot remove the staple case. Forcefully removing the staple case may cause mal- function.
- Page 82 Pinch both sides of the empty staple case ( ) and remove it from the cartridge ( Important If there are still staples in the staple case, you cannot remove the staple case. Forcefully removing the staple case may cause mal- function.
-
Page 83: Staple Jams
Staple Jams If paper is not being stapled or if staples are bent, follow the procedures mentioned in the follow- ing pages. If the issue isn't resolved even after the procedure, contact your local representative. Paper is not stapled Staple is bent If the staple looks like any of the following images, contact your local representative. - Page 84 Staple Cartridge for Side Stitch Tap [Device Status] > [Supplies] > [Staple Cartridge R1] > [Check] on the Touch Panel Display. Confirm that the machine is not operating, and open the Cover. Hold the handle and remove the Staple Cartridge. When using the Staple Unit 65 Sheets, flip the handle down and remove the Staple Cartridge.
- Page 85 Staple Cartridges for Saddle Stitch Confirm that the machine is not operating, and open the Cover. Pull out Booklet Maker [4]. Hold the handle of the Staple Cartridge (R2) (R3) and pull it out. Remove the jammed staples. Insert the Staple Cartridge into the original position. Hold the handle and lightly press it up until you hear a click.
-
Page 86: Transport Unit
Paper Jams If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine. -
Page 87: Booklet Tray
■Booklet Tray Open the Cover. Remove the jammed paper that sticks out from the exit of the Tray to the right direction. If you have difficulty in removing the papers, turn knob [4a] clockwise ( 1 ), and remove the jammed paper that sticks out from the exit of the Tray ( 2 ). - Page 88 ■Lever [3d] Open lever [3d] to the right ( 1 ) and remove the jammed paper( 2 ). Return lever [3d]. ■Booklet Marker Pull out Booklet Maker [4]. Turn knob [4a] counterclockwise ( 1 ) and remove the jammed paper( 2 ). Push in the Booklet Maker [4].
-
Page 89: Finisher D
Finisher D In this guide, “Finisher D6” and “Finisher D6 with Booklet Maker” are generally referred to as “Finisher D”. Device Components / Caution Labels Component Function Hole Punch Waste Container Punched pieces go in here. Refer For the discard method of waste in the waste container, refer to the label affixed on the machine. -
Page 90: Main Specifications
Component Function Booklet Tray Saddle stitch and Single fold paper is ejected. Note When the Square Back Fold Trimmer is equipped, it is installed to the Square Back Fold Trimmer. Cover Open this cover to clear paper jams, replace the Staple Cartridge, remove jammed staples or dispose of cut pieces for punched holes. - Page 91 Revoria Press EC2100S/EC2100: JIS B5 Custom size Width 182 to 297 (mm) Length Revoria Press SC285S/SC285: 146 to 432 Revoria Press EC2100S/EC2100: 148 to 432 Paper weight (g/m Uncoated 52 to 350 Coated 72 to 300 Stapled location 1 location, 2 locations, 4 locations Note ...
- Page 92 Item Specification Saddle stitch / Maximum number Saddle stitch 30 (90g/m or less) Single fold of sheets of paper Single fold 5 (220g/m or less) (sheets) Note The number of sheets varies depending on the grammage used. Depending on the paper size and paper type, the booklet may distend.
-
Page 93: Changing Angle
Important • Even with the types of papers that our company recommends, stapling failure may occur depending on the type of paper (especially fabric papers), the environment where the device is installed (temperature, humidity, etc.), and the data content, even when the number of sheets is within the stapling capacity. •... - Page 94 Pull the Top Output Tray to the right, remove it from the lower fixed position (A), and insert the claws at the front edge of the tray to the upper fixed position (B). Note • Normally set the tray at the lower fixed position. If the tray is at the upper fixed position of the exit, paper may fall from the Top Output Tray and a paper jam may occur when paper is output to the Finisher tray.
- Page 95 ￭ Lightweight paper housing wire When it is difficult to load thin paper, install the wire. Note • The tray capacity is 10 sheets. • Paper of which width is 256 mm or less cannot be used. • The supported paper weights are from 82 to 209 g/m Change the angle of the Top Output Tray to the lower fixed position (A).
-
Page 96: Paper Curl
Paper Curl • If A5 is curled upward, a paper jam may occur. In this case, set the Interface Decurler Module’s curl correction to the highest level and the In- serter’s curl correction to upward. • If the paper is curled downward, it might jam. In this case, set the Interface Decurler Module’s curl correction to the lowest level and the In- serter’s curl correction to downward. - Page 97 ■Staple Cartridge for Saddle Stitch ￭ Staple Cartridge Types XE (2PCS) Confirm that the machine is not operating, and open the Cover. Pull out Booklet Maker [3]. Hold the handle of the Staple Cartridge (R2) (R3) and pull it out. Push the orange buttons on either sides of the car- tridge ( ) and open the cover (...
- Page 98 Close the cartridge cover. Insert the cartridge into the original position. Hold the lever and lightly press it up until you hear a click. Note Align the ▲ marks. Slowly insert Booklet Maker [3] all the way. Close the cover. Optional Units...
- Page 99 Staple Jams If paper is not being stapled or if staples are bent, follow the procedures mentioned in the follow- ing pages. If the issue isn't resolved even after the procedure, contact your local representative. Paper is not stapled Staple is bent If the staple looks like any of the following images, contact your local representative.
- Page 100 Open the cover of the unit and remove the jammed staples. Insert the unit into the original position. Close the cover. Staple Cartridges for Saddle Stitch Confirm that the machine is not operating, and open the Cover. Pull out Booklet Maker [3]. Hold the handle of the Staple Cartridge (R2) (R3) and pull it out.
- Page 101 Insert the Staple Cartridge into the original position. Hold the handle and lightly press it up until you hear a click. Note Align the “” marks. Push in the Booklet Maker [3]. Close the cover. When Staple Cartridge for Side Stitch Comes off If the Staple Cartridge comes off from the unit due to fall during operation, etc., perform the fol- lowing steps.
- Page 102 Remove the staples that stick out from the Staple Cartridge. Caution Please be very careful not to hurt your fingers, etc. when separating staples. Insert the Staple Cartridge into the unit. Optional Units...
-
Page 103: Paper Jams
Paper Jams Note The error indicator at the top of the machine is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper. - Page 104 ■When Indicator E2 is Turned on Open lever [1c] to the right ( 1 ), turn knob [1e] clock- wise ( 2 ), and remove the jammed paper ( 3 ). Note Jammed paper may be hidden at the upper section. Return lever [1c].
-
Page 105: Booklet Maker
■When Indicator E6 is Turned on Remove the jammed paper that sticks out from the exit of the Finisher Tray. Close the cover. Check the curl direction of the jammed paper and correct the curl. Refer “Curl Correction” (p.44) Booklet Maker Open the Cover. - Page 106 ■When Indicator E8 is Turned on Pull out Booklet Maker [3]. Note Confirm that paper is not jammed at the lever [3a] before pulling it out. Turn knob [3b] counterclockwise ( 1 ) and remove the jammed paper ( 2 ). Push in the Booklet Maker [3].
-
Page 107: Square Back Fold Trimmer D1
Square Back Fold Trimmer D1 Device Components / Caution Labels Component Function Left Cover Open this cover to clear paper jams. Right Cover Open this cover to clear paper jams. Booklet Tray Outputs are delivered here. Note When Square Back is performed, a thin press mark parallel to the back is made. - Page 108 Main Specifications Item Specification Paper size According to Saddle stitch / Single fold of Finisher D Paper weight Booklet Tray capacity 20 copies (16 sheets or less) Note • A maximum of 16 copies for 17 to 20 sheets, a maximum of 12 copies for 21 to 25 sheets, and a maximum of 10 copies for 26 to 30 sheets.
- Page 109 Waste Container Note Dispose cut pieces while the machine is on. Confirm that the machine is not operating, and pull out the waste container. Hold the belt of the waste container and pull it out with both hands. Note Do not apply excessive load on the belt by twirling the container as holding the belt, etc.
- Page 110 Paper Jams Note The error indicator at the top of the machine is turned on. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine.
- Page 111 Turn knob [3b] clockwise and remove the paper. Close the Left Cover. ■When Indicator E2 is Turned on Open the Left Cover. Remove the jammed paper. Close the Left Cover. ■When Indicator E3 is Turned on Open the Right Cover. Remove the jammed paper.
