- Page 5 Insert dowels (A) into panel (2). Screw cam bolts (B) into panels (1,2). Insert dowels (A) into panel (4,15) and slats (6,7). Screw cam bolts (B) into slat (5).
- Page 6 Insert dowels (A) into legs (11,12,13,14) and panels (3,20). Screw cam bolts (B) into legs (11,12,13,14). Attach legs (11,13) to panel (3) using cam bolts and dowels as guides. Insert cam locks (C) into panel (3) and tighten with a screwdriver.
- Page 7 Attach legs (12,14) to second panel (20) using cam bolts and dowels as guides. Insert cam locks (C) into panel (20) and tighten with a screwdriver. Attach slat (7) to panel (2) using cam bolt and dowels as guides. Insert cam lock (C) into slat (7) and tighten with a screwdriver.
- Page 8 Attach support leg (8) to panel (2) using bolts (E). Tighten bolts (E) with wrench (G). Attach slat (5) to panel (4) using cam bolts and dowel as guides. Insert cam locks (C) into panel (4) and tighten with a screwdriver.
- Page 9 Attach panel (4) to panel (2) using bolts (E). Tighten bolts (E) with wrench (G). Attach slat (6) to slat (5) using dowel as guide.
- Page 10 Attach panel (3) with legs (11,13) to the assembly from the previous step using cam bolts and dowels as guides. Insert cam locks (C) into panel (2) and slat (6) and tighten with a screwdriver. Attach second panel (12) with legs (12,14) to the assembly from the previous step using cam bolts and dowels as guides.
- Page 11 Place the back panel (15,17,19) on the unit and secure it to the bottom panel (2) with bolt (E) and wrench (G). Place the back panel (16,18) on the unit and secure it to the bottom panel (2) with bolt (E) and wrench (G).
- Page 12 Carefully attach panel (1) to the assembly using cam bolts and dowels as guides. Insert cam locks (C,D) into the assembly as shown above and tighten with a screwdriver. Cover all visible cam locks with stickers (J) as desired.
- Page 13 Insert shelf support pins (F) into the assembly at desired shelf heights. Carefully place shelves (9,10) on shelf support pins (F).
