- Page 1 Q-TEE II Q-TEE II C INSTALLATION MANUAL (ENGLISH)
- Page 2 INSTALLATION MANUAL PRODUCTION NUMBER The production number is located on the back of the stove and on the first page of the user manual. THIS MANUAL APPLIES TO THE FOLLOWING MODELS: • Q-Tee II • Q-Tee II C Q-Tee II Q-Tee II C 2 - EN...
- Page 3 CONTENT PRODUCTION NUMBER INSTALLATION MANUAL Malfunctions ........... . . TECHNICAL DATA Specifications .
- Page 4 2:2015+A1:2019 based on the individual solution on site. ATTENTION! The appliance shall not be installed with ventilating systems which have pressure below -15 Pa. ATTENTION! RAIS/ATTIKA recommends having the appliance installed by an authorised technician. Please ask your deal- er for further information. 4 - EN...
- Page 5 INSTALLATION MANUAL ATTENTION! Before the stove may be put to use, the set-up must be reported to your local chimney sweeper. MALFUNCTIONS STOVE IS BURNING TOO WEAK If you are experiencing disturbances, some of the most • Insufficient wood common causes are listed below. •...
- Page 6 *Max. load limit Q-TEE II Q-TEE II C RATING PLATE All RAIS/attika stoves have a rating plate indicating the stove’s distance to combustibles, efficiency etc. The name- plate can also be found by scanning the QR code. 6 - EN...
- Page 7 TECHNICAL DATA Set-up distances Q-Tee II & Q-Tee II C Minimum distance from the back of the stove to combustible material Minimum distances from the sides to combustible material Minimum distance from the top to combustible material at the ceiling 1200 Minimum distance from the front to combustible material (Distance to furniture) Minimum distances from the front to combustible material in bottom front radi-...
- Page 8 The weight of the stove is indica- ted in the brochure. If the stove is installed with the RAIS/attika log store, the distance in front of the stove must meet the UK Building Regulations of 300 mm.
- Page 9 INSTALLATION DISTANCE IN CASE OF COMBUSTIBLE WALL - Isoleret røgrør - Isoleret røgrør Q-TEE II Q-TEE II C Combustible ceiling Combustible ceiling 1200 1200 1200 - Isoleret røgrør *0 mm: As 65 K is not exceeded by radiation on the floor in *0 mm: As 65 K is not exceeded by radiation on the floor in front and/or on the side wall.
- Page 10 INSTALLATION DISTANCE IN CASE OF NON-COMBUSTIBLE WALL INSTALLATION DISTANCE IN CASE OF NON-COMBUSTI- BLE WALL We recommend a minimum distance to non-combusti- ble material of 50 mm for cleaning purposes. SPECIAL PRECAUTIONS FOR INSTALLATION IN UK RECESS INSTALLATION - NON COMBUSTIBLE WALLS to the hearth should comply with the guidance on the For installation within a non combustible recess (ie a ty- separation of combustible material given in UK Building...
- Page 11 INSTALLATION DISTANCE IN CASE OF COMBUSTIBLE WALL WITH WALL PANELLING INSTALLATION DISTANCE IN CASE OF COMBUSTIBLE IMPORTANT WALL WITH WALL PANELLING Please bear in mind that the installation distan- Wall panelling with 50 mm Skamotec 225 or material ces on the following pages only apply to the with similar properties.
- Page 12 DIMENSIONAL SKETCHES DIMENSIONAL SKETCH: Q-TEE II - 60 CM BASIC 90 - Q-Tee II Classic 409 (G) 12 - EN...
- Page 13 DIMENSIONAL SKETCHES DIMENSIONAL SKETCH: Q-TEE II - 72 CM WITH LEGS 4290 - Q-Tee II Classic with Low Legs 409 (G) EN - 13...
- Page 14 DIMENSIONAL SKETCHES DIMENSIONAL SKETCH: Q-TEE II - 76 CM WITH LEGS 90 - Q-Tee II Classic with High Legs 409 (G) 14 - EN...
- Page 15 DIMENSIONAL SKETCHES DIMENSIONAL SKETCH: Q-TEE II - 88 CM BASE 290 - Q-Tee II Classic with Low Plinth 409 (G) EN - 15...
- Page 16 DIMENSIONAL SKETCHES DIMENSIONAL SKETCH: Q-TEE II - 98 CM BASE 290 - Q-Tee II Classic with High Plinth 409 (G) 16 - EN...
- Page 17 DIMENSIONAL SKETCHES DIMENSIONAL SKETCH: Q-TEE II C - 60 CM BASIC - Q-Tee II C Classic 409(G) EN - 17...
- Page 18 DIMENSIONAL SKETCHES DIMENSIONAL SKETCH: Q-TEE II C - 72 CM WITH LEGS - Q-Tee II C Classic with Low Legs 409 (G) 18 - EN...
- Page 19 DIMENSIONAL SKETCHES DIMENSIONAL SKETCH: Q-TEE II C - 76 CM WITH LEGS - Q-Tee II C Classic with High Legs 409 (G) EN - 19...
- Page 20 DIMENSIONAL SKETCHES DIMENSIONAL SKETCH: Q-TEE II C - 88 CM BASE - Q-Tee II C Classic with Low Plinth 409 (G) 20 - EN...
- Page 21 DIMENSIONAL SKETCHES DIMENSIONAL SKETCH: Q-TEE II C - 98 CM BASE 0 - Q-Tee II C Classic with High Plinth 409 (G) EN - 21...
- Page 22 INSTALLATION RECYCLING OF PACKAGING The stove is delivered in recyclable packaging. This packaging must be disposed of in accordance with na- tional regulations relating to the disposal of waste. Styrofoam Plastic straps Cardboard Plastic Sheet metal Pallet wood DISPOSAL AFTER END OF LIFE When your stove can no longer be used in the distant fu- ture, it is important that it is disposed of correctly.
- Page 23 INSTALLATION PACKAGING AT DELIVERY Upon delivery, the stove is secured to a transport pallet using four transport safety fittings. The safety fittings are attached with screws which must be unscrewed. The safety fittings can then be removed. HEIGHT ADJUSTMENT There are four adjustment screws underneath the ap- pliance.
- Page 24 INSTALLATION INSTALLATION OF SMOKE OUTLET IN TOP OUTLET The stove is prepared for top outlet on delivery. Mount the flue outlet with the nuts and bolts supplied. CHANGING THE CHIMNEY CONNECTION The stove is delivered ready for top outlet, but can be changed to rear outlet as follows.
- Page 25 INSTALLATION REMOVING THE COMBUSTION CHAMBER LINING To reach the flue, carefully remove the vermiculite smo- ke deflector plates. Remove the smoke deflector plate by pulling it forwards and tilting it so that the rear end is clear of the vertical plates. Remove the smoke baffle by lifting it up and forward to free it from the fixings.
- Page 26 INSTALLATION MOUNTING/CHANGING THE HANDLES On delivery, the stove is fitted with a temporary handle. This is removed by removing the nuts. The new handle can then be mounted on the stove with the nuts. 26 - EN...
- Page 27 CLEANING AND MAINTENANCE CLEANING AND MAINTENANCE It is important that the stove is cleaned and maintained both inside and out. When this is done, the stove must be cold. The stove should be inspected by a chimney sweep once a year. Always check the chimney and flue collar for blockages before a heating season.
- Page 28 All RAIS/attika stoves have the option to supply external air. If the air supply is 5-10 metres from the stove, use a Ø120 mm flex hose instead.
- Page 29 EXTERNAL AIR CONNECTION - AIRSYSTEM AIR CONNECTION ON THE BACK When purchasing a stove with rear air connection, it can either be mounted in the plinth or directly on the back. For base mounting, mount the airbox (1) under the reflector plate (2).
- Page 30 SPECIAL PRECAUTIONS FOR INSTALLATION IN UK PERMANENT AIR SUPPLY The appliance needs a permanent air supply to the room ATTENTION! of installation as the appliance is over 5 kW, confer with This page is only relevant for appliances installed Building regulation Approved Document J. in United Kingdom.
- Page 31 SPECIAL PRECAUTIONS FOR INSTALLATION IN UK chimney then a flue liner suitable for solid fuel must be WARNING! Health and Safety Advice Notice used in accordance with Building Regulations Approved The installation of this heating appliance is gover- Document J. ned by the Health and Safety at Work Act 1974.
- Page 32 Article number: 8426520ENG RAIS A/S ATTIKA FEUER AG Industrivej 20 Brunnmatt 16 DK-9900 Frederikshavn CH-6330 Cham Denmark Switzerland www.rais.com www.attika.ch...
