Summary of Contents for Gigabyte GSmart MW702

  • Page 2 Copyright All mobile products by GIGA-BYTE COMMUNICATIONS INC.mentioned in this document, including the device, accessories, software, text, music, and pictures, are owned by, or authorized by original manufacturers to GIGA-BYTE COMMUNICATIONS INC. Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of GIGA-BYTE COMMUNICATIONS INC.

  • Page 3: Safety Information

    Safety Information This chapter contains important information on safe and efficient operation. Please read this information before using the device. Exposure to Radio Frequency (RF) Energy The device contains a transmitter and a receiver. When it is ON, it receives and transmits RF energy. Please use the device appropriately.

  • Page 4: Regulatory Agency Identifications

    Regulatory Agency Identifications For regulatory identification purposes, your product is assigned a model number of MW702. To ensure continued reliable and safe operation of your device, use only the accessories listed below with your MW702. The Battery Pack has been assigned a model number of GPS-H01. Note: This product is intended for use with a certified Class 2 or Class 3 Limited Power Source, rated 5 Volts DC, maximum 1 Amp power supply unit.
  • Page 5 • ETSI EN 300 328 Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband Transmission systems; data transmission equipment operating in the 2.4 GHz ISM band and using spread spectrum modulation techniques. Safety precautions for RF exposure • Use only original manufacturer-approved accessories, or accessories that do not contain any metal. •...
  • Page 6 Telecommunications & Internet Association (TIA) safety information Pacemakers The Health Industry Manufacturers Association recommends that a minimum separation of six inches be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.
  • Page 7 equipment. RoHS Compliance This product is in compliance with Directive 2002/95/EC of the European Parliament and of the Council of 27 January 2003, on the restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS) and its amendments. MW702│0-6...

  • Page 8: General Information

    General Information This chapter contains important information on safe and efficient operation. Please read this information before using the device. Ignorance of the following notices may lead to violations of the law. • Before using the device, please make sure you have fully charged the battery. •...

  • Page 9: Table Of Contents

    Table of Contents Copyright……………………………………………………….…………………………………………………..……0-1 Safety Information…………………………………………………...……….…………………………………………0-2 Regulatory Agency Identifications………………………………………….……………….……………………….0-3 General Information…………………………………………….……………….………………………………….…0-7 Chapter 1 Before Using Your Device………………………………………………...………………………….…1-1 1.1 Getting to Know Your Device…………...……………………………………………………………………….1-1 1.2 Features ……..………………………………………………….…………………………………………………1-3 1.3 Insert the Battery & SIM card………………………………….…………….. …………………………………..1-3 1.4 SIM ………………………..….……………………………………………………………………………………..1-3 1.5 Battery …….…………………………………………………….……………………………….………………….1-3 1.6 Lock/Unlock …...……………….…………………………………………………………………………………..1-4 1.7 Power ………………….……………………………………………………………………………………………1-5 Chapter 2 Getting Started……..…………………………………………………………………………………….
  • Page 10 3.9 Call History ……….……………………………………………….………………………………………………..3-3 3.10 Setting Ringtone and Password ………………………………………………...………………………………3-4 3.11 Black List...……………………………………………………...…………………………………………………3-4 Chapter 4 Settings………………….……….....................4-1 4.1 Personal Settings …………..........………………............4-1 4.2 System Settings............................4-3 Chapter 5 Synchronization………………………….………….................5-1 5.1 About ActiveSync............................5-1 5.2 Install and Use ActiveSync.........................5-1 5.3 Synchronize via Bluetooth..........................5-2 Chapter 6 Getting Connected…………………....................6-1 6.1 Internet Access............................6-1 6.2 GPRS Connection Settings........................6-1 6.3 Activating GPRS Connection........................6-1...
  • Page 11 Chapter 9 Applications.......…………..…..................9-1 9.1 Calendar..............................9-1 9.2 Contacts..............................9-1 9.3 Tasks................................9-2 9.4 Notes…...............................9-3 9.5 Word Mobile ...............................9-3 9.6 Excel Mobile...............................9-4 9.7 PowerPoint Mobile............................9-4 9.8 OneNote Mobile............................9-4 9.9 Windows Media Player…..........................9-4 9.10 Internet Explore.…............................9-5 9.11 Calculator..............................9-6 9.12 Games..............................9-6 9.13 STK (SIM Tool Kit)............................9-6 9.14 Zip.…………………..........................9-6 9.15SD Add-Ons.…………………………………………………………………………………….…………………9-6 9.16 GPS Tracking............................9-7...

  • Page 12: Chapter 1 Before Using Your Device

    1. Before Using Your Device Press this key to end a 1.1 Getting to Know Your Device call or to return to End Key Today screen from any This section introduces you to the hardware of the screen. device and its function keys. Press the Windows Windows Flag key to open Start menu...
  • Page 13 Press and hold Power Plug in headset, and key for a few seconds then you can listen to Power On/Off to power on/off your the FM radio, music 15 Headset Plug device. via the headset or use the device's Use USB connector to hands-free kit.

  • Page 14: Features

    1.2 Features 5. Push the battery cover back, and then you will hear “click”. MW702 is not only having mobile phone features, it 1.4 SIM also integrates Personal Digital Assistant (PDA) capability. The following section provides more Before using your MW702, you must contact a information about the device features: network operator to get a personal SIM (Subscriber ․Touch screen: 2.8”...

  • Page 15: Lock/Unlock

    Please make sure that the battery is installed and fully charged when using your MW702 for the first time. You may charge the battery in the following ways: 1. Universal AC Adapter: Plug your AC adapter into a suitable main power socket, and plug the connector to the charging slot of your MW702.

  • Page 16: Power

    Power off While the power is on, press, and hold Power key on the top of the device for about 5 seconds to turn it off. To reduce the power consumption of your device, you may change the backlight duration and brightness level.
  • Page 17 Sleep Mode 1. Sleep Mode is a power saving mode designed to reserve battery power. After idling for a period of time, the device automatically enters Sleep Mode. You may also manually enter Sleep mode by pressing power On/Off key shortly. The backlight of the screen will turn off and the device will go into Sleep mode.

  • Page 18: Chapter 2 Getting Started

    2. Getting Started 4. Command area 2.1 Display Information Depending on different mode, this area contains different features such as menu The main screen displays the following information: options, input panel and commands to create or edit a file. 5. Pop up-menu This allows you to access an item quickly.
  • Page 19 From Today screen > Start > Programs Your device contains the following programs: Icon Programs Description Audio Mixer, Camera, Photo Editor, Pictures Multimedia & Videos, Recorder, JAVA, FM Radio Calculator, Pocket Remote, Tools Restore to Default, Zip Dial Kit, Internet Phone Sharing, SIM Manager...
  • Page 20 applications from the Internet for your device. Perform MSN Messenger functions. Write notes, Notes memo, or drawings. Connect, and control your Remote desktop Desktop computer Mobile remotely from your device Search for all Search data, programs, and files. Program Description This is your Windows gateway to help...
  • Page 21 Tap Start > Settings > System tab: Memory status and running Memory programs. Power status and wireless Power signals. You can activate the Quick Quick Menu Menu at the upper-right corner of the screen. Settings for region, number, Regional currency, time, and date. Settings Remove Remove programs from...
  • Page 22 Tap Start > Settings > Connections tab Use ActiveSync or SD-Card Reader. Wi-Fi Configurations for Wi-Fi. Display Wi-Fi status and IP Wi-Fi Utility info. Wireless Turn on/off Bluetooth, flight Manager mode, Wi-Fi. Status & Icon area This area shows icons of basic system status or alerts.

  • Page 23: Screen Orientation

    Wi-Fi is activated; a 2.2 Screen orientation Wi-Fi network is in You can choose your screen display in Portrait or range; Wi-Fi network Landscape mode. The Portrait mode allows you to is connected. get a better view or a better operation of certain Strong signal.

  • Page 24: Setting The Time& Date

    2.4 Using the Stylus Use the stylus to touch or write on your screen. Using stylus can avoid damaging your screen. There are 2 ways to use your stylus: ․Tap: softly tap a desired item by your stylus, and lift the stylus from the screen. ․Press: under the certain condition, touch and hold your stylus on a desired item for a few seconds until a dotted circle appears.
  • Page 25 3. Tap the delete key on your screen keyboard to delete. 4. To close the screen keyboard, tap the Input Panel icon again on your screen to hide the screen keyboard. Note: To change the displayed keyboard size on the screen, tap the Input Selector arrow icon beside the Input Panel icon...

  • Page 26: Drawing On The Screen

    appear. selection handle appears. To select multiple 3. Use the stylus to write anywhere on the screen. drawings, deselect the pen button and drag it to The handwriting will be converted to text after you select the drawings you want. lift the stylus from the screen.

  • Page 27: Editing My Info

    recording, hold down Volume key. When you 1. Tap Start > Settings > Personal tab > Lock > hear the beep, recording has begun. Release the Password tab. button when you are finished. The new recording 2. On Password tab screen, check Prompt if device is stored in the open note, or as a standalone unused for.

  • Page 28: Multi-Language

    2.13 Multi-Language Swedish (Finland), Tatar, Thai, Turkish, Ukrinian, Urdu (Islamic Republic of Pakistan), Uzbek (Cyrillic), The device supports multi-language automatically. If Uzbek (Latin). the documents don’t show correctly, tap Start > Settings > System > Regional Settings and select the region and the language you want. Supported languages in alphabetic order are: Afrikaans, Albanian, Arabic (Saudi Arabia), Azeri (Cyrillic), Azeri (Latin), Basque, Belarusian, Bulgarian, Catalan,...

  • Page 29: Chapter 3 Phone Functions

    3. Phone Functions 3.1 Phone Dialer Screen and Key When a call is connected, the screen displays the following: Introduction 1. The calling status 2. The name and number of the contact you are Press Talk/Send key to enter phone functions. calling Please insert a SIM card before using these 3.

  • Page 30: Receiving/Ignoring A Call

    number using the keypad on the screen. To make an international call 1. Tap, and hold 0 key until + sign appear. + 2. To delete an error input, use key on replaces the international prefix of the country your screen. that you are calling from.

  • Page 31: Making A Call From Contacts

    Contact. After you select one of them, you can edit change t o icon. the contact’s information. 3.7 Making a Call from Contacts 1. You may set photos in Picture field for this contact, by which the contact’s photo will display as an On Today screen, you can tap Contacts on the incoming call photo ID.

  • Page 32: Setting Ringtone And Password

    history. 3.11 Black List 4. On Call History screen, select the contact to redial this number at once. Block all unknown calls. When a blocked number 5. On Call History screen, tap, and hold on a phone calls, the screen will display incoming call alert and number to open a drop-down menu for more ring but will automatically hang up within 5 seconds.

  • Page 33: Chapter 4 Settings

    4. Settings recording. You can change input options by 4.1 Personal Settings tapping the arrow You may set your personalized settings by Lock preference. You may set a personal password to lock your device. Buttons A strong password must have at least 7 characters You may assign programs to a hardware button.
  • Page 34 1. Tap Start > Settings > Personal tab > Menus or .mid formats. 2. Select the programs you want, and then tap OK. Keypad Owner Information You can use this function to change the key tone. You can input your personal information in Owner If you select Long tones, the key tone will be Information to help you identify your phone.

  • Page 35: System Settings

    3. Choose a folder, and tap the file you want. 4. Tap OK to save. Note: All services in Services tab are provided by operators. Please contact Note: The recommended picture size for your operator for more services. the background is 240 x 320 pixels in jpeg file format.
  • Page 36 System tab > Backlight. Customers Feedback ˙On Battery Power tab, you can turn ON/OFF the It is Customer Experience Improvement Program backlight, when using battery power. designed by Microsoft®. The purpose is to identifying ˙On External Power tab, you can turn ON/OFF the trends and usage patterns to improve the software.
  • Page 37 type and how your device is being used. consumption. ˙On Advanced tab, you can select the options for Windows Update turning off your device to conserve battery power. Download and update Windows Mobile. To help keep ˙On Extended tab, you can check “lock device your mobile device protected.
  • Page 38 ˙On About tab, you can know the details of Voice Commander. MW702│ 4-6...

  • Page 39: Chapter 5 Synchronization

    5. Synchronization 5.1 About ActiveSync 1. ActiveSync Installation: You may use Microsoft ActiveSync to synchronize Use the enclosed CD to install Microsoft data in this device with personal computer. ActiveSync in your personal computer. This device already has the built-in ActiveSync. ․You can update Outlook data in this device and in 2.

  • Page 40: Synchronize Via Bluetooth

    5.3 Synchronize via Bluetooth You can synchronize data via Bluetooth. Select Start > Programs > ActiveSync > Menu, and then select “Connect via Bluetooth” and tap ”Synchronize” in this device to process synchronization. Note: If you want to synchronize your phone and your PC via Bluetooth, your PC needs to have a Bluetooth receiver, a host adapter, or a built-in Bluetooth.

  • Page 41: Chapter 6 Getting Connected

    6. Getting Connected When you use GPRS and Internet connection, you 3. Select a desired network name from the list; will not be able to answer a call. If you want to make press “New” to add available network to list; a call, your device will disconnect to the Internet press “Edit”...

  • Page 42: Gprs Wizard

    6.4 GPRS Wizard When you are connected to GPRS network, you may surf on the Internet or send and receive e-mail. GPRS Wizard selects your GPRS network automatically. 1. Tap Start > Settings > Connections tab > GPRS Wizard. 2. Choose the regional name and the network name.
  • Page 43 3. If you want this device to be detected by other 6. Select the device to be connected, and then Bluetooth devices, please check “Make this select “Next“. The screen will prompt for device visible to other devices”. (Without password. After inputting password on password checking this item, other Bluetooth devices are input screen, select “Next“.

  • Page 44: Internet Sharing

    Registering New Serial Port: 1. Select “New Incoming Port” to enter setup screen. 2. Select a port to be set. 3. Select “Finish”. 6.7 Internet Sharing You can set the device as a wireless modem. Internet Sharing allows your PC/Notebook be connected to a wireless network.

  • Page 45: Usb

    Note: Reboot is required when you change the IP address in Start > Settings > Connections tab > Wi-Fi > Network Adaptors tab > Edit > IP Address tab. 6.9 USB You may use the device as a mass storage device or a Micro SD card reader.

  • Page 46: Chapter 7 Messaging

    7. Messaging 7.1 SMS\MMS & E-mail Messaging includes text messages (SMS), multimedia messages (MMS), and E-mail. Before receiving and sending your e-mail, please make sure this device has connected to a network. When you are connected to a network, you may go to “Messaging”...
  • Page 47 5. Tap the Input Panel icon on the lower center of the screen to activate or disable the Input Panel, and then edit this SMS or MMS. When read a SMS\MMS, you can: Select Start > Messaging > SMS\MMS, and then select the SMS\MMS to read and reply.

  • Page 48: Synchronously Process E-Mail

    2. Tap “To”, “Cc”, or “Bcc” fields to input receivers’ Inbox synchronization process rules: phone numbers, or tap Menu > Add Recipient > 1. Please check the units related to ActiveSync. From Contacts or From Call History to add 2. If you choose not to perform synchronization, you recipients.

  • Page 49: Using E-Mail

    1. Select Start > Messaging > Menu > Options > 5. Tap the Input Panel icon on the lower center Accounts tab, and tap New Account; or simply of the screen to activate or disable the Input select “Setup E-mail” in Messaging. Input e-mail Panel, and then edit this e-mail.

  • Page 50: Push E-Mail

    up your device to synchronize via an over-the-air connection with Exchange Server. To use push e-mail, please turn on Wi-Fi or data connection to connect to the Exchange Server. Enabling Push E-mail on your PC: 1. Connect your device to the PC with a USB cable. 2.

  • Page 51: Messenger

    Note: To be able to use push e-mail, you need to have an exchange server. Microsoft Exchange Server also supports useful functions such as remote device wipe. To find out more on the benefit and usage of Microsoft Exchange server, please visit Microsoft’s website, http://www.microsoft.com.

  • Page 52: Chapter 8 Multimedia

    8. Multimedia 8.1 Camera Camera Settings: 1. Macro: On, or Off. You may use camera function in this device to 2. Mode: You may select different shooting modes capture important moments. for your needs. 3. Effect: You may apply many different photo 1.

  • Page 53: Video Mode

    8.2 Video Mode Video Settings: 1. Mode: You may select different recording modes The device camera can also be used as a video to fit the recording environment. recorder to record memorable moments of your life. 2. Effect: You may apply many different photo effects.

  • Page 54: Recorder

    keep recording on the background; or tap Menu > Note: For your convenience, the filename Exit to stop recording, and exit. of photos with coordinates always ends with (GPS) on this device. Example: Note: If there is incoming call during the Camera0024 (GPS).jpg recording, answering the call will terminate the recording automatically.

  • Page 55: Java

    8.6 JAVA This device supports JAVA, and therefore, you can use JAVA applications and play games. 8.7 Audio Mixer Audio Mixer enables you to configure bass, treble, and 3D effects while you listen to the music. Use Media Player to play your audio files, and then activate Audio Mixer to adjust the settings.

  • Page 56: Chapter 9 Applications

    9. Applications 9.1 Calendar If you select Remind me in “Reminder” field, then the device will remind you by an alert sound according to Appointments and Meetings: the settings in Start > Settings > Personal tab > You may use “Calendar” to arrange appointments, Sounds &...

  • Page 57: Tasks

    Phone Book: company name. “Contacts” helps you manage your phone book. ˙To search for a contact, select Start > 1. Tap “Enter a name…” field to input part of name Programs > Search. Enter the name of the or desired or phone number to search for that contact in “Search for”...

  • Page 58: Notes

    options list. Microsoft Word in your computer to copy and move 7. To add notes, select Notes tab and input desired document between this device and your computer content. easily. Through the synchronization, you may keep 8. Tap OK to save the task, and return to “Tasks” updated contents in both of this device and your screen.

  • Page 59: Excel Mobile

    9.6 Excel Mobile PowerPoint Mobile, the screen will show your PowerPoint files list, from which select the file you You may use Excel Mobile in this device with want to open. Microsoft Excel in your computer to copy or move 1.

  • Page 60: Internet Explore

    Windows Media Player in this device can play Windows Media and MP3 files. 9.10 Internet Explorer You may use the following methods to browse web pages or WAP pages. Select Start > Internet Explorer to activate Internet Explorer. You may: Synchronize your favorite URL links on your PC to the device.

  • Page 61: Calculator

    ˙You may add or delete folders or URL links. 9.12 Games Mobile Favorites Folder: You may access “Games” to select games you like in After you install ActiveSync to your computer, this device for entertainment. “Mobile Favorites” folder will be added to “My 1.

  • Page 62: Gps Tracking

    SD card. The installation process will be launched 9.17 Location Message automatically, when you insert the card into the device. Select the application you want, and follow This feature allows you to send immediate location the instructions to install. (Available in selected through SMS with assigned frequency.

  • Page 63: Sim Manager

    Manager > Dial Kit. 9.20 Magnifier You can enlarge words in the device. Tap Start > Programs > Tools > Magnifier. 9.21 Pocket Remote You can connect your computer with your device, and then you can use your computer to control your device via ActiveSync.
  • Page 64 2. On the next screen, you should provide the space on your device, you will be notified. backup file name and location. If you select the Scheduled Backup Custom location, you will be able to select any 1. On the initial screen, select Scheduled Backup. folder on your device.

  • Page 65: Search

    approximately half as small compared to the 9.26 QuickMark uncompressed one). The file size is dependant on the real device storage space used. QuickMark is an application that scans and decodes 6. On the final screen, make sure all the specified with camera of mobile device for offering services.
  • Page 66 applications. This information is sent automatically when you choose to continue. Personally identifiable information will be encrypted during transmission. Once information is sent it is subject to Spb Catalog for GSmart’s privacy policy and practices. Review Spb Catalog for GSmart’s privacy policy by selecting “Privacy Policy”...

  • Page 67: Chapter 10 Managing Your Mobile

    10. Managing Your Mobile The saved data in ROM will not be lost suddenly. As 10.1 Memory Management long as there is sufficient space in this device, you may install suitable programs. Select Start > Settings > System tab > Memory Adding programs through ActiveSync: Main Tab: Before you install a program, please make sure the...
  • Page 68 Adding programs through the Internet: Via the Internet, you may download software which is suitable for this device. Before you install the program, please make sure the device processor is suitable for the software. 1. Select Start > Settings > System tab > About > Version tab to check information in this device.

  • Page 69: Chapter 11 Specifications

    11. Specifications Item Specification System Information Operating System Windows Mobile 6.1 Professional Processor Marvell PXA 270 520 MHz Memory ROM 256 MB, RAM 128MB Size Dimensions (mm) 117 x 59.8 x 14.8 mm Weight (in grams) 130 g (Including battery) Battery Battery Capacity Lithium Polymer 1300 mAh...
  • Page 70 Band EDGE; GSM 900/1800/1900 Connectivity Bluetooth 2.0 Modulation: GFSK Bluetooth Band:2.4 - 2.4835GHz Output power:0dbm (Typical) WLAN 802.11b/g Wireless Technology: OFDM and DSSS Operating frequency: 2.412 - 2.462GHz WLAN WLAN 802.11b Output power:12dbm (Typical) WLAN 802.11g Output power:10dbm (Typical) GPRS GPRS Class 12 WAP 2.0 Modem dial-up...

  • Page 71: Digital Camera

    Max Size Depends on available RAM Phonebook Size Depends on available RAM Ringtone Type MP3, WMA, AMR Polyphone 48 polyphonic mid file Digital Camera Type JPEG Pixels 3.0 mega pixels Auto Focus (Rear Camera) Macro Mode Video Recording Message Windows Live Messenger E-mail External Memory...

  • Page 72: Operating Temperature

    Type Micro SD Card Max Size Maximum to 4GB Operating Temperature Temperature -10℃~45℃ Note: Specifications may vary in some regions. MW702│ 11-4...

  • Page 73: Chapter 12 Faq

    12. FAQ Why can’t I turn on the device? Why does the device launch wrong programs or ignore my command, when I press a device key? Please make sure that the device has sufficient power, and that the battery is secured in the device. Select Start >...
  • Page 74 Exchange Server at the same time? No. You can only synchronize information either with PC or with Exchange Server at one time. How do I connect a Bluetooth headset to my device? 1. Make sure that both of your device and the Bluetooth headset are turned on and within close range, and that the headset is visible.
