Product Name: Cyclone Harness Series
Part #: 21064; 21065; 21066; 21067; 21033; 21034; 21035; 21036; 21029; 21030; 21031;
21032; 21052; 21053; 21054; 21055; 21045; 21046; 21047; 21048; 21041; 21042; 21043;
21044; 21082; 21083; 21056; 21057; 21058; 21059; 21060; 21061; 21062; 21063
Instruction Manual
Do not throw away these instructions!
Read and understand these instructions before using equipment!
Introduction
Applicable Safety Standards
Worker Classi cations
Product Speci c Applications
Limitations
Components and Speci cations
Installation and Use
Maintenance, Cleaning, and Storage
Inspection
Inspection Log
Safety Information
Labels
ANSI Z359.11 Annex A
1
1
1
2
3
4
4 - 5
5
6
7
7
8
9 - 10
Advertisement
Related Manuals for Guardian Cyclone Series
Summary of Contents for Guardian Cyclone Series
- Page 1 Product Name: Cyclone Harness Series Part #: 21064; 21065; 21066; 21067; 21033; 21034; 21035; 21036; 21029; 21030; 21031; 21032; 21052; 21053; 21054; 21055; 21045; 21046; 21047; 21048; 21041; 21042; 21043; 21044; 21082; 21083; 21056; 21057; 21058; 21059; 21060; 21061; 21062; 21063 Instruction Manual Do not throw away these instructions! Read and understand these instructions before using equipment!
- Page 2 Introduction Thank you for purchasing a Guardian Fall Protection Cyclone Harness. This manual must be read and understood in its entirety, and used as part of an employee training program as required by OSHA or any applicable state agency. This and any other included instructions must be made available to the user of the equipment. The user must understand how to safely and e ectively use the Cyclone Harness, and all fall safety equipment used in combination with the Cyclone Harness.
- Page 3 Product Speci c Applications Use of equipment in unintended applications may result in serious WARNING injury or death. Maximum 1 attachment per connection point. Personal Fall Arrest: Cyclone Harness may be used to support a MAXIMUM 1 PFAS for use in Fall Arrest applications.
- Page 4 Limitations Fall Clearance: There must be su cient Fall clearance calculation shown based on standing clearance below the anchorage connector worker falling directly in-line with anchor point. to arrest a fall before the user strikes the Always consider potential swing fall and other ground or an obstruction.
- Page 5 Components and Speci cations Materials: polyester, nylon, steel, and aluminum. Part # Sizes Description S / M - L / 21064 / 21065 / Cyclone Construction Harness w/PT Chest, TB Legs, & TB Waist 21066 / 21067 XL / XXL S / M - L / 21033 / 21034 / Cyclone Construction Harness w/QC Chest, QC Legs , &...
- Page 6 Maintenance, Cleaning, and Storage If a Cyclone Harness fails inspection in any way, immediately remove it from service, and contact Guardian to inquire about its return or repair.
- Page 7 Inspection Prior to EACH use, inspect Cyclone Harness for de ciencies, including, but not limited to, corrosion, deformation, pits, burrs, rough surfaces, sharp edges, cracking, rust, paint buildup, excessive heating, alteration, broken stitching, fraying, and missing or illegible labels. IMMEDIATELY remove Cyclone Harness from service if defects or damage are found, or if exposed to forces of fall arrest.
- Page 8 Safety Information Failure to understand and comply with safety regulations may result in serious injury or death. Regulations included herein are not all-inclusive, WARNING are for reference only, and are not intended to replace a Competent Person’s judgment or knowledge of federal or state standards. Do not alter equipment.
- Page 9 Labels Compliant with: Make only compatible connections. Prior OSHA 1910.140 to use, inspect equipment for rips, tears, OSHA 1926.502, fraying, or any possible structural ANSI Z359.11-2021, deficiency that might compromise the & CSA Z259.10-2018 equipment in a fall. Avoid contact with sharp and abrasive surfaces.
- Page 10 ANSI Z359.11 Annex A Note: This information from the Z359.11 standard is required to be included in the instruction manual for the end user: ANSI/ASSE Z359 Requirements for Proper Use and Maintenance of Full Body Harnesses (Note: These are general requirements and information provided by ANSI/ASSE Z359, the Manufacturer of this equipment may impose more stringent restrictions on the use of the products they manufacture, see the Manufacturer’s instructions.) 1.
- Page 11 If the sternal attachment is used for fall arrest, the competent person evaluating the application should take measures to ensure that a fall can only occur feet rst. This may include limiting the allowable free fall distance. It may be possible for a sternal attachment incorporated into an adjustment style chest strap to cause the chest strap to slide up and possibly choke the user during a fall, extraction, suspension, etc.
