Guardian 42010CSA Instruction Manual

1600127 REV. B
CR3-EDGE
SELF-RETRACTING LIFELINE
Parts: 42010CSA
Instruction Manual
HOUSING LABEL
1500262 Rev. B
42010CSA CR3-EDGE 33' LE SRL
Class
SRL LE
Anchor above or
below dorsal D-ring
CR3-EDGE
33 ft (10 m) Self-Retracting Lifeline
CSA Z259.2.2-17
Suitable for
LEADING EDGE
Convient à une utilisation avec bord coupant
Label Stock:
MacTac REBEL 4MIL MATTE PVC HT PRINT RB528H
Laminate:
MacTac PERMAFLEX 5MIL LUSTRE CLEAR PVC PERM LAM PF6315
Do not throw instructions away.

Read and understand instructions before

using this equipment.
Part # Date of Manufacture Lot # Serial #
42010CSA MM YY
|
Read supplied instructions before using. Failure to follow instructions
may result in serious injury or death. Never modify product. This product is not repairable.
USE This device is only for use by one person as INSPECTION Prior to each use, check locking (pull
a fall arrester. Only make connections directly sharply to test) and retraction function. Inspect for signs
to attachment point on safety harness. Guard of deployment, defects or damage to housing, lifeline
(inspect full length), connectors, or missing parts. Inspect
against swing-fall by keeping lifeline vertically
overhead. Ensure that connection to anchorage impact indicator - see instruction manual. Ensure presence
and legibility of all labels. Inspection by Competent Person
is secured properly before use. Avoid lifeline
contact with sharp or abrasive edges and required at least every 12 months. Immediately remove from
service in event of failed inspection, or if unit is subjected
surfaces. May be used as a component of a
to a fall.
PFAS in HLL applications. Design, installation,
Lifeline Material: Galvanized Steel | Length: 33' (10 m)
and utilization of HLLs must be supervised by
Class SRL-LE | Max. Arrest Force: 1,800 lb (8kN)
a Qualified Person. Suitable for horizontal use.
Competent Person must calculate fall clearance Avg. Deployment Force: 900 lb (4,4 kN)
User Capacity Weight Range (including tools
prior to use; fall clearance calculations must
and equipment): 100-310 lb (45-140 kg)
include considerations for swing fall. Clearance
Min. Setback Distance From Edge: 0 ft
numbers specified based on lifeline installed
Max. Arrest Distance - LE* : 8 ft 6 in (2,6 m)
vertically overhead and in-line with worker.
Max. Arrest Distance - Non-LE** : 3 ft 11 in (1,2 m)
Max. Free Fall: 5 ft (1,5 m)
Inspection Min. Fall Clearance - LE*: 18 ft (5,5 m)
Date
Min. Fall Clearance - Non-LE**: 7 ft 5 in (2,3 m)
Initials D(m) = 0.75
Date of First Use *Anchor between dorsal D-ring and work
surface
Permitted Service Temperature Range:
** Anchor at or above dorsal D-ring
-40°F to 130°F (-40°C to 54°C)
Tested in USA.
Class SRL LE
Assembled in Canada.
DO NOT REMOVE
LABELS
guardianfall.com
PANTONE® Process Black PANTONE® 7549 White
C0 M0 Y0 K0 C0 M32 Y100 K0 C0 M0 Y0 K0
R0 G0 B0 R253 G181 B21 R255 G250 B250
#000000 #FCB414 #FFFFFF
2 English
10 Français
