Page 1: Table Of Contents
85044-L VERTICAL LIFELINE ASSEMBLY (VLA) Instruction Manual Contents 2 Worker Classifications 2 Applicable Safety Standards 2 Permitted User Weight 2 Product Specific Applications 3 Product Specifications and Materials 5 Limitations 5 Compatibility 5 Maintenance, Cleaning, and Storage 6 Installation and Use... -
Page 2: Worker Classifications
Worker Classifications Product Specific Applications Fall Arrest: This VLA may be used Qualified Person: A person with an to support a MAXIMUM 1 Personal accredited degree certification, Fall Arrest System (PFAS) for use and with extensive experience or in Fall Arrest applications. Structure must sufficient professional standing, who withstand loads applied in the directions is considered proficient in planning/... - Page 3 Part # Length Description 01310 Vertical Lifeline Assembly w/Shock Absorber, Positioning Device, and 18" Lanyard Extension 01320 Vertical Lifeline Assembly w/Shock Absorber, Positioning Device, and 18" Lanyard Extension 01323 Vertical Lifeline Assembly w/Shock Absorber, Positioning Device, and 18" Lanyard Extension...
- Page 4 Connector Shock Absorber Positioning Device Extension...
-
Page 5: Limitations
Limitations Maintenance, Cleaning, and Storage Fall Clearance: There must be sufficient clearance below the work surface to arrest Cleaning after important a fall before the user strikes the ground maintaining the safety and longevity of or an obstruction. When calculating fall the VLA. -
Page 6: Installation And Use
4. To move along lifeline, compress and hold Installation and Use Fall Arrester handle. ALWAYS adjust Fall Never for Leading Edge (LE) use. VLA Arrester to reduce slack in the system as must never impact edge of fall hazard. much as possible. - Page 7 Rope w/Integral Shock Fall Arrester w/Integral Shock Fall Arrester w/out Integral Shock Rope w/out Integral Shock...
-
Page 8: Inspection
Inspection Inspections MUST be recorded in inspection log in instruction manual Prior to EACH use, inspect VLA for and on equipment inspection grid label. deficiencies, including, but not limited to, The CP must sign their initials in the box corrosion, deformation, pits, burrs, rough corresponding to the month and year surfaces, sharp edges, cracking, rust, paint the inspection took place. -
Page 9: Safety Information
Safety Information instructions, and must be of compatible size and configuration. Snap hooks, WARNING! Failure to understand and carabiners, and other connectors must comply with safety regulations may result be selected and applied in a compatible in serious injury or death. Regulations fashion. -
Page 10: Labels
Labels ALWAYS READ AND UNDERSTAND ALL MANUFACTURER’S INSTRUCTIONS INCLUDED WITH EQUIPMENT AT TIME OF SHIPMENT. NOT SUITABLE FOR LEADING EDGE USE Compliant with all OSHA 1910.140 & 1926.502 regulations. Worker weight capacity range: 130-310 lbs. Materials: 5/8” diameter co-polymer, polyester, and steel. Make compatible connections only. - Page 11 Diagram A - Fall Clearance Diagram B - Connections Fall clearance calculation shown below is based on a standing worker falling directly in-line with anchor point. SAMPLE CALCULATION ONLY. ALWAYS REFER TO CONNECTOR INSTRUCTIONS FOR PRODUCT-SPECIFIC CLEARANCE INFORMATION.
- Page 12 +1 (800) 466 6385 info@guardianfall.com Guardian 607 East Sam Houston Pkwy South, STE 800 guardianfall.com Pasadena, TX 77503 Guardian® and its logo are registered trademarks of Guardian Fall, Inc. in the US and other countries.
