85082 REV. J
BEAMER 2000
Parts # 00101; 00103
Instruction Manual
Do not throw instructions away.
Read and understand instructions before
using this equipment.
2 Product Specific Applications
2 For All Product Applications
2 Applicable Safety Standards
2 Worker Classifications
3 Compatibility
3 Limitations
3 Maintenance, Cleaning, and Storage
4 Components
4 Specifications
4 Materials
5 Installation and Use
6 Loading Directions
7 Safety Information
8 Labels
9 Diagram
9 Inspection
10 Inspection Log
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Guardian BEAMER 2000
Summary of Contents for Guardian BEAMER 2000
- Page 1 85082 REV. J BEAMER 2000 Parts # 00101; 00103 Instruction Manual 2 Product Specific Applications 2 For All Product Applications 2 Applicable Safety Standards 2 Worker Classifications 3 Compatibility 3 Limitations 3 Maintenance, Cleaning, and Storage 4 Components 4 Specifications...
-
Page 2: Product Specific Applications
English Product Specific Applications Applicable Safety Standards May be used to support a MAXIMUM 1 Meets or exceeds: direct Personal Fall Arrest System ANSI Z359.18-2017 (PFAS) for use in Fall Arrest applications only when used in combination with an energy EN 795-2012 ... -
Page 3: Maintenance, Cleaning, And Storage
MINIMUM 2’ (0.6 m) safety factor, deceleration distance, user height, length of lanyard/SRL, harness stretch, free fall, and all other applicable factors. See Guardian Fall Clearance Calculator: https://guardianfall.com/digital-resources/ fall-clearance-calculator Swing Falls: Prior to installation or use, make considerations for eliminating or minimising all swing fall hazards. -
Page 4: Specifications
Description 00101 .5" to 1.25" (13 mm to 32 mm) Beamer 2000 for Flange Widths 3.5" to 14" (89 mm to 356 mm) 00103 .5" to 1.25" (13 mm to 32 mm) Beamer 2000 for Flange Widths 6" to 16" (152 mm to 406 mm) -
Page 5: Installation And Use
Installation and Use Installation (see illustration below): Step 1 Beamer 2000 is an adjustable anchorage connector designed for use both overhead Hook Fixed Clamp over selected beam flange. and at foot level. If used below the harness Aluminum Bar MUST be positioned parallel dorsal D-ring in Fall Arrest applications, with end of beam. - Page 6 English Loading Directions Beamer Anchor may be loaded in the directions shown below. *NOTE: ANSI or OSHA compliance varies by installation method: ANSI Z359.18-2017, EN 795-2012, OSHA 1926.502 & 1910.140 EN 795-2012, OSHA 1926.502,& 1910.140 Load Load Adjustable Arm Adjustable Arm Load Adjustable Arm Load...
-
Page 7: Safety Information
English Safety Information Harnesses and connectors selected must be compliant with manufacturer’s instructions, and WARNING! Failure to understand and must be of compatible size and configuration. comply with safety regulations may result Snap hooks, carabiners, and other connectors in serious injury or death. Regulations must be selected and applied in a compatible included herein are not all-inclusive, are fashion. - Page 8 Type A Anchorage Connector MAXIMUM 1 connection per Beamer Anchor guardianfall.com Capacity Range: 100-420 lb (45-191 kg) Beamer 2000 guardianfall.com Minimum Breaking Strength (MBS) 5,000 lb (22.2 kN) Beamer 2000 1.5” Permitted Service Temperature: -30⁰ F to 130⁰ F (-34⁰ to 54⁰ C) English ANSI Z359.18-2017...
- Page 9 English Inspection Diagram A - Connections Prior to EACH use, inspect Beamer Anchor for deficiencies, including, but not limited to, corrosion, deformation, pits, burrs, rough surfaces, sharp edges, cracking, rust, paint build-up, excessive heating, alteration, broken stitching, fraying, and missing or illegible labels. IMMEDIATELY remove Beamer Anchor from service if defects or damage are found, or if exposed to forces of fall arrest.
-
Page 10: Inspection Log
English Inspection Log Serial No: Date of first issue: Model #: User: Date: Results/Condition: Inspected by: Next Inspection Date:... - Page 11 Notes:...
- Page 12 This warranty is not transferable to any other Guardian service and does not apply to product that is resold after having been put into service. No other person, firm, entity, or the like is authorized to assume or assign for Guardian any other liability in connection with the sale or use of Guardian’s products.
