- Page 1 SOMATOM Instructions for Use – Operating console with height adjustable table siemens-healthineers.com...
- Page 2 Legend Legend Indicates a hint Is used to provide information on how to avoid operating errors or informa‐ tion emphasizing important details Indicates the solution of a problem Is used to provide troubleshooting information or answers to frequently asked questions Indicates a list item Indicates a prerequisite Is used for a condition that has to be fulfilled before starting a particular oper‐...
- Page 3 Legend CAUTION Used with the safety alert symbol, indicates a hazardous situation which, if not avoided, could result in minor or moderate injury or material damage. CAUTION consists of the following elements: • Information about the nature of a hazardous situation •...
- Page 4 Table of contents Introduction Scope of the Instructions for Use Applicability Safety information General safety information Specific safety information Description Operating console with height adjustable table 3.1.1 Height adjustable table 3.1.2 Actuator 3.1.3 Safety spacer Operation Changing the height of the table Cleaning and disinfection Technical specifications Operating console with height adjustable table...
- Page 5 This Instructions for Use document provides detailed information about your accessories and system components. 1.1 Scope of the Instructions for Use This Instructions for Use document applies to the following CT systems: • SOMATOM Definition AS • SOMATOM Definition Edge • SOMATOM Confidence • SOMATOM Edge Plus •...
- Page 6 2 Safety information 2 Safety information Follow the safety information in this document. To ensure the safe use of your product and the safety of people, you must adhere to the safety information provided in the Instructions for Use. In addition, also observe your country-specific regulations and guidelines.
- Page 7 2 Safety information 2.1 General safety information For the secure operation of your medical device, it is the responsibility of the system owner to ensure that each person who operates the system reads and understands the provided Instructions for Use. WARNING Not observing the Instructions for Use and the safety information of the medical device and the equipment!
- Page 8 Incorrect use and use of non-original and non-released equipment! Wrong diagnosis ◆ Use only the original accessories and equipment or equipment that is released by Siemens Healthineers. This includes, for example, phantoms, footswitches, ECG-cables, positioning aids, or table extensions. ◆ Use the released equipment exclusively for its original purpose.
- Page 9 3 Description 3 Description This section provides information about the design and composition of the operating console with height adjustable table. 3.1 Operating console with height adjustable table The operating console with height adjustable table is the working environment of the operator. A container to store more equipment is optionally available.
- Page 10 3 Description 3.1.2 Actuator Using the actuator, you can raise or lower the height of the table. (1) Upwards (2) Downwards 3.1.3 Safety spacer The safety spacer ensures a safety distance of 25 mm to building parts and surrounding equipment. The safety spacer can be mounted at the left or right side of the table.
- Page 11 4 Operation 4 Operation This section provides information about how to operate your system components or accessories. 4.1 Changing the height of the table You can raise and lower the table by pressing the buttons of the actuator. ✓ A safety distance of 25 mm to building parts and surrounding equipment is kept.
- Page 12 5 Cleaning and disinfection 5 Cleaning and disinfection This section provides you with information on how to clean and disinfect the equipment. ◆ Follow the instructions for cleaning and disinfecting the equipment. Follow the additional cleaning and disinfecting instructions provided in the SOMATOM Instructions for Use –...
- Page 13 6 Technical specifications 6 Technical specifications This section provides the technical specifications of the equipment. 6.1 Operating console with height adjustable table Dimensions and weight may vary slightly from the finished product due to manufacturing tolerances. Accessory Weight Dimensions Further specifications Operating console with height 70.0 kg •...
- Page 14 7 Location of labels 7 Location of labels This section provides information about the main labels applied on the outside of the CT system and system components. The positions on the equipment are also described here. For the meaning of the colors of the safety signs, refer to the SOMATOM Quick Guide.
- Page 15 Examples of environmentally relevant components are accumulators and batteries, transformers, capacitors, monitor picture tubes, and phantoms. For details, contact your local Representative at Siemens Healthineers. For further information about disposal, see System Owner Manual. Operating console with height adjustable table |...
- Page 16 Index cleaning 12 compatible systems 5 disinfecting 12 Disposal 15 height adjustable table 9 changing the height 11 location of labels 14 operating console with height adjustable table actuator 10 overview 9 safety spacer 10 safety advice 7 Safety information 6 technical specifications 13 Operating console with height adjustable table | SOMATOM...
- Page 17 Siemens Healthcare GmbH Henkestr. 127 Henkestr. 127 91052 Erlangen Germany 91052 Erlangen Germany Phone: +49 9131 84-0 siemens-healthineers.com Published by Siemens Healthineers / Print No. HC-C2-X05.610.52.02.02 / © Siemens Healthineers, 2017 - 2023 Date of first issue: 2017-06 / Revision date: 2023-03...
