1-4 Layout Diagram & Jumper Setting
PS/2 Mouse
PS/2 Keyboard
PS2 KB/Mouse Port
PC99 Back Panel
KB/USB Power On Jumper (JP1)
USB Port
USB Port/LAN Connector
SFAN1
Audio Connector
CPU F.S.B. Frequency Selector
(JP2, JP3)
VT6103L LAN Chip
AC97' Audio Codec
PCI Slot
Winbond 83687THF Chip
2MBit Flash ROM BIOS
Front Panel Audio
CD Audio
SPDIF Connector
PRINT
COM1
SFAN2
LAN
COM2 USB1
USB Port
(USB2, USB3)
4
MIC
LINE-IN
LINE-OUT
USB
ATX Power Connector
CPU FAN
DDR DIMM X2
CPU Socket
ATA 133 IDE Connector
(IDE1)
VIA KT880 Chip
ATA 133 IDE Connector
(IDE2)
AGP 4X/8X Slot
VIA VT8237 Chip
Serial-ATA Connector (SATA1, 2)
Clear CMOS (JBAT)
Front Panel Connector
Speak/Power LED Connector
USB Power On Jumper (JP4)
Floppy Connector
