Block mode is also called block transfer, multiple commands, or multiple sector read/write. If
your IDE hard drive supports block mode (most new drives do), select Enabled for automatic
detection of the optimal number of block read/writes per sector the drive can support. The
settings are: Enabled, Disabled.

3-7-2 OnChip Device Function

CMOS Setup Utility – Copyright(C) 1984-2003 Award Software
VIA 1394 Function
VIA LAN Function
VIA LAN Boot ROM
VIA LAN BootROM Boot option
VIA LAN BootROM PXERPL Option PXE
Current VIA MAC Address is
VIA MAC Address Input
AC97 Sound Device
Game Port Address
Midi Port Address
Midi Port IRQ
USB Host Controller
USB 2.0 Support
USB Keyboard Legacy Support
↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit
F5:Previous Values
AC97 Sound Device
This item allows you to decide to enable/disable the chipset family to support AC97 Audio.
The settings are: Enabled, Disabled.
Game Port Address/Midi Port Address
This will determine which Address the Game Port/Midi Port will use.
USB Host Controller
Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have
a USB peripherals. The settings are: Enabled, Disabled.
USB Keyboard Legacy Support
Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have
a USB keyboard. The settings are: Enabled, Disabled.
3-7-3 Onboard Super IO Function
OnChip Device Function
→ (for P4X400DBZ)
Enabled
→ (for P4X400DBP/
Enabled
P4X400DBZ)
Disabled
Hook INT19
003018-XXXXXX
Press Enter
Auto
201
Disabled
10
Enabled
Enabled
Disabled
F6:Optimized Defaults
28
Item Help
Menu Level >>
F1:General Help
F7:Standard Defaults
