Premium Dual Fuel Combi BBQ
Assembly Instructions -
Dimensions
Width - 139cm
Depth - 59cm
Height - 116cm
Important -
Please read this instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800.
Please visit the website www.argos.co.uk for more information.
Produced in China. Sainsbury's Supermarkets Ltd. 33 Holborn, London EC1N 2HT. Sainsbury's (NI) Ltd, Forestside
Shopping Centre, Upper Galwally, Belfast, United Kingdom, BT8 6FX. Argos Limited, 489-499 Avebury Boulevard,
Milton Keynes MK9 2NW. Argos (N.I.) Ltd, Forestside Shopping Centre, Upper Galwally, Belfast, United Kingdom,
BT8 6FX. Argos Distributors (Ireland) Limited, Unit 7, Ashbourne Retail Park, Ballybin Road, Ashbourne, County
Meath, Ireland
Please keep for future reference
206/6004
0359 24
2575 24
Issue 1 - 18/10/24
Advertisement
Related Manuals for Argos Saisbury's 206/6004
Summary of Contents for Argos Saisbury's 206/6004
- Page 1 Shopping Centre, Upper Galwally, Belfast, United Kingdom, BT8 6FX. Argos Limited, 489-499 Avebury Boulevard, Milton Keynes MK9 2NW. Argos (N.I.) Ltd, Forestside Shopping Centre, Upper Galwally, Belfast, United Kingdom, BT8 6FX. Argos Distributors (Ireland) Limited, Unit 7, Ashbourne Retail Park, Ballybin Road, Ashbourne, County...
- Page 2 Safety and Care Advice (Charcoal BBQ) Important - Please read this instructions fully before starting assembly War ning: Whilst every effort has been made in the manufacture of your BBQ to remove any sharp edges, care should be taken in handling to avoid any accidental injury. Assembly time: approx.
- Page 3 Safety and Care Advice (Charcoal BBQ) • Recommend using Maximum 1.5kg of charcoal briquettes on the charcoal grate. Excess charcoal will make the BBQ too hot for cooking. • Ensure the barbecue has cooled down completely before removing the charcoal ash. •...
- Page 4 Safety and Care Advice (Gas BBQ) Important - Please read this instructions fully before using the appliance • Assembly time: approx. 1h. Two people are required to build this BBQ. Retain these instructions for future reference. • Use outdoors only. •...
- Page 5 Safety and Care Advice (Gas BBQ) For optimal performance, we suggest to use a 5-15kg gas bottle. The maximum dimension of the gas bottle is dia 31.5cm and height 58cm. 1= maximum diameter 2= maximum height Never mount the gas bottle under the barbecue on the base shelf as this could result in serious injury to the user, other people and/or property.
- Page 6 Safety and Care Advice (Gas BBQ) Operation Warning • Before proceeding, make certain that you understand the IMPORTANT INFORMATION section of this manual. • Your barbecue is not designed to be used with more than 50% of the cooking area as a solid plate —...
- Page 7 Safety and Care Advice (Gas BBQ) Grill Cooking The burners heat up the flame tamer underneath the grill, which in turn heats the food on the grill. The natural food juices produced during cooking fall onto the hot flame tamer below and vaporise. The sub- sequent rising smoke bastes the food, as it travels upwards, imparting that unique barbecued flavor.
- Page 8 Safety and Care Advice (Gas BBQ) Care and Maintenance Regularly clean your barbecue between uses and especially after extended periods of storage. Ensure the barbecue and its components are sufficiently cool before cleaning. Do not leave the barbecue ex- posed to outside weather conditions or stored in damp, moist areas. Never douse the barbecue with water when its surfaces are hot.
- Page 9 Safety and Care Advice (Gas BBQ) Drip Tray After every use, empty and clean the drip tray of any fat or food particles, using a plastic or wooden scraper if necessary. Failure to keep it clean, and excessive build up can result in a fat fire. This can be hazardous and se- verely damage the barbecue.
- Page 10 Safety and Care Advice (Gas BBQ) Fixings All screws and bolts, etc. should be checked and tightened on a regular basis. Storage Ensure the barbecue is properly cooled before covering or storing. Store your barbecue in a cool dry place. It must be inspected on a regular basis as damp or condensation can form which may result in damage to the barbecue.
-
Page 11: Components - Parts
If you have damaged or missing components, Components - Parts call the Customer Helpline: 03456 400800 Please check you have all the panels listed below Side table panel x1 Side table Assembly x1 Grease Cup x1 Wheel x2 Control Panel Assembly x1 Left rear Left front Bottom Shelf x1... - Page 12 Components - Parts Please check you have all the panels listed below Charcoal Tray Windscreen x1 Burner w/o Ignition x1 Burner with Supporting Bracket x2 Ignition x1 Side Shelf Handle x1 Burner Heat Tent x2 Charcoal Tray Assembly x1 Cooking Grill x4 Lid Handle x2 Hinge x4 Warming Rack x2...
- Page 13 Components - Fittings Please check you have all the panels listed below The quantities below are the correct amount to complete the assembly. Note 12mm Bolt x 70 8mm Bolt x 3 15mm Bolt x 4 15mm Bolt x 2 12mm Shoulder bolt x 4 10mm Bolt x 2 35mm Bolt x 4...
- Page 14 Assembly Instructions Step 1 Fix the Left front leg Left rear leg on the Grill cabinet assembly using 12mm bolts FRONT Step 2 Fix the Right front leg Right rear leg on the Grill cabinet assembly using 12mm bolts FRONT...
- Page 15 Assembly Instructions Step 3 Fix the Cart front/rear bracket to the legs using 12mm bolts FRONT Step 4 Fix the bottom shelf to the Right front leg Right rear Left front leg Left rear leg using 12mm bolts FRONT...
- Page 16 Assembly Instructions Step 5 Fix the Cart right bracket on the Right front leg Right rear leg using 12mm bolts Fix the bolts tightly by the screwdriver. Step 6 Apply the wheels to the Left front leg and Left rear leg using the Axle Then fix the Axle By the R...
- Page 17 Assembly Instructions Step 7 Put the Cart Left bracket to the left front leg Left rear leg using 12mm bolts Step 8 Put the burners in the fire- bowl. The Burner with igniton MUST be installed on the right opening. Fix the burners with R pin...
- Page 18 Assembly Instructions Step 9 Fix the Fire cross-over tube on the burners using 8mm Tapping screws Step 10 Put the ignition wire on the burner into the igniter on the Control panel assembly...
- Page 19 Assembly Instructions Step 11 A: Put the Control panel as- sembly on the Grill cabi- net assembly using 12mm bolts B: Make sure the tip of the valve is completely inside the burner venturi. Step 12 Put the Condiment tray on the Grill cabinet assembly using 12mm bolts...
- Page 20 Assembly Instructions Step 13 Fix the Middle division plate into the Grill cabinet as- sembly using 15mm bolt and 10mm bolt Flange Step 14 Fix the Damper to the right side of the cabinet using 12mm shoulder bolts M5 nuts...
- Page 21 Assembly Instructions Step 15 Fix the Damper handle on the Damper Step 16 Place the Charcoal tray sup- porting brackets to the Charcoal cabinet assembly using 12mm bolts...
- Page 22 Assembly Instructions Step 17 Fix the Side table panel the Side table assembly using 8mm Tapping screws Step 18 Fix the Side table assembly on the Grill cabinet assembly using 12mm bolts...
- Page 23 Assembly Instructions Step 19 Fix the Side shelf handle on the Grill cabinet assembly and Right front leg Right rear leg using 12mm bolts Step 20 Loose the nut and washer from Temperature gauge and fix it on the Gas grill lid Fix Lid handle and Heat shield...
- Page 24 Assembly Instructions Step 21 Fix Chimney on the lid of the charcoal grill using 12mm bolts and M6 nut Fix the Chimney lid the Chimney using Spring and M6 cap nut Step 22 Loose the nut and washer from Temperature gauge and fix it on the Charcoal grill Fix Lid handle on the...
- Page 25 Assembly Instructions Step 23 Fix the Hinge on the Gas grill and Charcoal grill using 12mm bolts Step 24 Fix the Windscreen on the Hinge using 8mm Tapping screws...
- Page 26 Assembly Instructions Step 25 Insert the Grease cup wire hook through the grease drain hole on the bottom of the cabinet. Place the Grease cup into the wire hook. Step 26 Place the charcoal tray assembly onto the char- coal tray supporting brackets of the grill assembly.
- Page 27 Assembly Instructions Step 27 Fix the Warming rack the Gas grill and Charcoal grill using 35mm bolts Step 28 Please the Heat tent in the firebowl of the Gas grill.
- Page 28 Assembly Instructions Step 29 Put the Cooking grill in the Grill cabinet assembly. Step 30 Assembly is complete. ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE Do not forget to do the leak test. BARBECUE. Leak test annually, and whenever the gas bottle is removed or replaced.
-
Page 29: Technical Specification
Shopping Centre, Upper Galwally, Belfast, United Kingdom, BT8 6FX. Argos Limited, 489-499 Avebury Boulevard, Milton Keynes MK9 2NW. Argos (N.I.) Ltd, Forestside Shopping Centre, Upper Galwally, Belfast, United Kingdom, BT8 6FX. Argos Distributors (Ireland) Limited, Unit 7, Ashbourne Retail Park, Ballybin Road, Ashbourne, County... -
Page 30: Troubleshooting
Shopping Centre, Upper Galwally, Belfast, United Kingdom, BT8 6FX. Argos Limited, 489-499 Avebury Boulevard, Milton Keynes MK9 2NW. Argos (N.I.) Ltd, Forestside Shopping Centre, Upper Galwally, Belfast, United Kingdom, BT8 6FX. Argos Distributors (Ireland) Limited, Unit 7, Ashbourne Retail Park, Ballybin Road, Ashbourne, County...
