V-ZUG-Home
Install the app, network your appliances and
benefit from a wide range of useful functions.
Operating instructions
AdoraDry V2000
Tumble dryer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AdoraDry V2000 and is the answer not in the manual?

Questions and answers

Related Manuals for V-ZUG AdoraDry V2000

Summary of Contents for V-ZUG AdoraDry V2000

  • Page 1 V-ZUG-Home Install the app, network your appliances and benefit from a wide range of useful functions. Operating instructions AdoraDry V2000 Tumble dryer...
  • Page 2 Validity These operating instructions apply to: Model designation Type AdoraDry V2000 AT2T-12031 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2025...

  • Page 3: Table Of Contents

    Timed drying ............ 11 8.10 Childproof lock ............  23 Textile programmes.......... 11 8.11 Drum illumination .......... 23 Extra programmes .......... 11 8.12 V-ZUG-Home............ 23 Additional functions .......... 12 8.13 Factory settings ...........  24 EcoManagement .......... 12 Demo mode  24 Operation  13...
  • Page 4 13.4 Product fiche............ 34 Drying tips  34 14.1 Saving energy ............ 34 14.2 Avoiding damage.......... 35 Disposal  35 Index  37 Service & Support  39...

  • Page 5: Safety Warnings

    Safety warnings Symbols used and have understood the haz- ards involved. Children shall Denotes important safety precau- tions. not play with the appliance. Failure to observe said precautions Cleaning and user mainten- can result in injury or in damage to ance shall not be undertaken the appliance or fittings! by children without supervi-...
  • Page 6 1 Safety warnings or heat sources such as burn- ▪ Textiles that have been ing candles, incense sticks, cleaned, treated or soaked room heaters and the like with flammable chemicals, away from the appliance. detergents or solvents (such as white spirit, alcohol, stain remover, oil, edible oil, tur- ▪...

  • Page 7: Instructions For Use

    1 Safety warnings ▪ Ensure access to the place of discon- ▪ Exhaust air must not be dis- nection (e.g. socket outlet, wall switch, charged into a flue which is fuse) and the water tap. used for exhausting fumes Correct use from appliances burning gas ▪...
  • Page 8 1 Safety warnings ▪ As a general rule, rooms containing Caution: Risk of burns! heat pump dryers should be ventilated ▪ Do not dry fabrics that contain traces of as these produce a small amount of hair spray, hair gel, nail varnish remover moisture.

  • Page 9: Initial Set-Up

    Initial set-up The appliance must be installed and connected to the electricity supply in accord- ance with the separate installation instructions. Have a qualified fitter/electrician carry out the necessary work. If the location of the appliance is changed, because of the heat pump it must stand in its final position for around 2 hours before it can be operated again.

  • Page 10: Indicator Lights

    3 Appliance description Coloureds Select programme Operating panel V-ZUG-Home display Indicator light TouchDisplay Operating panel buttons TouchDisplay buttons EcoManagement Textile programmes Extra programmes Extra dry Start/Pause/Drum illumination Cupboard dry End of programme Iron dry Favourites Damp Timed drying Cottons eco...

  • Page 11: Programme Overview

    4 Programme overview Programme overview Automatic programmes Programme Description Load Extra dry For thick, multi-layered textiles and mixed loads. 1–7 kg Less suitable for knitted or woven articles (e.g. t- shirts or underwear). Cupboard dry For similar items of washing (e.g. t-shirts or under- 1–7 kg wear).

  • Page 12: Additional Functions

    4 Programme overview Programme Description Load Basket programme For drying clean canvas shoes/trainers and small items such as gloves, hats and soft toys in the basket (can be ordered as an accessory). Not suit- able for leather or synthetic leather. Airing For refreshing or airing little-worn garments.

  • Page 13: Operation

    5 Operation Operation Preparations ▸ Insert the mains plug into a mains socket. ▸ Press the 5 dots at the edge of the appliance door. – The appliance door opens. – The drum illumination switches on. ▸ Loosely load wet laundry items one by one into the appliance.

  • Page 14: Selecting Additional Functions

    5 Operation Timed drying ▸ Touch the button. Timed drying – A selection of drying times appears in the Duration in minutes TouchDisplay. ▸ Select the desired drying time, e.g. 30. – The programme selected and all selectable ad- ditional functions appear in the TouchDisplay. ▸...

  • Page 15: Setting A Delayed Start

    5 Operation Setting a delayed start ▸ Touch the button in the Additional functions Delayed start menu. 0 1 4 3 – The input field for the time delay to the start of the programme appears in the TouchDisplay. ▸ Enter the desired time delay to the start of the programme.

  • Page 16: Drying Phases

    5 Operation Drying phases The drying process has 3 phases: ▪ Drying: The laundry is dried as per the settings (programme selection and user set- tings). ▪ Cooling down / Final airing: The laundry is cooled down to a temperature at which the risk of creasing is minimized.

  • Page 17: With Childproof Lock Activated

    5 Operation 5.11 With childproof lock activated The «Childproof lock» user setting must be activated to use the childproof lock (see page 23). When the childproof lock is activated, the appliance can no longer be operated once a programme has started or if no button has been touched for over 20 seconds. A code must be entered to unlock the appliance.

  • Page 18: Ecomanagement

    5 Operation ▸ Press the 5 dots at the edge of the appliance door. – The appliance door opens. – The drum illumination switches on. – All the displays go out. ▸ Unload the laundry. Each time after use ▸ Clean the door filter. ▸...

  • Page 19: Favourites

    6 Favourites Displaying total and average consumption Total and average consumption can be displayed if no programme is running. ▸ Hold the button depressed for 3 seconds. EcoManagement – Total and average consumption appear in the Statistics TouchDisplay. Total 390 kWh ▸...

  • Page 20: Changing Or Clearing Favourites

    6 Favourites Changing or clearing favourites ▸ Press the 5 dots at the edge of the appliance door. – The appliance door opens. ▸ Touch the button. – The Favourite programmes menu appears in the TouchDisplay. ▸ Touch the favourite programme to be changed, Coloureds e.g.

  • Page 21: Zug-Home

    – A 6-digit PIN appears in the display of the household appliance. ▸ Enter the 6-digit PIN in the V-ZUG App and confirm the bluetooth pairing request. – The name of the active WLAN/Wi-Fi appears in the V-ZUG App and then you are prompted to enter the WLAN/Wi-Fi password.

  • Page 22: User Settings

    8 User settings User settings Providing no programme is running and no error messages are displayed, the user settings can be changed. Changing the user settings ▸ Close the appliance door. Extra ▸ Touch the button. – The selection of extra programmes appears in Cottons eco Basket the TouchDisplay.

  • Page 23: Level Of Dryness

    ▪ switch off a running appliance ▪ call up the status of your household appliances. When the network connection is activated, energy consumption in the standby mode is increased. Further information on V-ZUG-Home and its availability can be found at vzug.com.

  • Page 24: Factory Settings

    9 Demo mode 8.13 Factory settings The factory settings can be restored. The language if ▪ : Restore changed is not reset to the factory setting. ▪ : Do not restore Saved favourites are also cleared when factory settings are restored. Demo mode In the demo mode, almost all the appliance functions are available but it is not possible to dry with the appliance.

  • Page 25: Care And Maintenance

    10 Care and maintenance Care and maintenance A thick coating of fluff can trigger the «A9 Clean filter» (see page 28) error message. Fluff filters if not cleaned properly block the air flow. This results in a longer programme duration and higher energy consumption. 10.1 Cleaning intervals Appliance part...

  • Page 26: Cleaning The Front Filter

    10 Care and maintenance Cleaning the door filter mat ▸ Take out the door filter 1 and clean as described in «Cleaning the door filter». ▸ Open the door filter 1 and take out the door filter mat 2. ▸ Without using water, remove the fluff and deposits and dispose of in the waste bin.

  • Page 27: Cleaning The Moisture Sensor

    10 Care and maintenance ▸ Carefully lift up and remove the inner grille 4 from the back of the front filter 3. ▸ Take out the front filter mat 5, remove the fluff and deposits without using water and dispose of in the waste bin.

  • Page 28: Cleaning The Temperature Sensor

    11 Trouble-shooting 10.5 Cleaning the temperature sensor Carefully clean the temperature sensor! ▸ Open the appliance door and remove the front grille 1. ▸ Clean the temperature sensor 2 with a damp cloth. ▸ Put back the front grille 1. 10.6 Cleaning the appliance ▸...
  • Page 29 11 Trouble-shooting Display Possible cause Solution A9 Clean mats ▪ Door filter, door filter ▸ Check and clean door filter and door fil- mat and/or front filter ter mat. are clogged. ▸ Check and clean the front filter. ▸ Press the button.

  • Page 30: Other Possible Problems

    11 Trouble-shooting 11.2 Other possible problems Problem Possible cause Solution The programme ▪ Door filter and/or ▸ Clean door filter and/or door filter mat. takes signific- door filter mat are antly longer blocked. than indicated. ▪ Front filter is clogged. ▸ Clean the front filter. ▪...
  • Page 31 11 Trouble-shooting Problem Possible cause Solution The progress of ▪ The laundry is being ▸ No action is necessary. The laundry can the programme cooled down. be unloaded at any time as long as it is remains frozen ▪ A high ambient tem- then spread out to cool down.

  • Page 32: Spare Parts

    Front grille V-ZUG Ltd provides spare parts for 15 years after the making available on the market of the last appliance with this type designation. Deviations from this are subject to consider- ation of and compliance with the applicable ecodesign regulations on the availability of spare parts.

  • Page 33: Light Sources

    13 Technical data 13.1 Light sources Light sources may only be replaced by a service technician. This product contains a light source of energy efficiency class E. 13.2 Note for testing institutes ▸ The appliance must be connected to the electricity supply for at least 5 minutes be- fore taking measurements.

  • Page 34: Product Fiche

    14 Drying tips Programmes Fabric type [kg] [h:min] [kWh/cycle] [dB(A)] Iron dry Synthetic or 0h38 0.28 8 to 16 + Easy care mixed fabrics Damp Cottons 1h35 0.79 20 to 30 Shirts Shirts 0h40 0 to 2 Denim Denim 1h50 0.93 -1 to 2 Silks...

  • Page 35: Avoiding Damage

    15 Disposal 14.2 Avoiding damage ▪ Follow the fabric care symbols on garment labels. ▪ For drying, it is recommended that tumble dryer sheets or other fabric care solutions not be used. ▪ Remove foreign objects and larger parts made of metal or hard plastic (e.g. buckles, stones, detergent dosing aids) before tumble drying.
  • Page 36 989 Siam Piwat Tower, 12 A Floor, London W1U 1PN TT25, GREAT BRITAIN Rama1 Road, Pathumwan Pathumwan, Bangkok 10330 THAILAND HK/MO V-ZUG Hong Kong Co. Ltd. GÜRELLER 12/F, 8 Russell Street Anchor Sit.3A/1-2 Çayyolu Causeway Bay 06690 ÇANKAYA/ANKARA HONG KONG TURKEY Frigo 2000 S.p.A...
  • Page 37 Index Extra programmes ........... 10 Starting ...........  14, 22 Additional functions ......... 12 Starting............ 14 Addresses of the importers ......36 Factory settings..........24 Airing Favourites............10 Extra programmes........ 12 Starting ............ 20 Appliance Final airing............31 Disposal............ 35 Automatic programmes ........10 Consumption values ........
  • Page 38 Shirts ..............  11 Silks.............. 11 Type............... 2 Underwear Cupboard dry .......... 11 Using for the first time........9 Validity..............2 Viewing angle ........... 22 V-ZUG App ............21 V-ZUG-Home............. 21 Switching on mode........ 23 Warranty extensions ........39 WLAN connection ..........21...

  • Page 39: Service And Support

    V‑ZUG service centre. Technical questions, accessories, warranty extensions V-ZUG is happy to help you with any general administrative or technical queries, to take your orders for accessories and spare parts and to inform you about our progressive service agreements.

  • Page 40: Quick Instructions

    ▸ Close the appliance door. ▸ Select programme and any additional functions (if required). ▸ Press the button. The programme starts. 1284420-02 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
