V-ZUG AdoraDry V4000 Operating Instructions Manual

Hide thumbs Also See for AdoraDry V4000:

Operating instructions manual (20 pages)

page of 44

/ 44
Bookmarks

Quick Links

Download this manual

V-ZUG-Home

Install the app, network your appliances and

beneﬁt from a wide range of useful functions.

Operating instructions

AdoraDry V4000 | V6000

Tumble dryer

Need help?

Do you have a question about the AdoraDry V4000 and is the answer not in the manual?

Questions and answers

Summary of Contents for V-ZUG AdoraDry V4000

Page 1 V-ZUG-Home Install the app, network your appliances and beneﬁt from a wide range of useful functions. Operating instructions AdoraDry V4000 | V6000 Tumble dryer...
Page 2 Validity These operating instructions apply to: Model designation Type AdoraDry V4000 AT4T-12032 AdoraDry V6000 AT6T-12033 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2025...
Page 3 Childproof lock ............ 25 Textile programmes.......... 12 8.11 Drum illumination .......... 25 Extra programmes .......... 13 8.12 Standard mode............ 25 Additional functions .......... 14 8.13 V-ZUG-Home............ 25 EcoManagement .......... 14 8.14 Factory settings ........... 26 Operation 15 Demo mode 26 Preparations ............ 15 Switching on............
Page 4 13.3 Consumption values........... 35 13.4 Product fiche............ 36 Drying tips 37 14.1 Saving energy ............ 37 14.2 Avoiding damage.......... 37 V-Upgrade 38 Disposal 38 Index 40 Notes 42 Service & Support 43...
Page 5 Safety warnings Symbols used and have understood the haz- ards involved. Children shall Denotes important safety precau- tions. not play with the appliance. Failure to observe said precautions Cleaning and user mainten- can result in injury or in damage to ance shall not be undertaken the appliance or fittings! by children without supervi-...
Page 6 1 Safety warnings or heat sources such as burn- ▪ Textiles that have been ing candles, incense sticks, cleaned, treated or soaked room heaters and the like with flammable chemicals, away from the appliance. detergents or solvents (such as white spirit, alcohol, stain remover, oil, edible oil, tur- ▪...
Page 7 3) is switched by a CoinSystem 1 or CoinSystem 2 cashier system from V-ZUG Ltd into which you have inser- ted sufficient money for the drying programme you have selected to finish, or 4) is...
Page 8 1 Safety warnings Services and support Caution: Risk to life! ▪ If the appliance is not working properly ▪ Packaging material, e.g. plastic film and or in case a repair is needed, follow the polystyrene, can be dangerous for chil- instructions given in the «Service &...
Page 9 1 Safety warnings Transport and installation Front Tilt max. 90° to the left! ▪ Transport the appliance in an upright position only! Transporting it in any other position will result in damage to the appliance! When carried carefully without being shaken, the appliance may be tilted a maximum of 90°...
Page 10 Initial set-up The appliance must be installed and connected to the electricity supply in accord- ance with the separate installation instructions. Have a qualified fitter/electrician carry out the necessary work. If the location of the appliance is changed, because of the heat pump it must stand in its final position for around 2 hours before it can be operated again.
Page 11 3 Appliance description Operating and display elements Operating panel Coloureds Select programme Operating panel V-ZUG-Home display Indicator light TouchDisplay Operating panel buttons TouchDisplay buttons Door opener Textile programmes EcoManagement Extra dry Energy saving Cupboard dry Extra programmes Iron dry Start/Pause/Drum illumination...
Page 12 4 Programme overview Button state Activity Symbol colour State Blue White Function is active. Black White Function is selectable. Black Black Function is not selectable. Programme overview Automatic programmes Programme Description Load Extra dry For thick, multi-layered textiles and mixed loads. 1–7 kg Less suitable for knitted or woven articles (e.g.
Page 13 4 Programme overview Programme Description Load Bed linen For similar items of washing. Fasten zips and but- 1–3 kg tons. Thick down filling For bulky down textiles (e.g. pillows, jackets and 1–2 kg thick duvets). If recommended, tennis balls can be used for fluffing up the down during drying. Op- timum load: 1 item Thin down filling For light-weight down textiles (e.g.
Page 14 4 Programme overview Additional functions Whenever a programme is selected, the selectable additional functions are displayed. Additional function Description Load Easy care Gentle drying for mixed fabrics (e.g. shirts, 1–2.5 kg pullovers and t-shirts). The level of dryness is re- duced. To prevent creasing, put only a few items of laundry in the washing drum and unload them as soon as the programme ends.
Page 15 5 Operation Operation Preparations ▸ Insert the mains plug into a mains socket. ▸ Touch the button. – The appliance door opens. – The drum illumination switches on. ▸ Loosely load wet laundry items one by one into the appliance. ▸...
Page 16 5 Operation Timed drying ▸ Touch the button. Timed drying – A selection of drying times appears in the Duration in minutes TouchDisplay. ▸ Select the desired drying time, e.g. 30. – The programme selected and all selectable ad- ditional functions appear in the TouchDisplay. ▸...
Page 17 5 Operation Selecting additional functions ▸ Touch the button for the desired programme, e.g. 2 h 25 Extra dry – The programme selected and all selectable ad- ditional functions appear in the TouchDisplay. – Depending on the model, the indicator light for the selectable button flashes.
Page 18 5 Operation Duration remaining indicator When the programme starts, the programme dura- Extra dry tion at maximum load is displayed. The actual load 0 h 59 is determined and the expected duration remaining Calculating time remaining is calculated, which takes about 1 minute. The letter «h»...
Page 19 5 Operation Interrupting a programme ▸ Touch the button. Extra dry – In the TouchDisplay appears: «Pause – Con- Pause tinue with button » Continue with button ▸ Touch the button again. – The programme is resumed. Each time a programme is interrupted, the programme sequence is delayed by 5 minutes.
Page 20 5 Operation 5.13 End of programme Unloading the laundry When the programme has finished, – the indicator light for the button flashes. – the following appears in the TouchDisplay: «0h00» – information on the energy consumption (see page 21) appears in the TouchDisplay, provided «EcoManagement»...
Page 21 6 Favourites Displaying last programme The energy consumption of the last programme can be displayed if no programme is running. ▸ Touch the button. Last programme – The energy consumption of the last pro- gramme appears in the TouchDisplay. ▸ Touch the button to end statistic retrieval.
Page 22 6 Favourites Changing or clearing favourites ▸ Touch the button. Coloureds – The appliance door opens. ▸ Touch the button. – The Favourite programmes menu appears in the TouchDisplay. Change Clear ▸ Touch the favourite programme to be changed, e.g. –...
Page 23 – A 6-digit PIN appears in the display of the household appliance. ▸ Enter the 6-digit PIN in the V-ZUG App and confirm the bluetooth pairing request. – The name of the active WLAN/Wi-Fi appears in the V-ZUG App and then you are prompted to enter the WLAN/Wi-Fi password.
Page 24 8 User settings User settings Providing no programme is running and no error messages are displayed, the user settings can be changed. Changing the user settings ▸ Close the appliance door. Extra ▸ Touch the button. – The selection of extra programmes appears in Cottons eco Basket the TouchDisplay.
Page 25 8.13 V-ZUG-Home With V-ZUG-Home (see page 23), you can access ▪ Operate and display your appliances over the V-ZUG App to, for instance ▪ Display ▪ Off (factory setting) ▪ switch off a running appliance ▪ call up the status of your household appliances.
Page 26 9 Demo mode When the network connection is activated, energy consumption in the standby mode is increased. Further information on V-ZUG-Home and its availability can be found at vzug.com. 8.14 Factory settings The factory settings can be restored. The language if ▪...
Page 27 10 Care and maintenance Care and maintenance A thick coating of fluff can trigger the «A9 Clean filter» (see page 30) error message. Fluff filters if not cleaned properly block the air flow. This results in a longer programme duration and higher energy consumption. 10.1 Cleaning intervals Appliance part...
Page 28 10 Care and maintenance Cleaning the door filter mat ▸ Take out the door filter 1 and clean as described in «Cleaning the door filter». ▸ Open the door filter 1 and take out the door filter mat 2. ▸ Without using water, remove the fluff and deposits and dispose of in the waste bin.
Page 29 10 Care and maintenance ▸ Carefully lift up and remove the inner grille 4 from the back of the front filter 3. ▸ Take out the front filter mat 5, remove the fluff and deposits without using water and dispose of in the waste bin.
Page 30 11 Trouble-shooting 10.5 Cleaning the temperature sensor Carefully clean the temperature sensor! ▸ Open the appliance door and remove the front grille 1. ▸ Clean the temperature sensor 2 with a damp cloth. ▸ Put back the front grille 1. 10.6 Cleaning the appliance ▸...
Page 31 11 Trouble-shooting Display Possible cause Solution A9 Clean mats ▪ Door filter, door filter ▸ Check and clean door filter and door fil- mat and/or front filter ter mat. are clogged. ▸ Check and clean the front filter. ▸ Press the button.
Page 32 11 Trouble-shooting 11.2 Other possible problems Problem Possible cause Solution The programme ▪ Door filter and/or ▸ Clean door filter and/or door filter mat. takes signific- door filter mat are antly longer blocked. than indicated. ▪ Front filter is clogged. ▸ Clean the front filter. ▪...
Page 33 11 Trouble-shooting Problem Possible cause Solution The progress of ▪ The laundry is being ▸ No action is necessary. The laundry can the programme cooled down. be unloaded at any time as long as it is remains frozen ▪ A high ambient tem- then spread out to cool down.
Page 34 Front grille V-ZUG Ltd provides spare parts for 15 years after the making available on the market of the last appliance with this type designation. Deviations from this are subject to consider- ation of and compliance with the applicable ecodesign regulations on the availability of spare parts.
Page 35 13 Technical data 13.1 Light sources Light sources may only be replaced by a service technician. This product contains a light source of energy efficiency class E. 13.2 Note for testing institutes ▸ The appliance must be connected to the electricity supply for at least 5 minutes be- fore taking measurements.
Page 36 13 Technical data Programmes Fabric type [kg] [h:min] [kWh/cycle] [dB(A)] Iron dry Synthetic or 0h31 0.27 8 to 16 + Easy care mixed fabrics Damp Cottons 1h22 0.81 20 to 30 Shirts Shirts 0h35 0.29 0 to 2 Denim Denim 1h42 0.99 -1 to 2...
Page 37 14 Drying tips Warranty claim The manufacturer’s warranty is valid for 24 months starting from when the appliance is first put into service. Drying tips 14.1 Saving energy ▪ Spin the washing in the washing machine at a high spin speed before tumble drying. Mechanical draining in the washing machine is much more efficient than water evapor- ation in the tumble dryer.
Page 38 15 V-Upgrade V-Upgrade The following programmes and functions can be obtained subsequently from V-ZUG- Home (see page 23). More information can be found at www.vzug.com. After successful installation or modification of V-Upgrade on the appliance, the following appears in the TouchDisplay: «V-Upgrade was updated. The appliance is restarting.»...
Page 39 16 Disposal 16.3 Disposal The «crossed‐out wheeled bin» symbol requires the separate collection of waste ▪ electrical and electronic equipment (WEEE). Such equipment can contain hazardous, environmentally harmful materials. ▪ These appliances are to be handed over to a designated collection point for the recyc- ling of electrical and electronic equipment and must not be disposed of with unsorted household waste.
Page 40 Index Switching on .......... 25 Efficient drying Additional functions ......... 14 Cottons eco ........... 12, 13 Starting............ 17 Ending Airing Programme ........... 19 Extra programmes........ 13 Energy saving..........11, 14 Appliance Energy-efficient drying Disposal............ 39 Delayed start .......... 14 Automatic programmes ........11 Even drying Consumption values ........
Page 41 Safety precautions Validity..............2 General ............. 5 Viewing angle ........... 24 Safety warnings V-Upgrade ............38 Appliance-specific .......... 6 V-ZUG App............23 Saving energy........... 37 V-ZUG-Home............. 23 EcoManagement.......... 14 Switching on mode ........ 25 Service & Support..........43 Service agreement........... 43 Shirts WetClean finish ..........
Page 42 Notes...
Page 43 Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
Page 44 ▸ Close the appliance door. ▸ Select programme and any additional functions (if required). ▸ Press the button. The programme starts. 1284408-01 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
