- Page 1 2000 Series Awning OEM INSTALLATION MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction Safety Prior to Installation Resources Required Installation Awning Rail Installation (If Needed) Awning Installation Securing the Fabric Option 1 Option 2 Solera Serenity LED Lights Installation - Optional Seal Wall Penetrations Awning Wiring Wiring Diagram Notes Introduction The Solera®... -
Page 3: Safety
Lippert limited warranty. The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause death or serious personal injury if not performed safely and within the parameters set forth in this manual. -
Page 4: Installation
Installation Awning Rail Installation (If Needed) NOTE: Awning rail not included. NOTE: Before installing the awning rail, measure the opening to make sure that the opening is no larger 3/16 than " (Fig. 1A). An opening that is too large could lead to fabric detachment from the unit. Fig. -
Page 5: Awning Installation
Awning Installation On the awning rail, mark the position of the centerlines of the support arm assemblies. Make sure that the support arm assemblies will not interfere with any lights, vents or other obstructions. Using a non-permanent method of marking, mark a perpendicular line from the awning rail down to the floor line. - Page 6 Use a screwdriver to spread open either end of the awning rail channel (Fig. 5A). See Awning Rail Installation on page 4 for measurement procedure to ensure awning rail channel opening is not too large. To protect the fabric from damage during installation, file any sharp edges or burrs from the awning rail channel (Fig.
- Page 7 3/16 NOTE: Three rivets with " grip range can be used in place of the two middle and one lower screws for laminated walls. 10. Repeat step 9 for the other side. 11. Cut the zip ties and connect the wires from the drive head assembly to a drill battery and run the awning half way out.
-
Page 8: Securing The Fabric
Securing the Fabric Secure the fabric with to the awning rail using ONE of the two options listed below. In option 1 the screw will go through the fabric, awning rail, and polycord, while in option 2, the screw will only go through the awning rail and polycord. -
Page 9: Solera Serenity Led Lights Installation - Optional
Solera Serenity LED Lights Installation - Optional The Solera Serenity LED Lights (Fig. 10A) come pre-installed on specifically-fitted support arms. Installation also requires the proper fabric with an LED wire welded into the fabric at the base. The Edge Awning with Serenity must be installed prior to wiring the Solera Serenity LED lights. -
Page 10: Awning Wiring
30 seconds to reset. Lippert recommends the awning be wired with a 15A auto-reset circuit protector. If the circuit protector trips, it will take approximately 30 seconds to reset. All wire shall be 14 AWG or higher as necessary to provide 11.5V minimum at all times to the Lippert-supplied power cable connection. -
Page 11: Notes
Notes Page 11 Rev: 06.05.25 CCD-0002685... - Page 12 The contents of this manual are proprietary and copyright protected by Lippert. Lippert prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized Lippert representative has been provided. Any unauthorized use shall void any applicable warranty. The information contained in this manual is subject to change without notice and at the sole discretion of Lippert. ...
