- Page 1 1000 Series Manual Awning OWNER'S MANUAL Scan for Product Support...
-
Page 2: Table Of Contents
Notes Introduction The Solera 1000 Series Manual Awning is designed for use on most recreational vehicles and is available in a variety of sizes to fit even the largest unit. Additional information about this product can be obtained from lci1.com/support or by downloading the free LippertNOW app in Apple App Store®... -
Page 3: Operation
operation During incidents of high wind, heavy rain or extended time away from the unit, it is advisable to retract the awing completely to prevent damage to the awning and the RV. Extending the Awning Release the travel locks. A. Press slightly upward on the tab (Fig.1A) on the travel lock base latch (Fig. 1D) to release the travel lock body (Fig. -
Page 4: Extending Optional Car Port
Slide the bottom of the support arms (Fig. 2D) all the way to the top of the outer arm (Fig. 2E) and make sure they lock into place at the top of the outer arm (Fig. 3A). Note: Once spring clip (Fig. 3B) appears in the slot (Fig. 3A) the arm is locked. Pull the two arms away from each other until the fabric is taut and then tighten the knob. -
Page 5: Retracting The Awning
Retracting the Awning If the awning is in car port mode, remove the stakes from the foot of the outer arm (Fig. 6D). Walk the outer arm back to the unit and secure it into the lower mounting bracket on the sidewall by pushing the lever (Fig. -
Page 6: Troubleshooting
troubleshooting What is happening? Why it's happening What should be done? Cam lock engaged. Check position of the cam lock (roll out). Make sure that the travel locks have been released from the Travel locks engaged. outer arm. Rafter arm(s) locking knob(s) Awning will not extend. -
Page 7: Maintenance
Maintenance Resources Required • 5 gallon bucket • cup dish soap • Clean water • Bristle brush with sufficient reach Fabric Care over-spray of cleaning solution can cause eye and sensitive skin irritation. Flush affected area with clean water and seek medical attention, if necessary. Wear eye protection and appropriate protective clothing to avoid personal injury. - Page 8 Lippert representative has been provided. Any unauthorized use shall void any applicable warranty. The information contained in this manual is subject to change without notice and at the sole discretion of Lippert. Revised editions are available for free download from lippert.com.
