- Page 1 GG500 Awning For Towable and Motorized OEM INSTALLATION MANUAL...
-
Page 2: Table Of Contents
Failure to correctly follow the provided instructions may result in death, serious personal injury, severe product and/or property damage, including voiding of the Lippert limited warranty. The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause death or serious personal injury if not performed safely and within the parameters set forth in this manual. -
Page 3: Resources Required
The “CAUTION” symbol above is a sign that a safety risk is involved and may cause personal injury and/or product or property damage if not safely adhered to and within the parameters set forth in this manual. This product is to be used only for shade, not for sheltering from bad weather. To prevent damage to the awning, close the awning in bad weather including high winds and heavy rain or snow. - Page 4 Remove brackets from the awning and place the outer brackets on the unit. Make sure the brackets are level with each other and then mark the locations for the bracket's lag bolts based on the measurement. NOTE: The bottom of the wall brackets must be at least 10' 2" (3 m 100 cm) above the ground. NOTE: A spacer may be used to ensure the brackets are level under the unit's top rail.
-
Page 5: Awning Flap Installation
Awning Flap Installation Fig. 4 NOTE: Install the flap before the awning installation. Be sure flap channel (Fig. 4B) is clear of any debris. Insert the bulb side of the flap (Fig. 4A) into the channel. NOTE: Starting on either end is acceptable. Feed the flap completely through the channel to the opposite end. -
Page 6: Wiring Diagrams
Wiring Diagrams NOTE: Awnings are manufactured with wiring on both arms to permit either a right-hand or left-hand installation. Rocker Switch Wiring The rocker switch is wired according to Fig. 9. Fig. 9 Awning wiring diagram using rocker switch Motion Sensor and LED Connections A four-conductor power supply is featured on the next page. -
Page 7: Motor Controller Wiring
LED Cable Power Supply Cable Motion Sensor Cable Four Conductor Power Supply Motor Controller Wiring The motor controller is wired according to Fig. 10. NOTE: The larger 18 gauge red/black wire coming out of the control box is the incoming power. The smaller 22 gauge red/black wire is the LED outgoing power. -
Page 8: Programming The Motion Sensor
Programming the Motion Sensor NOTE: All electronic kits shipped from the factory are preprogrammed and do not require programming. This section is intended for reprogramming if required. Remove the two small Phillips screws which secure the motion sensor to the awning (Fig. 11). Turn sensor over. - Page 9 NOTE: When completing the next parts of the procedure, each step must be executed within 6 seconds of the previous one or the module will revert to factory settings. It is recommended that users read and understand the following sequence before attempting to complete it. Set the motion sensor adjustment dial to 0 (See Fig.
-
Page 10: Operation
Operation Use the switches to open and close the awning and to turn on and turn off the LED lights. NOTE: To prevent possible injury when opening awning, stand to the side of the awning, not in front of it. Manual Operation If the motor doesn't work, the awning can be closed manually. -
Page 11: Notes
Notes Page 11 Rev: 11.14.24 CCD-0008334... - Page 12 Lippert representative has been provided. Any unauthorized use shall void any applicable warranty. The information contained in this manual is subject to change without notice and at the sole discretion of Lippert. Revised editions are available for free download from lippert.com.
