Specifications

Model
SKU
Form factor SSI CEB (with ATX screw holes)
Dimensions 305mm(12" ) x 267mm(10.5" )
Single Intel® Xeon® 6700E-Series, 6500P-Series and 6700P-Series Processors,
Processor
TDP up to 350W
Socket 1 x Intel® LGA 4710 (Socket E2)
● 8 x DDR5 DIMM slots, 8 channels (1DPC), RDIMM/ MRDIMM*
- Max Frequency:
» RDIMM: 6400 MT/s
» MRDIMM: 8000 MT/s
Memory
- Max Capacity per DIMM:
» RDIMM: 256GB
» MRDIMM: 64GB
*MRDIMMs are only supported with Intel® Xeon® 6 P-core series processors.
● 2 x M.2 (M Key) slots
- Support 2280/22110 storage devices
- Support up to PCIe 5.0 x2 NVMe
Storage
● 3 x SlimSAS 4i connectors
- Support 12 SATA 3.0 (6Gb/s) drives
● 4 x PCIe 5.0 x16 slots
(1 slot only functional with R1S CPU)
Expansions
● 6 x PCIe 5.0 x8 MCIO 8i connectors
(4 connectors only functional with R1S CPU)
2 x 10G Base-T Ethernet ports
LAN
(Intel® X710AT2 with NCSI supported)
● 1 x M.2 (A-E Key) slot
Wireless LAN
- Supports 2230 Wi-Fi 6/7 module
RAID NVMe RAID 0/1/5/10 (Intel® VROC RAID key required)
Graphics 1 x VGA D-Sub 15-pin port (from the integrated AST2600 BMC)
● 3 x 3.5mm audio jacks
Audio
- Vertical stack: Line-in / Line-out /
Mic-in
● 1 x 20-pin USB 3.2 Gen 1 header (5 Gbps, internal, for 2 USB ports)
USB
● 2 x USB 3.2 Gen 1 Type-A ports (5 Gbps, rear)
D3060AGB2N-10G
Continued on next column
9
D3060
D3060GB2N-1G
2 x 1000Base-T Ethernet ports
(Intel® i210AT with NCSI supported)
