- Page 1 MONOBLOX INSTRUCTION FOR MOBILE PROJECTION SCREENS MONOBLOX 32 AND MONOBLOX 64...
- Page 2 FOLDABLE LEGS According to the size of the projection screen five different leg types are available VERTICAL MODULES Vertikal modules for Monoblox 64 By exchanging vertical modules of different length, the aspect ratio can be changed easily (4:3 - 16:9 - 16:10) WING SCREWS Thumb screws in yellow bag PROJECTION SCREEN BAG...
- Page 3 SOFTBAG WITH WHEELS padded , tearproof nylonbag with wheels and carrying straps small 128x25x30 cm big 133x31x35 cm HORIZONTAL FRAME ELEMENTS Compact transport volume due to patented snap joint technology Special extruded and hardened aluminum alloy allow maximum stability at minimum weight ASSEMBLY INSTRUCTION...
- Page 4 STANDARDS, REGULATIONS AND TECHNICAL SPECIFICATION ... 5 SAFETY ........................ 5 OPERATION, MAINTENANCE AND SERVICE ..........8 WARRANTY ......................9 MONOBLOX 64 .....................10 MONOBLOX 32 .....................12 FOLDABLE LEGS FOR VERTICAL ADJUSTMENT ........13 LEG TYPES .......................14 SURFACE MOUNTING ...................15 SET UP ......................16 DISMANTLING....................17...
- Page 5 BACK GENERAL STANDARDS, REGULATIONS AND TECHNICAL SPECIFICATION This projection screen is in accordance with the safety regulations in standard DIN 19045 and DIN 56950-4. The screen fabric is comply with DIN EN 13501-1 and/or DIN 4102 part 1 and the specifications of the according data sheet.
- Page 6 BACK SET UP-ASSEMBLY MECHANICAL HAZARDS Danger of injury due to improper assembly. Make sure all frame parts assembled correctly and all hinges and joints are locked before raising screen to standing position. Falling parts can cause severe injury or death! Projection surface damage in case of faulty assembly or set up.
- Page 7 BACK WARNING Mobile projection screens are developed for indoor use only. Failure to follow warning may result in personal injury due to unforeseen acts of nature. Any damage and consequential damage caused by outdoor use is not covered by warranty. BASIC SAFETY REQUIREMENTS Basic safety requirements for „flying“...
- Page 8 BACK OPERATION, MAINTENANCE AND SERVICE FRAME ELEMENTS, LEGS AND ACCESSORIES The frame elements, legs and additional elements are maintenance-free. PROJECTION SURFACE FOLDING Identical to the delivery condition, first halve and fold the surface with the projection side inwards on the shorter side to avoid soiling and damage to the surface.
- Page 9 BACK WARRANTY The warranty period for production deficiencies is 5 years for the frame elements and 24 months for the projection surface. Mobile projection screens are developed for indoor use only. Any damage and consequential damage caused by outdoor use is not covered by warranty. The general terms and conditions are available at www.AVstumpfl.com/agb LIMITATION OF LIABILITY All the details in this manual were compiled in consideration of the standards and legal regulations...
- Page 10 BACK MONOBLOX 64 The basic frame in System Monoblox 64 exists of 2 horizontal and 2 vertical frame elements, which have to be connected and screwed together with small wing screws. 1-7 Open the folded horizontal frame elements (top and bottom) and the snap joints engage automatically.
- Page 11 BACK 8-11 Open the corners and plug-in the vertical elements. 12 Simply change the aspect ratio by using vertical modules of different length (4:3 - 16:9 - 16:10) 13 The vertical modules have to be secured with two wing screws M8x15. 14 Engaging the shear joints ensures the maximum screen stability.
- Page 12 BACK MONOBLOX 32 1-7 Open the folded frame horizontally and the locking hinges quickly engage and lock automatically. Pull the frame apart and the vertical frame parts lock into place. Beware of pinch points!
- Page 13 BACK FOLDABLE LEGS FOR VERTICAL ADJUSTMENT The legs are foldable for compact transport volume. All profile elements are connected with snap joints or hinges inseparable. MOUNTING 1 First open the vertical elements of the legs (with holes). 2-3 The snap joints engage automatically. 4 To secure the legs by a single person, we recommend the use of set up supports.
- Page 14 When a high degree of stability is needed, especially with large screens or a high set-up height, we recommend using following legs: AT32 for MONOBLOX 32 and AT48 or AT64 for MONOBLOX 64. AT-Legs have a telescopic support that is tightened with two wing screws.
- Page 15 BACK SURFACE MOUNTING Lay out the surface on the frame with the label „OBEN-TOP“ corresponding with the upper frame bar. Press on the projection surface by starting at one corner and fasten the buttons one by one. Please mind the instructions for projection surfaces in chapter OPERATION, MAINTENANCE and SERVICE.
- Page 16 BACK SET UP 1 Lift the projection screen with one person at each of the top corners and put it up by supporting the screen along the vertical frame elements. To avoid mechanical overload and damage of the screen elements and legs with large screens or high set-up height, the screen has to be raised with an appropriate number of persons or rather by using hoisting devices.
- Page 17 BACK DISMANTLING Open the shear joints and telescopic leg supports with one person next to each of the foldable legs. Bring down the screen by supporting the screen along the legs and vertical frame elements towards the top corner edges. WARNING Beware of falling parts!
- Page 18 BACK ACCESSORIES ANTI-SWAY BRACE To increase the side-stability of the projection screen the in length variable Anti-Sway Brace has to be screwed on the leg and clamped to the basic frame. DRAPEKIT To drape a projection screen with decoration curtains. Depending on requirements, various frame parts can be used to attach the drapes Valance Bar (top drape), Wing Bar (left and right drape) and Skirt Bar (bottom drape - height...
- Page 19 BACK SET UP SUPPORT The optional available set up support allows an easy mounting of the legs. By means of the 4 round bar holders the wings screws can be bolted by one person only without holding the frame and leg in position. FLIGHT CASE As an option we offer sturdy, stackable transport cases with rollers for all mobile projection screens.
- Page 20 BACK AV Stumpfl GmbH A-4702 Wallern, Mitterweg 46 Tel.: +43 07249/42811 Fax: +43 07249/428114 AVstumpfl@AVstumpfl.com www.AVstumpfl.com Declaration of Conformity for product lines named as follows MONOBLOX 32 DECOFRAME MONOBLOX 64 FULLWHITE MONOCLIP 32 VARIO CURVE MONOCLIP 64 FULLWHITE CURVE MONOLYTE...
- Page 21 BACK AV Stumpfl GmbH A-4702 Wallern, Mitterweg 46 Tel.: +43 07249/42811 Fax: +43 07249/428114 AVstumpfl@AVstumpfl.com www.AVstumpfl.com Declaration of Conformity for product lines named as follows MONOBLOX 32 DECOFRAME MONOBLOX 64 FULLWHITE MONOCLIP 32 VARIO CURVE MONOCLIP 64 FULLWHITE CURVE MONOLYTE...
- Page 22 BACK AV Stumpfl GmbH | Mitterweg 46 | 4702 Wallern AVstumpfl@AVstumpfl.com | www.AVstumpfl.com | +43 7249 42811...
