- Page 1 Grandstream Networks, Inc. CCC602x Series GWN602x - Quick Installation Guide...
-
Page 2: Package Contents
Overview The GCC6020 Series is a powerful all-in-one platform that integrates unified communications, networking, and advanced security features into a single device. Designed for small-to-medium-sized businesses, this series combines the capabilities of four distinct products: a high-performance VPN router, a next-generation firewall, a full-featured IP PBX system, and an enterprise-grade network switch. -
Page 3: Hardware Overview
1× Power Cord Anti-Trip 4× Rubber Feet 1× Regulatory Information 1× Quick Installation Guide 2× M.2 SSD Screws (top) 1× M.2 SSD Securing Screw (bottom) Package Contents Hardware Overview The GCC6020 and GCC6021 feature front and rear panels with multiple Ethernet, SFP, USB, and management ports. The exact port layout varies depending on the model. -
Page 4: Rack Mount Installation
Powering the Device Rack Mount Installation To mount the device into a standard 19” rack: 1. Attach the Rack Brackets Secure the provided rack mount brackets (d) to both sides of the device (a) using the included screws (e). 2. Install the Unit into the Rack Carefully align and slide the device into the rack, then secure the brackets to the rack frame. -
Page 5: Safety And Precautions
Safety and Precautions Do not attempt to open, disassemble, or modify the device. Do not expose this device to temperatures outside the range of 0 °C to 45 °C for operating and -10 °C to 60 °C for storage. Do not expose the device to environments outside of the following humidity range: 5-95% RH (non-condensing). Do not power cycle the device during system boot-up or firmware upgrade.
