Operating Manual
STUDIOART
S100 Audiobar
V1.3 m2

Advertisement

loading
Need help?

Need help?

Do you have a question about the STUDIOART S100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Revox STUDIOART S100

  • Page 1 Operating Manual STUDIOART S100 Audiobar V1.3 m2...
  • Page 2 INTRODUCTION ..............................1 Unpacking ....................................1 Network requirements for S100 ............................... 1 Included in delivery ................................... 1 Optional accessories ................................. 1 Installation - Safety advice..............................2 Safety measures ..................................2 Please note .................................... 2 S100 connector panel, rear ..............................3 Operation via the glass touch panel ............................
  • Page 3 INTRODUCTION Congratulations on acquiring your new STUDIOART S100 Audiobar. We would like to thank you for the trust you have shown in our company by purchasing this high-quality product. Before commissioning your Revox Audiobar, you should pay attention to the following instructions in order to fully benefit from the acoustic qualities of the product.
  • Page 4 - dust - accesses to the inside of the device Please note In order to exclude the risk of an electric shock, do not remove the housing. Only have repair work carried out by a Revox specialist dealer. STUDIOART S100 Audiobar...
  • Page 5 Connector sockets (RCA, Stereo) for analogue signal sources such as tuners, audio tape devices, or reel-to-reel tape decks. The Revox STUDIOMASTER T700 turntable with integrated high-end phono amplifier can also be connected here. For mobile devices with a low output level, there is a special adjustment option in the STUDIOART app. You will find a detailed description in the chapter STUDIOART App of this operating manual.
  • Page 6 5 Digital optical input [Optical IN] Connector socket (TOSLINK optical fibre) for digital signal sources such as CD Players, satellite receivers, or TV sets. Supported formats: Bitstream/ PCM/ SPDIFF up to 192 kHz/ 24 bit Take note: Sensitive input with automatic switch-on/switchover 6 LAN port [Network] If it is not possible to operate the S100 Audiobar on a stable WiFi network, the S100 can also be connected to a router or switch using a patch cable.
  • Page 7 TV set (only with HDMI-ARC connection). Because the button symbols are not visible when the device is switched off, you can use the large V of the ReVox logo as a reference point.
  • Page 8 RC100 – IR remote control  Before initial use, the safety film must be removed/ pulled out of the battery compartment. Function [ Explanation Display] Navigation / OK Selection and confirmation in the basic settings Back Go back one level in the OSD menu Basic settings Play/ Pause/ Stumm ...
  • Page 9 STUDIOART TV pedestal If it is difficult to mount the TV on the wall, e.g. due to the structural stability of the wall, Revox offers a large STUDIOART pedestal for TV sets measuring up to 65" into which the S100 Audiobar is also integrated. In this case, the screen "floats" several centimetres above the Audiobar, and can be optimally aligned to it.
  • Page 10 Installation in a room The Audiobar is designed as a 2.1 system so that you can enjoy excellent music and film playback without requiring any extensions. A full-range phase-linear speaker with its own power amplifier is used in each case for the left, right, and centre channels.
  • Page 11 B100, can barely be localised by the human ear. The goal is to integrate the B100 such that it is not perceived in the foreground, but instead positively expands the overall audio experience where deeper frequencies are concerned. In order to achieve this, Revox recommends observing the following points: ...
  • Page 12 Brightness of the Revox logo Brightness setting of the Revox logo on the glass surface in the range of 1-15. Automatic switch-on If the function is activated, the audio bar switches itself on again automatically after a power failure.
  • Page 13 Sound format display on the front display When the display is activated, the detected sound formats are shown in the display behind the front grille of the audio bar every time the source (station) is changed. Automatic standby mode If there is no action by the handset, the Audiobar is switched to standby mode after 20 minutes. This applies to all local audio and video sources (e.g.
  • Page 14 5.1 Center Gain When playing 5.1 Dolby Digital sound formats, it is sometimes necessary to adjust the volume of the voice range via the center loudspeaker. In the OSD menu you can increase the volume in 9 steps (0 - 9 dB). This setting can also be carried out with the help of the RC100 IR remote control by pressing the Play/ Pause button for at least 4 seconds and then using the UP / Down buttons to select the center volume.
  • Page 15 2. Integrating the S100 Audiobar into the home network via WiFi/LAN The S100 Audiobar functions primarily by streaming content from the internet. For the full range of control options, the Audiobar communicates with the STUDIOART app, which must also be in the same network as the Audiobar. This chapter explains the options available for connecting the S100 with your home network.
  • Page 16 Android device Connecting the S100 to the local network via an Download and install the free STUDIOART app from the Google Play Store. Deactivate Energy-saving mode on your phone. Tap on the row of text that reads "Press and hold this row to configure a new device"...
  • Page 17 LAN connection Connecting the S100 Audiobar to the local network via a If it is not possible to operate the Audiobar on a stable WiFi network, it can also be connected to a router or switch using a LAN cable (patch cable with RJ45 plug). multi-room mode Important note: In multi-room operation, STUDIOART loudspeakers can be operated via LAN as well as via WLAN in the home network.
  • Page 18 ( Setup / Info) or a network IP scanner. Enter this IP address in the command line of your browser. Immediately afterwards, the Revox web interface opens, in which, in addition to the manual IP address assignment, you will also find change options for the S100 name, WLAN band and a manual update option.
  • Page 19 At low volume levels, our ears perceive low frequencies with less intensity than medium or high frequency ranges. This leads to persons listening to music at low volume levels feeling that the bass frequencies are missing. Hence, Revox has created an adaptive bass correction algorithm that takes hearing perception into account.
  • Page 20 .Widening effect. The Revox Audiobar has been designed as a multi-channel speaker for high-quality audio playback. If you wish to experience the audio on its own without additional spatial effects, select Off. Particularly for (stereo) recordings, this is the best choice, as the piece of music will already have been given echo and other effects in the recording studio.
  • Page 21 .Revox logo always lit. The Revox logo in the glass section of the Audiobar can be illuminated. If the illumination is not desired, it can be deactivated via this switch. This function has no influence over the touch panel located below the Revox logo.
  • Page 22 .External Bass. Traditionally wired active subwoofers such as the Revox Active 04 can also be connected to the audio bar. The music signal is passed on from the audio bar to the active subwoofer using a mono cinch cable (Sub OUT socket). The Distance parameter specifies how many meters the audio bar is further from the listening position than the external subwoofer.
  • Page 23 .External Bass. (Continued) Note: For automatic signal detection, which many subwoofers have, it is advantageous if a T- adapter is used with a stereo input (R + L). The level of the mono signal (from the S100) is doubled and the external subwoofer switches on reliably even at low levels. This settings menu is always available, even if no external subwoofer is connected.
  • Page 24 Define A100 + P100 combo as surround loudspeaker * (left / right): hold for approx. 5 seconds (5a) - Status LED flashes quickly and a periodic beep is audible (5b) Only the A100, either as right or left surround speaker, will be integrated. The place of installation defines whether it is right or left.
  • Page 25 Using the STUDIOART app Speaker/room selection the first step , the STUDIOART speaker and/or the corresponding room is selected by tapping on the corresponding row. The currently selected speaker (A100 active speaker, S100 Audiobar) is indicated with a blue rectangle and its name appears in the top left of the row.
  • Page 26 Source and music selection Accessing the music service TIDAL (subscription required). This music service is integrated natively into the STUDIOART app, i.e. all functions are executed in the STUDIOART app. Accessing the music service Deezer (subscription required). This music service is integrated natively into the STUDIOART app, i.e.
  • Page 27 Playback view fourth step is where the title or the source is shown with a cover. Furthermore, the volume slider can be used to adjust the volume within a range of 0- 100% on this screen. The Pause/ Play button in the middle of the screen also allows the playback to be paused.
  • Page 28 1. The Audiobar is not shown in the STUDIOART app The STUDIOART app does not show the Audiobar in the device list (left main tab with speaker symbol ), even though a connection was established in the past. Possible causes: The S100 Audiobar is not on the same network as the STUDIOART app.
  • Page 29 Solution 3: Use a LAN connection instead of a WiFi connection. If no LAN connection is available at the installation site, powerline adapters can be used to establish a LAN connection between the router and the STUDIOART product via normal power cables (230 V AC). This wired transmission technology is highly resistant to wireless interference. Popular manufacturers of powerline products are the companies Devolo and TP-Link.
  • Page 30 6. When playing an album, music playback stops at the end of a title Possible causes: The STUDIOART app was closed during the playing of the album. It does not matter if it was an album from a music service (e.g. Spotify) or the music server.
  • Page 31 Technical data S100 Audio data Speaker principle Active bass reflex system with dual port Frequency response 44 -20000 Hz (-3 dB) (with deactivated B100 / Sub-out) 120 -20000 Hz (-3 dB) (with activated B100 / Sub-out) Max. sound pressure level 100 dB/ 1m Power amplifier Power –...
  • Page 32 Copyright Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories. The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. Use of the Works with Apple badge means that an accessory has been designed to work specifically with the technology identified in the badge and has been certified by the developer to meet Apple performance standards.
  • Page 33 Austria Revox Handels GmbH Josef-Pirchl-Strasse 38, AT 6370 Kitzbühel Tel +43 535 666 299, Fax +43 535 666 299 4 info@revox.at www.revox.at Operating Manual Active 04 / Item no. 10.18.1504 E&EO Copyright by Revox Deutschland GmbH, Germany STUDIOART S100 Audiobar...
