- Page 1 WOOD PRODUCTS USER MANUAL MONOBLOCCO 3LC.16 MADE ITALY design & production 004300033 - Rev.001...
- Page 2 ENGLISH...
- Page 3 ATTENTION SURFACES CAN BECOME VERY HOT! ALWAYS USE PROTECTIVE GLOVES! During combustion, thermal energy is released that significantly increases the heat of surfaces, doors, handles, controls, glass, exhaust pipes, and even the front of the appliance. Avoid contact with those elements if not wearing protective clothing (protective gloves included).
- Page 4 INSTALLAZIONE - INSTALLATION - INSTALLATION - L’INSTALLATION - LA INSTALACIÓN Per facilitare la movimentazione del Monoblocco sono stati previsti dei fori nella base delle gambe per l’utilizzo di eventuali tubi rotondi. I tubi dovranno avere un diametro da 1’’(33.7mm) e uno spessore di 3.2 mm. To facilitate the handling of the Unit, there are some holes in the base of the legs to use round tubes.
- Page 7 SET FORTH IN THESE INSTRUCTIONS AND PROFESSIONAL STANDARDS, BY QUALIFIED PERSONNEL ACTING ON BEHALF OF COMPANIES CAPABLE OF ASSUMING FULL RESPONSIBILITY FOR THE ENTIRE SYSTEM. LA NORDICA S.p.A. IS NOT RESPONSIBLE FOR ANY UNAUTHORISED MODIFICATIONS TO THE PRODUCT, NOR FOR THE USE OF NON-ORIGINAL SPARE PARTS.
- Page 8 UNDERSTAND THE POTENTIAL HAZARDS. CHILDREN MUST BE SUPERVISED TO ENSURE THEY DO NOT PLAY WITH THE APPLIANCE. CLEANING AND MAINTENANCE INTENDED TO BE PERFORMED BY THE USER MUST NOT BE CARRIED OUT BY CHILDREN WITHOUT SUPERVISION. Š DO NOT TOUCH THE HEATER WITH BARE FEET OR WITH WET OR DAMP BODY PARTS. Š...
- Page 9 FIRE SAFETY MINIMUM CLEARANCES Installation next to combustible or heat-sensitive materials is permitted, provided that suitable safety distances are maintained, as specified in the CEMI (CE Marking Information), the Declaration of Performance (DoP) and the label at the beginning of the manual (page 2).
- Page 10 Figure 1 Beams Insulating refractory material Air vacuum Metallic protection IN CASE OF FAULTS The steps to follow to safely switch off the appliance in the event of a malfunction are: Discontinue use of the product and contact the authorised Broken glass door service centre Immediately stop loading the firewood, do not open the door,...
- Page 11 Š Check the load-bearing capacity of the structure to ensure it can support the weight of the appliance. If the load-bearing capacity is insufficient, appropriate measures must be taken. LA NORDICA S.p.A.’s responsibility is limited to supplying the appliance only (see technical data in the document "CE MARKING INFORMATION").
- Page 12 FOR PROPER OPERATION OF THE APPLIANCE, IT IS MANDATORY TO ENSURE AN ADEQUATE SUPPLY OF AIR IN THE INSTALLATION AREA, BOTH FOR COMBUSTION AND FOR RE-OXYGENATION OF THE ROOM. This means that, through dedicated openings communicating with the outside, combustion air must be able to circulate even when doors and windows are closed.
- Page 13 FLUE EXHAUST FLUE PIPE THE COMPONENTS OF THE COMBUSTION GAS EVACUATION SYSTEM MUST BE SELECTED AND RATED IN ACCORDANCE WITH CURRENT REGULATIONS, CONSIDERING THE SPECIFIC INSTALLATION CONDITIONS. The following checks are recommended: Š The chimney system must be assessed in accordance with the following technical standards (where applicable): EN 15287-1, EN 15287-2, EN 13063-1, EN 13063-2, EN 1457, EN 1806, EN 1856-1, EN 1856-2, and EN 13384-1;...
- Page 14 A cross-section that is too small will reduce the draught. A minimum height of 4 metres is recommended. The following materials are PROHIBITED, as they compromise the proper functioning of the appliance: fibre cement, galvanised steel, rough or porous internal surfaces. illustrates several possible solutions.
- Page 15 FLUE FOR AN OPEN FIREPLACE OR FIREBOX When using the flue of an open fireplace or firebox, the hood must be airtight below the connection point of the flue pipe (Pos. A Figure 4 If the flue is too large (e.g. 30x40 cm or 40x50 cm), it must be lined with a stainless steel pipe with a minimum diameter of 200 mm (Pos. B), ensuring that the remaining space between the pipe and the flue is completely sealed immediately below the chimney pot (Pos.
- Page 16 Figure 6 The chimney pot must not have any obstructions within 10 m, such as walls, roof slopes or trees. Otherwise, it must be raised by at least 1 m above the highest obstacle. The chimney pot must extend at least 1 m above the roof ridge. CHIMNEY POT DISTANCES AND POSITIONING (UNI 10683) >10°...
- Page 17 PERMITTED/NOT PERMITTED FUELS Only logs may be used as fuel. Only dry logs (max. moisture content 20%) should be used. A maximum of 2 or 3 logs should be loaded at a time. Logs should be approximately 20–30 cm in length and have a maximum circumference of 30–35 cm. NON-RESINOUS PRESSED WOOD LOGS MUST BE USED WITH CAUTION TO AVOID OVERHEATING THAT COULD DAMAGE THE APPLIANCE, AS THEY HAVE A HIGH HEATING VALUE.
- Page 18 INSTALLATION OF INSERT 3LC.16 ASSEMBLY MUST BE CARRIED OUT BY QUALIFIED PERSONNEL! THE HEAT VENT GRATE (FIGURE 8 POS. 6 - FIGURE 9) IS TO BE INSTALLED ON THE UPPER PART OF THE HOOD ABOUT 20 CM FROM THE CEILING. THIS MUST ALWAYS BE INSTALLED, AS ITS FUNCTION IS TO RELEASE THE HEAT ACCUMULATED INSIDE THE HOOD (OVERPRESSURE) INTO THE ROOM.
- Page 19 Figure 8 NON-FIREPROOF MATERIAL FIREPROOF MATERIAL INSULATED FLUE Images are for illustrative purposes ENGLISH...
- Page 20 HOOD OR ADJACENT ROOM VENTILATION The product can distribute heated air by NATURAL CONVECTION, or FORCED CONVECTION using the OPTIONAL ventilation - WIND AIR KIT (see separate instructions). DURING INSTALLATION, THE TYPE OF CONVECTION TO BE USED MUST BE DETERMINED A) NATURAL CONVECTION: Figure 9 - 10 B) FORCED CONVECTION:...
- Page 21 Figure 10 CAUTION It is recommended to construct a fireproof plasterboard counter-hood with a self-supporting metal frame to prevent the weight from being transferred onto the aesthetic cladding (marble). >750 cm2 A - Natural convection; B - Fresh air intake for appliance; C - Forced convection >1000 cm2 Images are for illustrative purposes...
- Page 22 Firebox door handle Ducted air outlet Primary/secondary air damper TECHNICAL DESCRIPTION La NORDICA wood-fired products are suitable for heating living spaces for certain periods. LOGS ARE USED AS FUEL. THIS IS AN INTERMITTENT COMBUSTION APPLIANCE. CONSTRUCTION SYSTEM: Type 1: products with automatic door closure.
- Page 23 ACCESSORIES SUPPLIED STANDARD OPTIONAL GLOVE WIND AIR KIT (air ducting) Figure 11 POKER SHADE model diffuser (air ducting) - C1 Figure 11 WAVE model diffuser (air ducting) Figure 11 - C2 USING A FLEXIBLE HOSE (FIREPROOF, NOT SUPPLIED), COMBUSTION AIR CAN BE TAKEN DIRECTLY FROM OUTSIDE (SEE SECTION ON VENTILATION AND AIRING OF INSTALLATION ROOMS).
- Page 24 IGNITION AT THE FIRST IGNITION, AN UNPLEASANT ODOUR WILL INEVITABLY BE PRODUCED (DUE TO THE DRYING OF THE ADHESIVES IN THE SEALING GASKET OR THE PROTECTIVE VARNISH), WHICH DISAPPEARS AFTER A SHORT PERIOD OF USE. HOWEVER, GOOD VENTILATION OF THE ROOM MUST BE ENSURED. AT THE FIRST IGNITION, IT IS ADVISABLE TO LIMIT THE AMOUNT OF LOADED FUEL, GRADUALLY INCREASING THE HEAT OUTPUT OF THE APPLIANCE.
- Page 25 FIRST LOAD IGNITION (see figure A - For ignition, arrange the largest pieces of firewood (1) with a maximum length of 25 cm at the bottom; - Arrange the finer pieces of firewood (2), with a maximum length of 25 cm, on top of the other pieces (1);...
- Page 26 NORMAL OPERATION Before placing the firewood, fully open the primary air damper and, using the supplied poker, stir the embers to reignite them. Once the firewood is in the combustion chamber (see LOADING INSTRUCTIONS) close the door and wait up to 3 minutes for the flame to ignite, then set the damper in the appropriate position to obtain the nominal output.
- Page 27 NEVER OVERLOAD THE APPLIANCE. TOO MUCH FUEL AND COMBUSTION AIR CAN CAUSE OVERHEATING AND THUS DAMAGE THE APPLIANCE. DAMAGE CAUSED BY OVERHEATING IS NOT COVERED BY WARRANTY. ALWAYS USE THE PRODUCT WITH THE DOOR CLOSED TO AVOID DAMAGE DUE TO OVERHEATING (FORGING EFFECT). IN ADDITION TO THE COMBUSTION AIR SETTING, THE COMBUSTION INTENSITY AND THUS THE HEAT OUTPUT IS ALSO INFLUENCED BY THE CHIMNEY.
- Page 28 CLEANING AND MAINTENANCE MUST ONLY BE PERFORMED WHEN THE APPLIANCE IS COLD. USE ONLY SPARE PARTS EXPRESSLY AUTHORISED AND SUPPLIED BY LA NORDICA S.P.A. PLEASE CONTACT YOUR SPECIALISED RETAILER IF YOU REQUIRE SPARE PARTS. NO CHANGES MUST BE MADE TO THE APPLIANCE!!!
- Page 29 A specific secondary air inlet effectively slows down the formation of dirt deposits on the door glass. However, such deposits can never be avoided with the use of solid fuels (e.g. damp firewood) and are not to be regarded as a defect of the appliance . THE PANORAMIC GLASS MUST ONLY BE CLEANED WHEN THE APPLIANCE IS COLD TO PREVENT IT FROM EXPLODING.
- Page 30 LOWERING THE DOOR MULTIPLE TIMES TO ENSURE THE GREASE IS EVENLY DISTRIBUTED ACROSS ALL THE BALL BEARINGS. CAUTION: USE ONLY THE GREASE SUPPLIED BY LA NORDICA S.P.A. SUMMER SHUTDOWN After cleaning the firebox, chimney and flue, ensuring that all ash and any other residue have been removed, all doors and relative firebox dampers should be closed.
- Page 31 Symbol EN 16510-1 EN 16510-1 EXPLANATION Symbol Nominal heat output part Part load heat output CON / INT Appliance operation, Continuos (CON) or Intermittent (INT) / CO Carbon dioxide emission 2 nom 2 part / CO Carbon monoxide emission part Minimum distances to combustible materials - bottom Minimum distances to combustible materials - ceiling Minimum distances to combustible materials - floor in front...
- Page 32 CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM The manufacturer reserves the right to vary the characteristics and the data reported in this pamphlet at any moment and without notice, in order to improve its products. 17/04/2025 004300033-001 MAN.UT.MONOBLOCCO 3LC.16...
