Technical specifications
Frequency control
Transmit frequency
Channels
LCD
Nominal effective range
Power requirements
Crystal controlled PLL synthesizer
Baby unit: 2405 - 2475 MHz
Parent unit: 2405 - 2475 MHz
32
3.5" Colour LCD
(QVGA 320x240 pixel)
Actual operating range may vary according to environmental
conditions at the time of use.
Parent unit: 3.6V, 2600mAh Li-ion, 9.36Wh Li-ion battery
Baby unit power adaptor: Output: 6V DC @ 400mA
Parent unit power adaptor: Output: 5V DC @ 1A
3.5" Video Baby Monitor
Quick start guide
Specifications are subject to change without notice.
© 2024 VTech Telecomunications Ltd.
All rights reserved. 05/24. VM4254_UK_QSG_V1.
VM4254
with Night Light
Advertisement
Table of Contents
Related Manuals for VTech VM4254
Summary of Contents for VTech VM4254
- Page 1 Parent unit: 3.6V, 2600mAh Li-ion, 9.36Wh Li-ion battery Baby unit power adaptor: Output: 6V DC @ 400mA Parent unit power adaptor: Output: 5V DC @ 1A Specifications are subject to change without notice. © 2024 VTech Telecomunications Ltd. All rights reserved. 05/24. VM4254_UK_QSG_V1.
-
Page 2: Important Safety Instructions
Power adaptor information: concerning use of the appliance by a person responsible Parent unit output: 5V DC 1A for their safety. VTech Telecommunications Ltd. SAVE THESE INSTRUCTIONS Model: VT05EUK05100(UK) Cautions Baby unit output: 6V DC 400mA VTech Telecommunications Ltd. -
Page 3: What's In The Box
What’s in the box Quick start guide Connect the baby monitor The parent unit turns on automatically after connecting the power adaptor to the power socket and the battery LED light illuminates. NOTES NOTE • The rechargeable battery in the parent unit is built-in. •... - Page 4 Connect the baby monitor (cont’d) Charge the parent unit battery When you have connected and turned on the parent unit, the battery will be charged automatically. Notes NOTES NOTE • Before using the baby monitor for the first time, charge the parent unit battery for 12 hours. When the parent unit battery is fully charged, the battery icon segments are solid •...
-
Page 5: Positioning The Baby Monitor
Positioning the baby monitor Caution • Keep the baby unit out of the reach of your baby. Never place or mount the baby unit inside the baby’s cot or playpen. ≥ < Note Caution NOTES NOTE • To avoid interference from other electronic devices, •... -
Page 6: Use The Menu
Basic operation - Parent unit Use the menu Press MENU to enter the menu, or save a setting. You can use the parent unit for advanced settings or operations, such as to play or stop the baby unit lullaby, or to adjust the baby unit sound sensitivity. - Page 7 Adjust parent unit speaker volume Zoom Adjust parent unit speaker volume Zoom Press VOL+ / VOL- to adjust your parent unit Press MENU when in idle mode. speaker volume. Press VOL+ / VOL- to adjust your parent unit Press MENU when in idle mode. Go to Settings menu, then choose Alternately, you may press MENU >...
-
Page 8: Overview - Baby Unit
Overview - Baby unit Microphone PAIR hole • The parent unit and Camera lens baby unit(s) provided are already paired. Infrared LEDs Speaker Light sensor Power jack POWER LED light Slots for wall mounting Night light Night light ON/OFF... -
Page 9: Status Icons
Parent unit icons Status icons Connection status • displays when strong signal strength is detected between the baby unit and the parent unit. • displays when moderate or low signal strength is detected between the baby unit and the parent unit. •... -
Page 10: Main Menu Icons
Main menu icons Main Sub-menu menu Volume • Adjust the parent unit speaker volume. Settings Brightness • Adjust the parent unit LCD screen brightness level. Screen off timer • The parent unit screen will turn off after the selected time to save energy. -
Page 11: Lullaby Volume
Main Sub-menu menu Temperature • Set temperature display in Fahrenheit ( or Celsius ( • Set the minimum/maximum temperature. • Turn on/off temperature alert tone. • Set the parent unit to beep whenever the room temperature detected by the baby unit falls outside of the set temperature range. - Page 12 Parent unit icons (cont’d) Warning icons and messages Parent Unit Indication Lights LINK • On when the parent unit is linked to the baby unit. The battery is empty and • Flashes when the link to the needs to be recharged. Battery low at baby unit being viewed is Parent Unit...
- Page 13 Sound sensitivity and sound activation Adjust the sound sensitivity of the baby unit The parent unit screen will turn on only when the detected sounds exceed a set level. Use the parent unit to adjust the microphone sensitivity of your baby unit. The higher the sensitivity level, the more sensitive the baby unit is in detecting sounds that transmit to the parent unit.
-
Page 14: Dim Mode
Dim mode Dim mode helps you save parent unit power. When your parent unit is not charging, the display will automatically dim after 10 minutes of inactivity if no keys are pressed or alerts are received from the baby unit. 10 min inactivity Press any button Note... - Page 15 Mount the baby unit on dry wall (optional) Items to purchase You will need to purchase the following items separately to mount your baby unit: 2 screws 2 wall plugs Note NOTES NOTE • The types of screws and wall plugs you need depend on the composition of the wall.
-
Page 16: Frequently Asked Questions
Frequently asked questions Below are the questions most frequently asked about the baby monitor. Why does the Try the following (in the order listed) for common cure: baby monitor 1. Disconnect the power to the baby unit and the parent unit. not respond 2. -
Page 17: Customer Service And Product Warranty
Breakages to the LCD screen are not covered by the warranty. Email: service-ukbm@vtechphones.eu VTech Electronics Europe Plc, c/o XPO Logistics, Warehouse 350, Cat & Fiddle Lane, West Hallam, DE7 6HE THIS WARRANTY IS OFFERED AS AN EXTRA BENEFIT AND DOES NOT AFFECT CONSUMERS’... -
Page 18: Disposal Of Batteries And Product
(2014/53/EU) and the UK’s Radio Regulations 2017 on radio systems and telecommunication equipment. VTech Telecommunications Ltd. hereby declares that this Video Baby Monitor VM4254 is in compliance with the essential requirements and other relevant provisions of EU’s Radio Equipment Directive (2014/53/EU) and UK’s Radio Equipment Regulations 2017. -
Page 19: General Product Care
General product care To keep this product working well and looking good, follow these guidelines: • Avoid placing it near heating appliances and devices that generate electrical noise (for example, motors or fluorescent lamps). • DO NOT expose it to direct sunlight or moisture. •...
