Technical specifications
Frequency control
Transmit frequency
Channels
LCD
Nominal effective range
Power requirements
Crystal controlled PLL synthesizer
Baby unit: 2405 - 2475 MHz
Parent unit: 2405 - 2475 MHz
32
5" Colour LCD
(WQVGA 480x272 pixel)
Actual operating range may vary according to environmental
conditions at the time of use.
Parent unit: 3.6V, 2600mAh, 9.36Wh Li-ion battery
Baby unit power power adaptor: Output: 5V DC @ 1A
Parent unit power power adaptor: Output: 5V DC @ 1A
Video Baby Monitor
Quick start guide
Specifications are subject to change without notice.
© 2024 VTech Telecommunications, ltd. All rights reserved.
05/24. VM924-x_UK_Type-C_QSG_V1.
VM924
VM924-2
Pan and Tilt
Advertisement
Table of Contents
Related Manuals for VTech VM924
Summary of Contents for VTech VM924
- Page 1 Parent unit: 3.6V, 2600mAh, 9.36Wh Li-ion battery Baby unit power power adaptor: Output: 5V DC @ 1A Parent unit power power adaptor: Output: 5V DC @ 1A Specifications are subject to change without notice. © 2024 VTech Telecommunications, ltd. All rights reserved. 05/24. VM924-x_UK_Type-C_QSG_V1.
-
Page 2: Important Safety Instructions
Cautions Parent unit output: 5V DC 1A • Use and store the product at a temperature between 0 VTech Telecommunications Ltd. and 40 Model: VT05EUK05100 • Mishandling batteries can cause burn, fire or explosion Baby unit output: 5V DC 1A hazards. -
Page 3: What's In The Box
What’s in the box Quick start guide 1 set for VM924 2 sets for VM924-2 Connect the baby monitor NOTES NOTE • The rechargeable battery in the parent unit is built-in. • Use only the power adapters supplied with this product. - Page 4 Connect the baby monitor (cont’d) Charge the parent unit battery When you have connected and turned the parent unit on, the battery charges automatically. Notes NOTES NOTE • Before using the baby monitor for the first time, charge the parent unit battery for 12 hours. When the parent unit battery is fully charged, the battery icon segments become solid •...
-
Page 5: Positioning The Baby Monitor
Positioning the baby monitor Caution • Keep the baby unit out of reach of your baby. Never place or mount the baby unit inside the baby’s cot or playpen. Caution > 1m • The default volume of your parent unit is level 4, and the maximum volume is level 7. - Page 6 Basic operation - Parent unit Basic operation - Parent unit Use the menu Use the menu Press to enter the menu, choose a menu item, or save a setting. You Press to enter the menu, choose a menu item, or save a setting. You can use the parent unit for advanced settings or operations, such as can use the parent unit for advanced settings or operations, such as to play or stop the baby unit lullaby, or to adjust the baby unit sound...
- Page 7 Adjust parent unit volume Pan and tilt the baby unit Adjust parent unit volume Pan and tilt the baby unit Press VOL - VOL + to adjust your parent Press Arrow keys to pan and Press VOL - VOL + to adjust your parent Press Arrow keys unit speaker volume.
-
Page 8: Overview - Baby Unit
Overview - Baby unit Light sensor Antenna Camera Power jack Infrared LEDs Slots for wall mounting Microphone PAIR/RESET key • The parent unit and POWER LED light baby unit provided are ON/OFF switch already paired. Speaker... -
Page 9: Main Menu Icons
Parent unit icons Main menu icons Main Sub-menu menu Brightness • Adjust the parent unit LCD brightness. Lullaby Play/Stop lullaby • Select one of the soothing sounds, or white noise. • Select one of the five melodies. • Play all melodies. •... -
Page 10: Sound Sensitivity
Main Sub-menu menu Screen off Timer Screen off Timer • The parent unit screen will turn off after the selected time to save energy. You can still hear your baby while the screen is turned off. Sound Sensitivity • When AUTO is selected, the parent unit screen will automatically turn on when detected sounds exceed a set level. -
Page 11: Monitoring Mode
• Adjust the baby unit speaker volume. • Zoom in. Monitoring Mode (For pairing with only) VM924-2 • Single CAM mode The screen displays images only from the selected baby unit in full screen. • Split mode The screen displays images from all the paired baby units at the same time in split view. - Page 12 • - Weak signal strength. (e.g. 57 F or 14 Split mode Temperature alert tone (*For pairing with only) VM924-2 Patrol mode Talkback - On (*For pairing with only) VM924-2 Current view status Mute alert • Displays when the parent unit •...
- Page 13 Sound sensitivity and sound activation Adjust sound sensitivity level of the baby unit The parent unit screen will turn on only when the detected sounds exceed a set level. Use the parent unit to adjust the microphone sensitivity of your baby unit. The higher the sensitivity level, the more sensitive the baby unit is in detecting sounds that transmit to the parent unit.
-
Page 14: Dim Mode
Dim mode Dim mode helps you save parent unit power. When your parent unit is not charging, the display will automatically dim after 10 minutes of inactivity if no keys are pressed or alerts are received from the baby unit. 10 mins inactive Press any button Night vision... - Page 15 For VM924-2 only Status check - Two baby units If you are viewing baby unit , the POWER LED light of baby unit turns on. As baby unit is not being viewed, its POWER LED light flashes. Note NOTES NOTE •...
- Page 16 Mount the baby unit on dry wall (optional) Notes NOTES NOTE • Check for reception strength and camera angle before drilling the holes. • The types of screws and wall plugs you need depend on the composition of the wall. You may need to purchase the screws and wall plugs separately to mount your camera units.
-
Page 17: Frequently Asked Questions
Frequently asked questions Below are the questions most frequently asked about the baby monitor. Why does the Try the following (in the order listed) for common cure: baby monitor 1. Disconnect the power to the baby units and the parent unit. not respond 2. -
Page 18: General Product Care
General product care To keep this product working well and looking good, follow these guidelines: • Avoid placing near heating appliances and devices that generate electrical noise (for example, motors or fluorescent lamps). • DO NOT expose to direct sunlight or moisture. •... -
Page 19: Customer Service And Product Warranty
Damage to the antenna is not covered by the warranty. Email: service-ukbm@vtechphones.eu VTech Electronics Europe Plc, c/o XPO Logistics, Warehouse 350, Cat & Fiddle Lane, West Hallam, DE7 6HE THIS WARRANTY IS OFFERED AS AN EXTRA BENEFIT AND DOES NOT AFFECT CONSUMERS’... -
Page 20: Disposal Of Batteries And Product
(2014/53/EU) and the UK Radio Regulations 2017 on radio systems and telecommunication equipment. VTech Telecommunications Ltd. hereby declares that Pan and Tilt Video Baby Monitor VM924/ VM924-2 complies with the essential requirements and other relevant provisions of EU Radio Equipment Directive (2014/53/EU) and UK Radio Equipment Regulations 2017.
