- Page 1 VM350 Go to www.vtechphones.com to register your product for VM350-2 enhanced warranty support and Full Color Video Monitor the latest VTech product news. User’s manual...
-
Page 2: What's In The Box
Congratulations on purchasing your new VTech product. Before using this product, please read Important safety instructions. This manual has all the feature operations and troubleshooting necessary to install and operate your new VTech product. Please review this manual thoroughly to ensure proper installation and operation of this innovative and feature rich VTech product. -
Page 3: Install The Battery
Install the battery The parent unit runs on rechargeable battery or AC power. To continuously monitor your baby, make sure you use both battery and AC power at the same time. With the battery alone, the parent unit can cordlessly run for a short time only. - Page 4 Connect and charge the battery NOTES • Use only the power adapters supplied with this product. • Make sure the electrical outlets are not controlled by wall switches. • The power adapters are intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if they are plugged into a ceiling, under-the-table or cabinet outlet.
- Page 5 Charge the parent unit battery When you have connected the parent unit and installed its battery for the first time or after power outage, the parent unit powers on automatically. The battery icon indicates the The battery icon indicates the battery status (see the following table).
-
Page 6: Before Use
Before use NOTE • This baby monitor is intended as an aid. It is not a substitute for proper adult supervision, and should not be used as such. Test your baby monitor You may test the baby monitor before initial use, and at regular times thereafter. -
Page 7: Positioning The Baby Monitor
Positioning the baby monitor CAUTION • Keep the baby units out of the reach of your baby. Never place or mount the baby units inside the baby’s crib or playpen. NOTE • To avoid interference from other electronic devices, place your baby monitor far away from devices such as wireless routers, microwaves, cell phones and computers. -
Page 8: Operating Range
Operating range The operating range of the baby monitor is up to 1000 feet (300 meters) outdoors or 160 feet (50 meters) indoors. The actual operating range may vary depending on the environmental conditions and other interferences such as walls, doors and other obstructions. - Page 9 PAIR button • Your baby units and parent unit provided are already paired. POWER LED light • On when the baby unit is turned on and is paired to the parent unit. • Flashes when the baby unit is not being viewed;...
-
Page 10: Parent Unit Overview
Parent unit overview LED lights • Indicate the different statuses of the parent unit. For details, refer to Parent unit lights. LCD Display • Press to increase the parent unit speaker volume. • Press to decrease the parent unit speaker volume. •... - Page 11 VIEW / LCD ON/OFF • Press and hold to turn off the parent unit screen. • Press to view the image of the next baby unit in Single CAM or Patrol mode. Microphone POWER • Press and hold to power on. •...
-
Page 12: Parent Unit Lights
Speaker Power jack Battery compartment cover Stand Parent unit lights LINK • On when the parent unit is linked to the baby unit. • Flashes when the link to the baby unit being viewed in Single CAM or Patrol mode is lost; or when the link to at least one baby unit being viewed in Split mode is lost. - Page 13 Split mode. Patrol mode • Displays when the parent unit is in Patrol mode. • For VM350-2 only Split mode • Displays when the parent unit is in Split mode. • For VM350-2 only Night vision •...
-
Page 14: Parent Unit Main Menu Icons
Monitoring Mode If you have two baby units, you can select a monitoring mode (Single CAM, Patrol or Split). • For VM350-2 only Alert Tone You can set the parent unit to beep when • the parent unit operates in low battery condition;... -
Page 15: Parent Unit Display Messages
Sound-activated Screen When the baby unit detects no sound, the parent unit screen stays off to save power. Once a sound is detected, the parent unit screen turns on automatically. It will then turn off again after 50 seconds of no sound detection. -
Page 16: Using The Baby Monitor
Powering on... The parent unit is turning The parent unit is searching for baby units. Auto Timer of The timer that determines lullaby is reset the remaining play time for the lullabies is restarted. represents the baby unit number. Using the baby monitor Power on or off the baby unit ON/OFF switch downward to turn •... - Page 17 For baby unit: The baby unit speaker volume determines the lullaby volume and talkback volume transmitted from parent unit. The volume can be adjusted in the parent unit. Press MENU when the parent unit is idle. to choose Volume on CAM, Press then press SELECT.
-
Page 18: Set The Language
To stop lullaby or soothing sound: Press MENU when the parent unit is idle. to choose Lullaby on CAM, Press then press SELECT. to choose Stop, then press Press SELECT. To set auto timer for lullaby: While the baby unit is playing lullaby or soothing sound, the auto timer feature helps you automatically stop the lullaby or soothing sound after playing for 15/30/45/60 minutes. - Page 19 Turn on or off the dim mode The dim mode is preset to on to help you save the parent unit power. Your parent unit display will dim automatically after 10 minutes of inactivity, in which there is neither key pressed nor alert received from the baby unit.
-
Page 20: Adjust The Sound Sensitivity Of The Baby Unit
Adjust the sound sensitivity of the baby unit You can choose to hear sounds from the baby unit all the time, or to hear sounds that exceed a certain level. You can use the parent unit to adjust the microphone sensitivity of your baby unit. -
Page 21: Monitoring Mode
This depends on whether the baby unit detects any sounds. Monitoring mode for VM350-2 only Every time the parent unit is turned on, it displays a baby unit in Single CAM mode. If there are two baby units in your system, you can also monitor your baby in Patrol or Split mode. - Page 22 Single CAM The screen displays a single baby unit in full screen. A single cam view that Patrol transits to a different baby unit every 10 seconds. The screen displays all Split baby units. You can choose the desired monitoring mode. Press MENU when the parent unit is idle.
-
Page 23: Set Alert Tone
Zoom You can zoom in or out while viewing image from baby unit in Single CAM and Patrol mode. • Press to zoom in. • Press and hold to move the zoomed image upward or downward. • Press and hold to move the zoomed image leftward or rightward. -
Page 24: Monitor The Temperature
to choose No Link Alert, Press then press SELECT. to choose On or Off, then Press press SELECT to confirm your selection. Sound alert in split-view You can turn on the sound alert feature so that, while in Split mode, the parent unit beeps and displays Sound detected at CAM # whenever the baby unit detects sounds. - Page 25 Temperature alert tone You can turn on the temperature alert tone so that the parent unit will emit an alert tone if the detected temperature is out of range. Press MENU when the parent unit is idle. to choose Temperature, Press then press SELECT.
-
Page 26: Night Vision
Night vision The baby unit has infrared LEDs that allow you to see your baby clearly at night or in a dark room. When the baby unit being viewed detects low light levels, the infrared LEDs are switched on automatically. The images from the baby unit are in black and white, and appears on screen. -
Page 27: Frequently Asked Questions
Frequently asked questions Below are the questions most frequently asked about the baby monitor. If you cannot find the answer to your question, visit our website at www.vtechphones.com, or contact 1 (800) 595-9511 for customer service. Why does the Try the following (in the order baby monitor listed) for common cure: not respond... - Page 28 Why does the The parent unit and baby units baby monitor may be too close to each other. produce a • Move the parent unit away high-pitched from the baby units until the noise? noise stops; OR • Turn down the volume of your parent unit.
-
Page 29: Important Safety Instructions
Important safety instructions When using your equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: Follow all warnings and instructions marked on the product. Adult setup is required. This product is intended as an aid. - Page 30 where proper ventilation is not provided. Slots and openings in the back or bottom of this product are provided for ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register.
- Page 31 VTech product service centers. Please call ® 1 (800) 8 BATTERY for information on Li-ion battery recycling and disposal bans/restrictions in your area. VTech’s involvement in this program is part of its commitment to protecting our environment and conserving natural resources. ® ®...
-
Page 32: Fcc And Ic Regulations
FCC and IC regulations FCC Part 15 This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. -
Page 33: For Cetl Compliance Only
The term ‘’IC:‘’ before the certification/registration number only signifies that the Industry Canada technical specifications were met. This product meets the applicable Innovation, Science and Economic Development Canada technical specifications. RF radiation exposure statement The baby unit complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. - Page 34 dans un sous-sol humide ni près d’une piscine, dans un soussol humide ou une douche. MISE EN GARDE: Il peut y avoir un risque d’explosion si vous utilisez le mauvais type de piles pour l’unité du parent. N’utilisez que le bloc-piles rechargeable inclus ou le bloc-piles de rechange (BT198555/BT298555).
- Page 35 de vous assurer qu’il y ait une bonne circulation d’air. N’enfoncez jamais d’objets à travers les ouvertures de cet appareil, car ils pourraient entrer en contact avec des points de tension dangereux ou causer des courts-circuits qui peuvent dégénérer en incendies ou en risques d’électrocution.
-
Page 36: Limited Warranty
Consumer for Products purchased and used in the United States of America and Canada. What will VTech do if the Product is not free from defects in materials and workmanship during the limited warranty period (“Materially Defective Product”)? - Page 37 Product, we may replace it with a new or refurbished Product of the same or similar design. We will retain defective parts, modules, or equipment. Repair or replacement of the Product, at VTech’s option, is your exclusive remedy. VTech will return the repaired or replacement Products to you in working condition.
- Page 38 Product under this limited warranty. Transportation, delivery or handling charges are prepaid. VTech assumes no risk for damage or loss of the Product in transit. If the Product failure is not covered by this limited warra nty, or proof of...
-
Page 39: Technical Specifications
Creative Commons license. The Heart Beat sound file was created by Zarabadeu, and is used under the Creative Commons license. Specifications are subject to change without notice. © 2018 VTech Communications, Inc. All rights reserved. 03/18. VM350-X_CIB_V1 Document order number: 91-010899-010-100...
