ECB-960T-A15
SMARC Carrier Board
st
User's Manual 1
Ed
Last Updated: March 7, 2025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECB-960T-A15 and is the answer not in the manual?

Questions and answers

Related Manuals for Aaeon ECB-960T-A15

Summary of Contents for Aaeon ECB-960T-A15

  • Page 1 ECB-960T-A15 SMARC Carrier Board User’s Manual 1 Last Updated: March 7, 2025...

  • Page 2: Copyright Notice

    AAEON assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. AAEON reserves the right to make changes in the product design without notice to its users.
  • Page 3 Acknowledgement All other products’ name or trademarks are properties of their respective owners. Preface...
  • Page 4 Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity ECB-960T ⚫ COM Port Cable ⚫ HDA Cable ⚫ SATA Cable ⚫ GPIO Cable ⚫ If any of these items are missing or damaged, please contact your distributor or sales representative immediately.
  • Page 5 (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the product page at AAEON.com for the latest version of this document. Preface...
  • Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
  • Page 7 If any of the following situations arises, please the contact our service personnel: Damaged power cord or plug Liquid intrusion to the device iii. Exposure to moisture Device is not working as expected or in a manner as described in this manual The device is dropped or damaged Any obvious signs of damage displayed on the device...
  • Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation.
  • Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON 主板/子板/背板 QO4-381 Rev.A2 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 × ○ ○ ○ ○ ○ 及其电子组件 外部信号 × ○ ○ ○ ○ ○ 连接器及线材 本表格依据 SJ/T 11364 的规定编制。...
  • Page 10 China RoHS Requirement (EN) Name and content of hazardous substances in product AAEON Main Board/Daughter Board/Backplane QO4-381 Rev.A2 Hazardous Substances 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 Part Name (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB Assemblies × ○ ○ ○...

  • Page 11: Table Of Contents

    Table of Contents Chapter 1 - Product Specifications..................1 Specifications ......................2 Block Diagram ......................4 Chapter 2 – Hardware Information ..................5 Dimensions ....................... 6 2.2 Jumpers and Connectors .................... 8 List of Jumpers and Switches ................9 2.3.1 DP0/1 Voltage Selection (JP1/JP2) ..........
  • Page 12 2.4.3 Micro SD Card (CN3) ..............23 2.4.4 Serial Port 1 (CN4) ................24 2.4.5 +12V DC Power Jack (CN5)............24 2.4.6 SATA Port 0 (CN6) ................25 2.4.7 Fan Port 2 (CN7) ................25 2.4.8 USB 2.0 (lane 0,1) (CN8) ..............26 2.4.9 OTG Port (lane 0) (CN9) ..............
  • Page 13 2.4.31 MIPI CSI Port 1 (CN36) ..............40 2.4.32 SATA Port 0 Power (CN39) .............41 2.4.33 Giga LAN (lane 1) + USB 3.2 (lane 2,3) (CN40) ......42 2.4.34 eDP Port 0 (lane 0) (JEDP1) ............43 2.4.35 eDP Port 1 (lane 1) (JEDP2)............44 2.4.36 LVDS Back Light Power Port 0 (JLVDSP1) ........

  • Page 14: Chapter 1 - Product Specifications

    Chapter 1 Chapter 1 - Product Specifications...

  • Page 15: Specifications

    Specifications System Form Factor Mini-ITX COM Express Connector — I/O Chipset — Front Panel Control 10-pin Header (2x5P) Ethernet 10/100/1000/2500 Base-TX RJ-45 x 2 (From CPU Module) Expansion Interface PCIe Lane [x4] x 1 Power Supply Type Dependent on Module CMOS Battery RTC Battery Socket x 1 BIOS...
  • Page 16 Storage SATA 6Gb/s x 1 M.2 2280 M-Key x 2 (PCIe Gen 4 [x4] for NVMe) Serial Port 4-Wire UART x 4 or Serial Port x 4 (Optional, by CPU Module) Type-A Connector x 6 (USB 2.0 x 4, USB 3.2/2.0 x 2) OTG x 1 (co-lay USB 2.0 x 1) Audio High Definition Audio x 1 (Pin Header) or I2S x 1...

  • Page 17: Block Diagram

    Block Diagram Chapter 1 – Product Specifications...

  • Page 18: Chapter 2 - Hardware Information

    Chapter 2 Chapter 2 – Hardware Information...

  • Page 19: Dimensions

    Dimensions Top Side Chapter 2 – Hardware Information...
  • Page 20 Bottom Side Chapter 2 – Hardware Information...

  • Page 21: 2.2 Jumpers And Connectors

    2.2 Jumpers and Connectors Top Side Chapter 2 – Hardware Information...

  • Page 22: List Of Jumpers And Switches

    List of Jumpers and Switches Please refer to the table below for all of the board’s jumpers that you can configure for your application Label Function Note DP0 Level Select 3.3V or 1.8V DP1 Level Select 3.3V or 1.8V Audio Codec Level Select 1.8V or 1.5V FAN 1 Level Select 12V or 5V...

  • Page 23: Dp0/1 Voltage Selection (Jp1/Jp2)

    2.3.1 DP0/1 Voltage Selection (JP1/JP2) 3.3V 1.8V (Default) 2.3.2 Audio Codec Voltage Selection (JP4) 1.8V (Default) 1.5V 2.3.3 FAN 1 Voltage Selection (JP5) 12V (Default) Chapter 2 – Hardware Information...

  • Page 24: Espi Chip Selection (Jp7)

    2.3.4 eSPI Chip Selection (JP7) ESPI_CS0#(Default) ESPI_CS1# 2.3.5 eDP0/1 Voltage Selection (JP8/JP10) 3.3V 1.8V (Default) 2.3.6 Auto Power Button Select (JP11) Auto Power Button Power Button(default) Chapter 2 – Hardware Information...

  • Page 25: Fan 2 Voltage Selection (Jp13)

    2.3.7 FAN 2 Voltage Selection (JP13) 12V (default) 2.3.8 Clear CMOS Selection (JP17) RTC BAT (Default) Clear CMOS 2.3.9 Power Button (SW1) Function PWRBTN# 2.3.10 Reset Button (SW2) Function RSTBTN# Chapter 2 – Hardware Information...

  • Page 26: Port Power Switch (Sw3)

    2.3.11 80 Port Power Switch (SW3) Function ON (Default) 2.3.12 Sleep Button (SW4) Function Sleep Mode 2.3.13 Boot Select (SW5) BOOT_SEL2# BOOT_SEL1# BOOT_SEL0# Note Carrier SATA Carrier SD card Carrier eSPI (CS0#) Carrier SPI (CS0#) Module device-vendor specific Remote boot-vendor specific Module eMMC Flash Module SPI (default) Note: Please refer to SMARC SPEC V2.1.1 Boot Select for more details.

  • Page 27: Com-Port 0,1 Loopback (Sw7)

    2.3.15 COM-Port 0,1 Loopback (SW7) TX0/RX0 short TX0/RX0 not short (Default) RTS0/CTS0 short RTS0/CTS0 not short (Default) TX1/RX1 short TX1/RX1 not short (Default) 2.3.16 COM-Port 2,3 Loopback (SW8) TX2/RX2 short TX2/RX2 not short (Default) RTS2/CTS2 short RTS2/CTS2 not short (Default) TX3/RX3 short TX3/RX3 not short (Default) Chapter 2 –...

  • Page 28: List Of Connectors

    List of Connectors Please refer to the table below for all of the board’s connectors that you can configure for your application. Label Function MXM Connector Burn Carrier SPI Micro SD Card Serial Port 1 12V DC Power Jack SATA Port 0 Fan Port 2 USB 2.0 (lane 0,1) OTG Port (lane 0)
  • Page 29 Label Function JEDP1 eDP (lane 0) JEDP2 eDP (lane 1) JLVDSP1 LVDS Back Light Power JLVDSP2 LVDS Back Light Power DP (lane 0) DP/HDMI DP/HDMI (lane 1) RTC Battery I2S Wafer UART0 TX0/RX0/RTS0/CTS0 UART1 TX1/RX1 UART2 TX2/RX2/RTS2/CTS2 UART3 TX3/RX3 Chapter 2 – Hardware Information...

  • Page 30: Mxm Connector (Follow Smarc 2.1.1) (Cn1)

    2.4.1 MXM Connector (Follow SMARC 2.1.1) (CN1) Pin Name Pin Name SMB_ALERT# I2C_CAM1_CK I2C_CAM1_DAT CSI1_CK+ CSI1_CK- RSVD GBE1_SDP I2C_CAM0_CK GBE0_SDP CAM_MCK CSI1_RX0+ I2C_CAM0_DAT CSI1_RX0- CSI0_CK+ CSI0_CK- CSI1_RX1+ CSI1_RX1- CSI0_RX0+ CSI0_RX0- CSI1_RX2+ CSI1_RX2- CSI0_RX1+ CSI0_RX1- CSI1_RX3+ CSI1_RX3- GBE1_MDI0+ GBE1_MDI0- GBE0_MDI3- GBE1_LINK100# GBE0_MDI3+ GBE1_MDI1+ GBE0_LINK100#...
  • Page 31 Pin Name Pin Name SDIO_WP PCIE_D_RX- SDIO_CMD SDIO_CD# USB4+ SDIO_CK USB4- SDIO_PWR_EN USB3_VBUS_DET AUDIO_MCK SDIO_D0 I2S0_LRCK SDIO_D1 I2S0_SDOUT SDIO_D2 I2S0_SDIN SDIO_D3 I2S0_CK SPI0_CS0# ESPI_ALERT0# SPI0_CK ESPI_ALERT1# SPI0_DIN MDIO_CLK SPI0_DO MDIO_DAT SATA_TX+ I2C_GP_CK SATA_TX- I2C_GP_DAT HDA_SYNC SATA_RX+ HDA_SDO SATA_RX- HDA_SDI HDA_CK ESPI_CS0#/SPI1_CS0#/QSPI_CS0 *P54 SATA_ACT#...
  • Page 32 Pin Name Pin Name USB2_EN_OC# USB2_SSTX+ RSVD USB2_SSTX- RSVD USB3_EN_OC# USB2_SSRX+ PCIE_A_RST# USB2_SSRX- USB4_EN_OC# PCIE_B_RST# PCIE_B_CLKREQ# PCIE_C_RST# PCIE_A_CLKREQ# PCIE_C_RX+ PCIE_C_RX- PCIE_C_REFCK+ PCIE_C_REFCK- PCIE_C_TX+ PCIE_C_TX- PCIE_A_REFCK+ PCIE_A_REFCK- PCIE_B_REFCK+ PCIE_B_REFCK- PCIE_A_RX+ PCIE_A_RX- PCIE_B_RX+ PCIE_B_RX- PCIE_A_TX+ PCIE_A_TX- PCIE_B_TX+ PCIE_B_TX- HDMI_D2+/DP1_LANE0+ HDMI_D2-/DP1_LANE0- DP0_LANE0+ DP0_LANE0- HDMI_D1+/DP1_LANE1+ DP0_AUX_SEL HDMI_D1-/DP1_LANE1-...
  • Page 33 Pin Name Pin Name *P10 *S10 LVDS1_CK-/eDP1_AUX-/DSI1_CL GPIO1/CAM1_PWR# *P110 GPIO2/CAM0_RST# S110 *P111 GPIO3/CAM1_RST# *S111 LVDS1_0+/eDP1_TX0+/DSI1_D0+ *P112 GPIO4/HDA_RST# *S112 LVDS1_0-/eDP1_TX0-/DSI1_D0- *P113 GPIO5/PWM_OUT S113 eDP_HPD/DSI1_TE *P114 GPIO6/TACHIN *S114 LVDS1_1+/eDP1_TX1+/DSI1_D1+ P115 GPIO7 *S115 LVDS1_1-/eDP1_TX1-/DSI1_D1- P116 GPIO8 S116 LCD1_VDD_EN P117 GPIO9 *S117 LVDS1_2+/eDP1_TX2+/DSI1_D2+ P118 GPIO10 *S118 LVDS1_2-/eDP1_TX2-/DSI1_D2-...

  • Page 34: Burn Carrier Spi (Cn2)

    FORCE_RECOV# P156 VDD_IN S156 BATLOW# S157 TEST# S158 Note: If function modification is required, please contact the AAEON support team. Note: The marked functions are only for ARM. 2.4.2 Burn Carrier SPI (CN2) Pin Name Signal Type Signal Level SPI_DI_F...
  • Page 35 SPI_DO_F SPI_CE#_F Note: CN2 is optional. Chapter 2 – Hardware Information...

  • Page 36: Micro Sd Card (Cn3)

    2.4.3 Micro SD Card (CN3) Pin Name Signal Type Signal Level SDIO_D2_3V SDIO_D3_3V SDIO_CMD_3V VCC_3V3_SD +3.3V SDIO_CK_3V SDIO_D0_3V SDIO_D1_3V SDIO_CD#_3V Note: CN3 is optional. Chapter 2 – Hardware Information...

  • Page 37: Serial Port 1 (Cn4)

    2.4.4 Serial Port 1 (CN4) Pin Name Signal Type Signal Level SRXD1 STXD1 2.4.5 +12V DC Power Jack (CN5) Pin Name Signal Type Signal Level VCC_DCIN_EXT +12V Chapter 2 – Hardware Information...

  • Page 38: Sata Port 0 (Cn6)

    Pin Name Signal Type Signal Level 2.4.6 SATA Port 0 (CN6) Pin Name Signal Type Signal Level SATA_TX_P DIFF SATA_TX_N DIFF SATA_RX_N DIFF SATA_RX_P DIFF 2.4.7 Fan Port 2 (CN7) Pin Name Signal Type Signal Level +12V_FAN2 +5V / +12V Note: Fan 2 can be set to +5V or +12V by JP13.

  • Page 39: Usb 2.0 (Lane 0,1) (Cn8)

    2.4.8 USB 2.0 (lane 0,1) (CN8) Pin Name Signal Type Signal Level +5V_DUAL_USB_1 USB2N_1_CM DIFF USB2P_1_CM DIFF +5V_DUAL_USB_1 USB2N_1_CM DIFF USB2P_1_CM DIFF 2.4.9 OTG Port (lane 0) (CN9) Pin Name Signal Type Signal Level USB2_0_VBUS_DET USB2N_1_CM_OTG DIFF USB2P_1_CM_OTG DIFF USB2_0_OTG_ID Chapter 2 –...

  • Page 40: Fan Port 1 (Cn10)

    2.4.10 FAN Port 1 (CN10) Pin Name Signal Type Signal Level +12V_FAN +5V / +12V FAN_CN_TACHIN FAN_CN_PWMOUT Note: FAN1 can be set to +5V or +12V by JP5. 2.4.11 MIPI CSI Port 0 (CN11) Pin Name Signal Type Signal Level VCC_3V3 +3.3V VCC_3V3...

  • Page 41: Lid Pin Header (Cn12)

    Pin Name Signal Type Signal Level MCSI1_DN3 MCSI1_CLKP MCSI1_CLKN I2C_CAM0_CK I2C_CAM0_DAT CAM0_PWR# PCAM_MCK 2.4.12 LID Pin Header (CN12) Pin Name Signal Type Signal Level LID# 2.4.13 SPI Socket (CN13) Pin Name Signal Type Signal Level SPI_CE#_F SPI_DI_F 3VSB_SPI Chapter 2 – Hardware Information...

  • Page 42: Pcie Gen 3 [X4] (4X1) (Cn14)

    Pin Name Signal Type Signal Level SPI_DO_F SPI_CLK_F 3VSB_SPI 3VSB_SPI +3.3V 2.4.14 PCIe Gen 3 [x4] (4x1) (CN14) Pin Name Signal Type Signal Level VCC_12V +12V VCC_12V +12V VCC_3V3 +3.3V VCC_3V3 +3.3V PCIE_A_X4_RST# PCIE_A_REFCK_P DIFF PCIE_A_REFCK_N DIFF PCIE_A_RX_P DIFF PCIE_A_RX_N DIFF PCIE_B_RX_P DIFF...
  • Page 43 Pin Name Signal Type Signal Level PCIE_C_RX_P DIFF PCIE_C_RX_N DIFF PCIE_D_RX_P DIFF PCIE_D_RX_N DIFF VCC_12V +12V VCC_12V +12V VCC_12V +12V I2C_GP_CK_3V I2C_GP_DTA_3V VCC_3V3 +3.3V VCC_3V3_SBY +3.3V PCIE_WARK# PCIE_A_CKREQ# PCIE_A_TX_P DIFF PCIE_A_TX_N DIFF PCIE_PRSNT PCIE_B_TX_P DIFF PCIE_B_TX_N DIFF PCIE_C_TX_P DIFF PCIE_C_TX_N DIFF PCIE_D_TX_P DIFF...

  • Page 44: Module Power Connector (Cn15)

    Pin Name Signal Type Signal Level PCIE_PRSNT Note: Supports PCIe_CLK_REQ (Default off). 2.4.15 Module Power Connector (CN15) Pin Name Signal Type Signal Level VCC_5V_Module Chapter 2 – Hardware Information...

  • Page 45: Giga Lan (Lane 0) + Usb 2.0 (Lane 4,5) (Cn16)

    2.4.16 Giga LAN (lane 0) + USB 2.0 (lane 4,5) (CN16) Pin Name Signal Type Signal Level +5V_DUAL_USB_5 USB2N_5_CM DIFF USB2P_5_CM DIFF +5V_DUAL_USB_4 USB2N_4_CM DIFF USB2P_4_CM DIFF GBE0_MDI0_P DIFF GBE0_MDI0_N DIFF GBE0_MDI1_P DIFF GBE0_MDI1_N DIFF GBE0_MDI2_P DIFF GBE0_MDI2_N DIFF GBE0_MDI3_P DIFF GBE0_MDI3_N DIFF...

  • Page 46: Hda Wafer (Hda)

    2.4.17 HDA Wafer (HDA) Pin Name Signal Type Signal Level LOUT_R MIC_R LOUT_L MIC_L FRONT-JD MIC-JD AUD_GND AUD_GND LINE-JD LIN_R VCC_5V_SBY LIN_L 2.4.18 CANBus Port 1 (CN18) Pin Name Signal Type Signal Level CANH1 -27V~+40V CANL1 -27V~+40V Note: CN18 is optional. Chapter 2 –...

  • Page 47: Spi (Lane 0) (Cn19)

    2.4.19 SPI (lane 0) (CN19) Pin Name Signal Type Signal Level 3VSB_SPI +3.3V SPI_CE#_F SPI_CLK_F SPI_DI_F SPI_DO_F 2.4.20 12V ATX 4-pin Power (CN20) Pin Name Signal Type Signal Level VCC_DCIN_EXT +12V VCC_DCIN_EXT +12V Chapter 2 – Hardware Information...

  • Page 48: Terminal Blocks (Cn21)

    +12V Note: CN21 is optional. 2.4.22 eSPI (Debug Card) (CN22) Pin Name Signal Type Signal Level SPI1_IO0_3V SPI1_IO1_3V SPI1_IO2_3V SPI1_IO3_3V VCC_3V3_SBY +3.3V ESPI_R_CS# SPI1_RESET#_3V GND_eSPI SPI1_CK_3V VCC_3V3 +3.3V Note: Only supports AAEON ECBU Debug Card. Chapter 2 – Hardware Information...

  • Page 49: Canbus Port 0 (Cn25)

    2.4.23 CANBus Port 0 (CN25) Pin Name Signal Type Signal Level CANH0 -27V~+40V CANL0 -27V~+40V Note: CN25 is optional. 2.4.24 Serial Port 0 (CN26) Pin Name Signal Type Signal Level SRXD0 SRTS#0 STXD0 SCTS#0 Chapter 2 – Hardware Information...

  • Page 50: Serial Port 2 (Cn27)

    2.4.25 Serial Port 2 (CN27) Pin Name Signal Type Signal Level SRXD2 SRTS#2 STXD2 SCTS#2 2.4.26 Serial Port 3 (CN28) Pin Name Signal Type Signal Level Chapter 2 – Hardware Information...

  • Page 51: Gpio (Lane 0-6) (Cn29)

    Pin Name Signal Type Signal Level SRXD3 STXD3 2.4.27 GPIO (lane 0-6) (CN29) Pin Name Signal Type Signal Level GPIO0_5V/ CAM0_PWR# +3.3V GPIO1_5V/ CAM1_PWR# +3.3V GPIO2_5V/ CAM0_RST# +3.3V GPIO3_5V/ CAM1_RST# +3.3V GPIO4_5V/ HDA_RST# +3.3V GPIO5_5V/FAN_PWMOUT +3.3V GPIO6_5V/ FAN_TACHIN +3.3V VCC_3V3 +3.3V Chapter 2 –...

  • Page 52: Gpio (Lane 7-13) (Cn30)

    2.4.28 GPIO (lane 7-13) (CN30) Pin Name Signal Type Signal Level GPIO7_5V +3.3V GPIO8_5V +3.3V GPIO9_5V +3.3V GPIO10_5V +3.3V GPIO11_5V +3.3V GPIO12_5V +3.3V GPIO13_5V +3.3V VCC_3V3 +3.3V 2.4.29 I2C Wafer (CN31) Pin Name Signal Type Signal Level VCC_3V3 +3.3V I2C_GP_CK_R I2C_GP_DTA_R Chapter 2 –...

  • Page 53: Smbus Wafer (Cn32)

    2.4.30 SMBus Wafer (CN32) Pin Name Signal Type Signal Level VCC_3V3 +3.3V I2C_PM_CK_R I2C_PM_DTA_R 2.4.31 MIPI CSI Port 1 (CN36) Pin Name Signal Type Signal Level VCC_3V3 +3.3V VCC_3V3 +3.3V MCSI2_DP0 MCSI2_DN0 MCSI2_DP1 MCSI2_DN1 Chapter 2 – Hardware Information...

  • Page 54: Sata Port 0 Power (Cn39)

    Pin Name Signal Type Signal Level CAM1_RST# MCSI2_CLKP MCSI2_CLKN I2C_CAM1_CK I2C_CAM1_DAT CAM1_PWR# PCAM_MCK 2.4.32 SATA Port 0 Power (CN39) Pin Name Signal Type Signal Level Chapter 2 – Hardware Information...

  • Page 55: Giga Lan (Lane 1) + Usb 3.2 (Lane 2,3) (Cn40)

    2.4.33 Giga LAN (lane 1) + USB 3.2 (lane 2,3) (CN40) Pin Name Signal Type Signal Level +5V_DUAL_USB_2 USB2_2_DN_CM DIFF USB2_2_DP_CM DIFF USB3_2_RXN_CM DIFF USB3_2_RXP_CM DIFF USB3_2_TXN_CM DIFF USB3_2_TXP_CM DIFF +5V_DUAL_USB_3 USB2_3_DN_CM DIFF USB2_3_DP_CM DIFF USB3_3_RXN_CM DIFF USB3_3_RXP_CM DIFF USB3_3_TXN_CM DIFF USB3_3_TXP_CM DIFF...

  • Page 56: Edp Port 0 (Lane 0) (Jedp1)

    Pin Name Signal Type Signal Level GBE1_MDI1_P DIFF GBE1_MDI1_N DIFF GBE1_MDI2_P DIFF GBE1_MDI2_N DIFF GBE1_MDI3_P DIFF GBE1_MDI3_N DIFF 2.4.34 eDP Port 0 (lane 0) (JEDP1) Pin Name Signal Type Signal Level LVDS_1_LANE3_DP_C LVDS_1_LANE3_DN_C LVDS_1_CLKP_C LVDS_1_CLKN_C LVDS_1_LANE2_DP_C LVDS_1_LANE2_DN_C LVDS_1_LANE1_DP_C LVDS_1_LANE1_DN_C LVDS_1_LANE0_DP_C LVDS_1_LANE0_DN_C VCC_3V3 LVDS_DDC_CK_EDP_HPD...

  • Page 57: Edp Port 1 (Lane 1) (Jedp2)

    Pin Name Signal Type Signal Level EDP_AUX_DP DIFF EDP_AUX_DN DIFF EDP_TX3_DP DIFF EDP_TX3_DN DIFF EDP_TX0_DP DIFF EDP_TX0_DN DIFF EDP_TX1_DP DIFF EDP_TX1_DN DIFF EDP_TX2_DP DIFF EDP_TX2_DN DIFF +VDD_LVDS_eDP +3.3V +VDD_LVDS_eDP +3.3V +VDD_LVDS_eDP +3.3V Note: Pins 38, 39, 40 total driving current supports up to 2A. 2.4.35 eDP Port 1 (lane 1) (JEDP2) Pin Name...
  • Page 58 Pin Name Signal Type Signal Level VCC_3V3 LVDS_DDC_CK_1_EDP1 _HPD EDP1_BKLT_EN_3V3 LVDS1_DDC_DAT_CON EDP1_BKLT_CTL_3V3 EDP1_AUX_DP DIFF EDP1_AUX_DN DIFF EDP1_TX3_DP DIFF EDP1_TX3_DN DIFF EDP1_TX0_DP DIFF EDP1_TX0_DN DIFF EDP1_TX1_DP DIFF EDP1_TX1_DN DIFF EDP1_TX2_DP DIFF EDP1_TX2_DN DIFF +VDD_LVDS_eDP1 +3.3V +VDD_LVDS_eDP1 +3.3V +VDD_LVDS_eDP1 +3.3V Note: Pins 38, 39, 40 total driving current supports up to 2A. Chapter 2 –...

  • Page 59: Lvds Back Light Power Port 0 (Jlvdsp1)

    2.4.36 LVDS Back Light Power Port 0 (JLVDSP1) Pin Name Signal Type Signal Level +VCC_EDP_BKLT_0 +12V/+5V +VCC_EDP_BKLT_0 +12V/+5V EDP_BKLT_CTL_3V3 +3.3V EDP_BKLT_EN_3V3 +3.3V Note: The driving current supports up to 2A. 2.4.37 LVDS Back Light Power Port 1 (JLVDSP2) Pin Name Signal Type Signal Level +VCC_EDP_BKLT_1...

  • Page 60: Dp (Lane 0) (Dp)

    2.4.38 DP (lane 0) (DP) Pin Name Signal Type Signal Level DP0_LANE0_RP_C DIFF DP0_LANE0_RN_C DIFF DP0_LANE1_RP_C DIFF DP0_LANE1_RN_C DIFF DP0_LANE2_RP_C DIFF DP0_LANE2_RN_C DIFF DP0_LANE3_RP_C DIFF DP0_LANE3_RN_C DIFF DP0_AUX_SEL_R DP0_AUXP_RP DIFF DP0_AUXN_RP DIFF DP0_HPD_R +V3P3S_DP_F0 3.3V Note: Pin 20 driving current supports up to 0.5A. Chapter 2 –...

  • Page 61: Dp/Hdmi (Dp Lane 1) (Dp/Hdmi)

    2.4.39 DP/HDMI (DP lane 1) (DP/HDMI) Pin Name Signal Type Signal Level DP1_LANE0_RP_C DIFF DP1_LANE0_RN_C DIFF DP1_LANE1_RP_C DIFF DP1_LANE1_RN_C DIFF DP1_LANE2_RP_C DIFF DP1_LANE2_RN_C DIFF DP1_LANE3_RP_C DIFF DP1_LANE3_RN_C DIFF DP1_AUX_SEL_R DP1_AUXP_RP DIFF DP1_AUXN_RP DIFF DP1_HPD_R +V3P3S_DP_F0 3.3V HDMI_D2+ DIFF Chapter 2 – Hardware Information...

  • Page 62: Rtc Battery (Bt2)

    Pin Name Signal Type Signal Level HDMI_D2- DIFF HDMI_D1+ DIFF HDMI_D1- DIFF HDMI_D0+ DIFF HDMI_D0- DIFF HDMI_CK+ DIFF HDMI_CK- DIFF HDMI_CTRL_CK_3V HDMI_CTRL_DAT_3V +V5S_HDMI1 HDMI_HPD Note: Pins 20, 38 driving current supports up to 0.5A. Note: HDMI and DP can’t work at the same time, configure by BOM. 2.4.40 RTC Battery (BT2) Pin Name...

  • Page 63: Uart Lane 0 (Uart0)

    Pin Name Signal Type Signal Level LINE_OUT_R MIC_IN_R LINE_OUT_L MIC_IN_L AGND_AUD AGND_AUD LINE_IN_R VCC_3V3_AUD +3.3V LINE_IN_L Note: I2S is optional. 2.4.42 UART Lane 0 (UART0) Pin Name Signal Type Signal Level SER0_RTS_3V_R 3.3V or 1.8V SER0_TX_3V_R 3.3V or 1.8V SER0_RX_3V_R 3.3V or 1.8V SER0_CTS_3V_R 3.3V or 1.8V...

  • Page 64: Uart Lane 1 (Uart1)

    2.4.43 UART Lane 1 (UART1) Pin Name Signal Type Signal Level VCC_3V3_L +3.3V SER1_TX_3V_R 3.3V or 1.8V SER1_RX_3V_R 3.3V or 1.8V Note: UART1 is optional. 2.4.44 UART Lane 2 (UART2) Pin Name Signal Type Signal Level SER2_RTS_3V_R 3.3V or 1.8V SER2_TX_3V_R 3.3V or 1.8V SER2_RX_3V_R...

  • Page 65: Uart Lane 3 (Uart3)

    2.4.45 UART Lane 3 (UART3) Pin Name Signal Type Signal Level VCC_3V3_L +3.3V SER3_TX_3V_R 3.3V or 1.8V SER3_RX_3V_R 3.3V or 1.8V Note: UART3 is optional. Chapter 2 – Hardware Information...

  • Page 66: Appendix A - Mating Connectors

    Appendix A Appendix A – Mating Connectors...

  • Page 67: List Of Mating Connectors And Cables

    Molex 470541000 CN15 Module Power Conn Molex 510210200 50247-012H0H0 CN17 HDA Wafer ACES 170X000156 -001 CN20 ATX CPU 4-Pin Molex 39012045 AAEON ECBU CN22 eSPI Connector SHR-10V-S-B 1703100133 Debug Card Only CN26 COM Port 0 Molex 51021-0900 1701090150 CN27 COM Port 2...
