NIIMBOT B1 Product Manual

Hide thumbs Also See for B1:

Advertisement

Quick Links

Download this manual
Product Manual
Label Printer
Smart
NIIMBOT B1

Advertisement

loading
Need help?

Need help?

Do you have a question about the B1 and is the answer not in the manual?

Questions and answers

Related Manuals for NIIMBOT B1

Summary of Contents for NIIMBOT B1

  • Page 1 Product Manual Label Printer Smart NIIMBOT B1...
  • Page 2 Package Contents Smart Label Printer *1 Label Paper Roll *1 USB Type-C Cable *1 Product Manual *1...
  • Page 3 Installation Button to open compartment Press the open button on the left-hand side of the printer to open the paper compartment. Printing surface The label paper should be inserted with the printing side face down in the paper compartment Cutting blade Roll holders Push the two paper tension plates outward and insert the label paper with the print side down.
  • Page 4 Paper outlet Slide the paper tension plates inward to secure the label paper, then pull the first label to make it protrude out from the paper outlet. Power button Indicator light Close the paper compartment, then press and hold the power button to turn on.
  • Page 5 NIIMBOT app, which downloading and using the NIIM app, features a wide range of industry- which features a variety of fun and...
  • Page 6 03-2 Download computer version Visit the software downloads page on NIIMBOT's official website (www.niimbot.com) to download and install the computer version of "NIIMBOT ". Note: To connect a computer to this device, please use the officially provided data cable or a data cable that supports...
  • Page 7 Android phones. 8:30 Turn on Bluetooth NIIMBOT Open the app and search for Bluetooth devices to connect to. Note: If it asks for a PIN, enter 0000 or 1234 then press OK. Once successfully connected, go to the Drawing Board.
  • Page 8 Basic operations Function Process Turn on Press and hold the power button for three seconds Press and hold the power button for three seconds Turn off while powered on Feed paper Press the power button once while powered on Print testing page Press the power button twice while powered on...
  • Page 9 Meaning of Indicator Lights Color Status Meaning Blue Flashing Upgrading firmware Blue Solid Standby Green Flashing Printing Green Solid Bluetooth connected Flashing Charging The paper compartment is not Solid closed;out of paper; or paper output error...
  • Page 10 Specifications Product Label Printer Model NIIMBOT B1 Dimensions 132*91*62mm Weight 293g Charging Time 3.5 - 4 hours Input 5V DC, 1A Battery Printing 1500mAh Thermal printing Capacity Method Printing Printing 203dpi 20-48mm Resolution Width Connectivity Bluetooth, Type-C Charge Type-C Operating...
  • Page 11 Safety Precautions Read all instructions and warnings in this guide carefully before using the product to ensure proper and safe use of the product and to avoid personal injury or damage to property. *Warning Do not disassemble the Do not use corrosive chemical Do not use the product in product yourself.
  • Page 12 Purchasing the product through other channels may mean you buy a pirated product or a product not adapted to your region or country of use which may lead to usage issues. In such cases, NIIMBOT may be unable to provide you with further assistance.
  • Page 13 Wuhan Jingchen Intelligent ldentificationTechnology Co., Ltd. Support Email : service@niimbot.com Official Website : www.niimbot.com Manufacturer's Address : No. 5, Creative Workshop, Creative World,Yezhihu West Road,Hongshan District,Wuhan, China © 2024 NIIMBOT. All Rights Reserved. NIIMBOT is a brand under Wuhan Jingchen Intelligent ldentification Technology Ltd.
