CS1922 / CS1924
2/4-Port USB 3.0 4K DisplayPort KVMP™ Switch
Quick Start Guide
© Copyright 2022 ATEN
ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd.
All rights reserved. All other trademarks are the property of their respective owners.
Part No. PAPE-1223-F81G
®
International Co. Ltd.
Released: 03/2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS1922 and is the answer not in the manual?

Questions and answers

Related Manuals for ATEN CS1922

Summary of Contents for ATEN CS1922

  • Page 1 Quick Start Guide © Copyright 2022 ATEN ® International Co. Ltd. ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. Part No. PAPE-1223-F81G Released: 03/2022...

  • Page 2: Package Contents

    Package Contents CS1922 1 2-Port USB 3.0 4K DisplayPort KVMP™ Switch 2 DisplayPort cables 2 USB 3.0 cables 4 audio cables 1 power adapter 1 user instructions CS1924 1 4-Port USB 3.0 4K DisplayPort KVMP™ Switch 4 DisplayPort cables 4 USB 3.0 cables...
  • Page 3 Hardware Overview CS1922 Front View CS1924 Front View CS1922 Rear View CS1924 Rear View...

  • Page 4: Operation

    Installation Operation CS1922 (Front) Audio Scroll Scroll Speakers Enter Lock Lock Monitor USB Keyboard USB Mouse At the other ends of the cables, plug the DisplayPort, USB 3.0, microphone, and speaker connectors into their respective ports on the computer. (Optional) Plug the USB peripherals into the Type-A ports in the USB 3.0 hub sections.
  • Page 5 Operation Scroll Scroll Enter Lock Lock...

  • Page 6: Hardware Overview

    CS1922 / CS1924 2/4-Port USB 3.0 4K DisplayPort KVMP™ Switch Hardware Overview Rear view Front view console ports port selection pushbuttons KVM ports port LEDs power jack audio jacks audio jacks USB 3.0 hub USB 3.0 hub Installation To set up the switch, refer to the diagram above and do the following: Plug the USB keyboard and mouse into the console ports on the rear panel.

  • Page 7: Mouse Switching

    At the other ends of the cables, plug the DisplayPort, USB 3.0, microphone, and speaker connectors into their respective ports on the computer. (Optional) Plug the USB peripherals into the Type-A ports in the USB 3.0 hub sections. Plug the power adapter (provided with this package) into the switch’s power jack and then plug the other end into a AC power source.

  • Page 8: Hotkey Switching

    KVM focus to the next port on the switch. (1 to 2, 2 to 1 for mage to your installation from power the CS1922; 1 to 2, 2 to 3, 3 to 4, 4 to 1 for the CS1924). [Enter]...
  • Page 9 To reduce the environmental impact of our products, ATEN documentation and software can be found online at http://www.aten.com/download/ Technical Support www.aten.com/support...
