TX-2
TWO-WAY RADIO
UHF HANDHELD FM TRANSCEIVER
USER'S MANUAL
Long Range
Robust &Durable
Li-ion Battery
Plug-in USB Charger
Loud Clear Audio
16 Channels
Thank you for purchasing the Zartek TX-2 Portable Two Way Radio.
This radio is easy to use and gives you reliable and clear
communication. The TX-2 UHF transceiver is approved by ICASA to
operate at 0.5W on license-free band 446MHz consisting of 8
frequencies.
Please read this manual carefully before using the radio. The
information presented here will ensure that you get maximum
performance and functionality from the radio. There are also
important battery and charging maintenance procedures.
High strength materials and quality components have been used in
the manufacture of this two-way radio to give many years of
product use. It is designed for general use both indoors and
outdoors and is durable and easy to operate.
Advertisement
Table of Contents
Related Manuals for Zartek TX-2
Summary of Contents for Zartek TX-2
- Page 1 Plug-in USB Charger Loud Clear Audio 16 Channels Thank you for purchasing the Zartek TX-2 Portable Two Way Radio. This radio is easy to use and gives you reliable and clear communication. The TX-2 UHF transceiver is approved by ICASA to operate at 0.5W on license-free band 446MHz consisting of 8...
-
Page 2: Warranty
If the product has been tampered with in any way, the warranty shall be considered null and void. For any queries, email info@zartek.co.za Safety Information • Study this manual carefully to understand your transceiver well. - Page 3 There is 1 band, PMR 446MHz band with 8 frequencies (1-8) and sub tones for privacy. Select the same channel on any TX-2 radio to communicate with each other. Compatibility:...
-
Page 4: Battery Information
TX-2 radio when there are other channels to be set. Both the frequency (1 - 8 ) and CTCSS sub tones (1 - 38), DCS tone must be the same on all radios for full intercommunication. Should there be interference on a specific channel, select a different channel. - Page 5 to charge fully may shorten the life span of the battery. Recharge the battery immediately once it goes flat as it could get damaged if left very flat for long periods. The maximum battery capacity and performance is achieved after three full charge-discharge cycles.
-
Page 6: Included Items
If any items are missing or have been damaged during shipment, contact the supplier immediately. For optional accessories, please visit our website www.zartek.co.za INCLUDES • 2 x Handheld UHF FM •... -
Page 7: Radio Overview
Radio Overview TX-2 VOL+ VOL-... -
Page 8: Getting Started
Getting Started Remove and Install the belt clip case To remove the belt clip, first detach the top arm and slide radio out of case. To install the case, ensure that the back plate has fully closed the battery compartment. Insert the bottom of radio into case and clip the top arm into groove to secure. -
Page 9: Basic Operation
Only recharge using standard USB supply adaptors with output of 5V and 1A. CHARGE TIME is approximately 4 hours from flat to full. OPERATING TIME is approximately 25 hours with a fully charged battery if used typically on a 5:5:90 duty cycle on 0.5W power with medium volume and battery save ON. - Page 10 Radio will “Beep” once when locking and “Beep” twice when unlocking. Communication Range Range will depend on the type of terrain that you are communicating across. The TX-2 uses the UHF (Ultra High Frequency) band and will be subject to similar obstacle interference as cellular phones.
- Page 11 The radio works indoors as well as outdoors. Typical rough estimate ranges for different terrains are: • Indoors or Shopping centre 300m-1200m • Building 5-30 stories, • City centre & dense bush 500m-2km, • Residential & over water 2-6km, • Farmland 3-7km, •...
-
Page 12: Programming (Optional)
Programming (optional) A two-pin programming cable (optional) is needed to program different channels or functions on the TX-2. The programming cable links the radio to USB port on a PC or laptop. USB installation: Plug in the cable to a USB port, the computer should locate the cable and configure it automatically if using window 10 / 11. - Page 13 Reading data: Click on the “READ” icon and press “OK” to begin reading the data from the radio. Once loaded, the data can be edited to the appropriate channels and settings and then saved or printed for future reference. See below for instructions on each function.
- Page 14 There are 38 CTCSS standard tones (1-38) plus 12 extra QT tones. The 38 tones are common on other 446 MHz radios such as the Zartek RX-8, COM8 or PT8, see table how to correspond Code number to Hz value. If the tone is left “OFF”, the frequency is left “open”...
- Page 15 CTCSS standardtones1-38 Code # (Hz) Code # (Hz) 67.0 131.8 71.9 136.5 74.4 141.3 77.0 146.2 79.7 151.4 82.5 156.7 85.4 162.2 88.5 167.9 91.5 173.8 94.8 179.9 97.4 186.2 100.0 192.8 103.5 203.5 107.2 210.7 110.9 218.1 114.8 225.7 118.8 233.6 123.0...
- Page 16 Battery Save Function The Battery Save function decreases the amount of power used when a signal is not being received and no operations are being performed (no keys are being pressed, and no switches are being turned) thereby increasing standby time. While the channel is not busy and no operation is performed for 10 seconds, Battery Save turns ON.
- Page 17 VOX (Voice-operated Transmission) The TX-2 has a multi-level sensitivity built-in VOX function. You can enjoy talking and listening without pressing PTT key as transmit is automatically activated by sound. This turns your radio into hands-free “walk & talk” when used with a headset.
- Page 18 Scan: A scan function is useful when you want to find other people on similar frequencies or to monitor communication within your group. If an active channel is found the scan will stop and lock on to that channel. You can now transmit and receive on this frequency.
-
Page 19: Optional Accessories
Optional Accessories HEADSETS (use with PTT or VOX) GE-252 Earphone speaker with in-line PTT microphone GE-259 Lapel speaker microphone for vehicle & security use Acoustic eartube speaker with microphone for GE-266 discrete communication GE-272 Single Muff Earpiece Boom microphone with PTT Heavy Duty D-Cup high volume speaker with mic. -
Page 20: Troubleshooting
Troubleshooting Problem Solution • The battery pack may be dead. No power. Recharge or replace the battery pack • The battery pack may not be installed correctly. Remove the battery pack and install it again. Battery power • The battery pack life is finished. Replace dies shortly after the battery pack with a new one. -
Page 21: Specification
Specification Specifications may be revised without notice due to technical improvements. GENERAL Frequency Range 446MHz Channel Capacity Frequency Spacing 12.5kHz Working Voltage 3.7V Antenna Integrated Operating Temperature Range -10℃~ +50℃ Dimension incl Antenna 128mm×59mm×21mm (L×W×H), without case Weight (including Antenna 110g and Battery) Battery Capacity... - Page 22 说明书要求 尺寸：74x100mm 印刷： 1、黑白印刷 3、内页黑白印刷 装钉：胶合钉 纸张材质： 1、普通印刷纸 本页无需印刷...
