User's Manual
INTRODUCTION
Congratulations! You have just purchased a new remarkable
product in communications. The
and lightest two-way radios in the world. This is due to the use of Li-ION battery
technology and micro-circuitry. With the
as large a group as required and as often as you like without airtime charges, giving
you, family, friends, commercial and industrial colleagues many years of free quality
communications. The
advanced and ecologically friendly rechargeable battery available (most advanced
mobile phones also use a Li-ION battery).
New legislation allows you now to own and use this relatively powerful
equipment without an operator's annual license from ICASA. This applies in most
European countries (using the
Development Community) countries (using the
To obtain maximum performance from your personal two-way radio, please
take a few minutes to carefully read this user's manual. The
lightweight, palm-sized wonder communication device, so small you can carry
anywhere and talk to any person who is set on the same channel, as long as they are
within range. The range of the
20kms outdoors, depending on terrain and environment. The signal will bounce
around and penetrate materials at the speed of light, bearing in mind the greater the
barriers the more attenuation i.e. weakening of the signal.
Zartek Pro
The
frequency versions,
frequencies often called the PMR (Public Mobile Radio) band. It is pre-programmed
with 8 frequencies and is therefore channel compatible to the original
The
Pro-5
is programmed with 5 frequencies in the 463MHz band. It is therefore
channel compatible to the original
referred as the ZA-200. The
operated in different frequency bands.
(WT-206 PRO SERIES)
Zartek Pro
Zartek Pro
Pro-8
Zartek Pro
is our exciting new generation series and comes in two
Pro-5
and
Pro-8
Zartek
Pro-5
is one of the smallest
Zartek Pro
uses a Lithium Ion battery (Li-ION), the most
) as well as in all SADC (Southern African
Pro-8
is anything from 1km indoors to
. The
Pro-8
model no. 21-1860-AF sometime also
is not compatible to the
you can talk instantly to
or
Pro-5
)
Zartek Pro
sits in the 446MHz band of
Zartek
Pro-8
as they
is a
Eco.
Advertisement
Chapters
Table of Contents
Related Manuals for Zartek Zartek Pro 5
Summary of Contents for Zartek Zartek Pro 5
- Page 1 User’s Manual (WT-206 PRO SERIES) INTRODUCTION Congratulations! You have just purchased a new remarkable Zartek Pro product in communications. The is one of the smallest and lightest two-way radios in the world. This is due to the use of Li-ION battery Zartek Pro technology and micro-circuitry.
- Page 2 MAIN FEATURES • PLL (Phase Lock Loop) Controlled Circuitry • Ultra Slim size (19mm) • Ultra light weight (67g with battery) • Li-ion rechargeable battery • 5 or 8 UHF (Ultra High Frequencies) Frequencies • 38 Quiet (CTCSS-Continuous Tone Coded Sub-audible Squelch) Codes •...
- Page 3 Follow "This Side Face Up" and +/- polarity to install the Li-ION battery pack into the compartment Slide the battery door on to close. WAR I G • Make sure the polarity of battery is correct. • When the battery is damaged or not working, dispose of it safely. Never discard them or put them close to heat, otherwise, it may explode.
- Page 4 WAR I G: • Only use vehicle cigarette lighter adaptor with standard 13.6vDC socket. • The unit will warm up slightly during charging. With Desk Top Charger • Plug the AC/DC adaptor into wall and other end plug into the desk-top charger. •...
- Page 5 GENERAL OPERATION Power On/Off the unit Making communication Speak to other radios Listen to other radios Adjusting speaker volume Talk Time-Out Function Talk Range Menu Flow chart Select channel CTCSS code function FM Radio Sending Call Tones Select Call Tones Scramble Function VOX “Hands-Free Walk &...
-
Page 6: Making Communication
(7) TALK RANGE The range will depend on the type of terrain that you are communicating across. Zartek Pro uses the UHF (Ultra High Frequency) band and will be subject to similar obstacle interference as cellular phones. The radio works indoors as well as outdoors. -
Page 7: Menu Flow Chart
• Building 5-30 stories, • City centre & dense bush 500m-2km, • Residential & over water 2-4km, • Farmland 3-5km, • Top of mountain or building (line-of-sight) 10-30km. When you press the PTT talk button a signal is transmitted and the signal floods the area in all sideway directions. -
Page 8: Ctcss Code Function
(10) CTCSS CODE FUNCTION This function can help you select your group (38 CTCSS codes) of users on the shared frequency. Only the users with the same CTCSS code can listen and talk to each other. To select a CTCSS code •... -
Page 9: Scramble Function
(15) VOX “HANDS FREE WALK & TALK” Zartek Pro has innovative state-of-the-art technology not seen in other two- way radios with its multi-level sensitivity built-in VOX function. You can enjoy talking and listening without pressing PTT key as transmit is automatically activated by sound. -
Page 10: Stop Watch
• Press the " " key to stop and show the lap time while the watch is running. • Press the" " key again to switch back to stopwatch mode and show the running time. • Press the " " or " " key to stop and press " " key to reset. •... -
Page 11: Keypad Lock
ote: Pressing the button for over 2 seconds, will break the squelch noise and open (un-squelch) the frequency. • The radio scans all the frequencies one by one and will lock on any activity. After locking-on to a conversation, press the " " or " " key to continue scanning or press the PTT key to store the channel and communicate back. -
Page 12: Specifications
GE-246 ………PTT (and VOX) Earphone with in-line microphone (29) WARRANTY This product is warranted by Zartek against manufacturing defects in materials and workmanship under normal use for a 12 month period from date of purchase via our authorized appointed dealers.
