Zartek PERSONAL TWO-WAY RADIO User Manual

Personal two-way radio
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
(1) INTRODUCTION
Congratulations! You have just purchased a new remarkable breakthrough
product in communications to be used on the Public Radio Service (PRS)
frequency band. The
large a group as required, as often as you like without airtime charges and will give
you, family, friends, commercial and industrial colleagues many years of quality
communications. New legislation now allows you to own and use this relatively
powerful equipment without an operator's annual license from ICASA (formally
SATRA). This applies to all SADC(Southern African Development Community)
region countries as well. National standby communication channel is 0
should be used to make contact with outsiders and springboard to other channels.
To obtain maximum performance from your personal two-way radio, please
take a few minutes to read this users manual carefully. The
lightweight, palm-sized wonder with 190 two-way radio channels that you can carry
almost anywhere and use to talk to any person who is set on the same channel as
long as they are within range. ote! Generally the higher you are, the further the
line-of-sight communication distance.
The range of the
dependant on terrain and environment. The signal will bounce around and penetrate
materials at the speed of light, bearing in mind the greater the barriers the more
attenuation i.e. weakening of the signal.
The
Zartek
Portocom
, now with many more features and higher specifications, but
channel related communication still maintaining 100% compatibility.
(2) MAIN FEATURES
• PLL(Phase Lock Loop) Controlled Circuitry
• 2 Memory Channels
• 5 UHF (Ultra High Frequencies) Frequencies
• 38 Quiet (CTCSS- Continuous Tone Coded Sub-audible Squelch) Codes
• Rotary Volume Control with Power On/Off
• Scanning Frequency/CTCSS
• VOX (Voice Operated Transmit) Function – Hi/Low
• Call Function – Ringer Type
• Auto Squelch Control
• Back lighted LCD (Liquid Crystal Display) Display
• Keypad Lock
• Auto Power Off (enable/disable)
• Memory Retention Function
• Power Saving Circuitry
Zartek
two-way radio enables you to talk instantly to as
Zartek
is anything from 1km indoors to 20kms outdoors,
is our exciting second-generation product, super-ceding the
1
01. This
Zartek
is a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PERSONAL TWO-WAY RADIO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zartek PERSONAL TWO-WAY RADIO

Summary of Contents for Zartek PERSONAL TWO-WAY RADIO

  • Page 1 National standby communication channel is 0 01. This should be used to make contact with outsiders and springboard to other channels. To obtain maximum performance from your personal two-way radio, please take a few minutes to read this users manual carefully. The Zartek...
  • Page 2 • NI-Cd/Alkaline Charge Switch (inside battery compartment) • External Mic/Headset • Battery Charging • Fixed Rubber Duck Antenna • Water Resistant - JIS Level 4(i.e. splash proof) • Power Source: 6V DC (4 x AA cells) (3) DISPLAY 1. Displays when function is enabled 2.

  • Page 3: Installing Batteries

    (4) INSTALLING BATTERIES Your radio uses standard universal “AA” size batteries. This means, unlike cell- phones & other two-way radio products, you are flexible to utilize any batteries of the “AA” size, non-rechargeable or rechargeable and at any of the available capacities (mA hours).
  • Page 4 KEY LOCK/PTT-To transmit, hold Zartek down continuously with transmit icon displayed, then speak into the microphone. Release when you have PERSONAL TWO-WAY RADIO finish talking to receive response. OFF/VOL –Rotate Q-SCA /QUIET- Hold down to turn your radio on to set the quiet code. Press to...

  • Page 5: Selecting A Frequency

    having 38 QUIET (CTCSS) CODES. The CTCSS code is used to control the receiver squelch. It filters out all unwanted messages, interference and noise. They also let you talk and listen to other radios set to the same frequency and quiet code. This is like having a sub-channel in a frequency, giving you greater communication flexibility.

  • Page 6: Using Auto Power - Off

    2. Hold down FU C/MO and press M1/DW1 or M2/DW2 simultaneously to recall memory channel. DUAL appears and the two channel appear alternately. The radio checks the two channels and locks on to the active one until the signal disappears, then reverting back checking for activity. 3.

  • Page 7: Scanning Frequency

    Scanning resumes after the signal disappears. Press any keypad to stop scanning. (20) VOICE OPERATED TRANSMIT (VOX) ZARTEK has innovative state-of-the-art technology not seen in other two- way radios with its dual level built-in VOX function. Operation can be with OR without an external headset/mic.

  • Page 8: Specifications

    (22) WARNING Do not operate radio in hazard environments. Explosion or fire may result. Do not operate radio near unshielded electrical blasting caps. Under certain conditions, radio can interfere with blasting operations and may cause an explosion. Turn your radio OFF to prevent accidental transmission when in a “blasting area” or in areas posted “Turn your radio off”.

  • Page 9: Warranty

    GE-234 ………Carry case, webbing, with adjustable shoulder strap GE-235……….Battery pack, super 1800mA NiMH(Nickel Metal Hydride) (25) WARRANTY This product is warranted by Zartek against manufacturing defects in materials and workmanship under normal use for a 12 month period from date of purchase via our authorized appointed dealers.
  • Page 10 Zartek Zartek Zartek Zartek PERSONAL TWO-WAY RADIO AUTHORISED DEALER DATE PURCHASED SERIAL UMBER...
