DWT_WT- 202_PMR_User's Manual V.3
30 Mar., 2004
462/ 467MHz GMRS & FRS 2-Way Radio
Model: WT-202
FEATURES
1. 22 Channel – GMRS & FRS version
2. 38 CTCSS code
3. VOX ( 3 Levels of Sensitivity)
4. 10 Group Call Tone Selection
6. Scan
1. Transmit LED indicator
2. Microphone
3. Earphone and Wall Charger jack
4. Call Key
5. Scan / Monitor Key
6. Menu / Lock Key
7. PTT (Push To Talk) Key
8. Up Key
9. Down Key
10. Power On/Off Key
11. Speaker
12. Desktop Charger Pins (Desktop Charger is option accessory)
13. Detachable Belt Clip Hold (Belt Clip is option accessory)
14. Battery Cover
1 / 6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Zartek WT-202
Summary of Contents for Zartek WT-202
- Page 1 DWT_WT- 202_PMR_User’s Manual V.3 30 Mar., 2004 462/ 467MHz GMRS & FRS 2-Way Radio Model: WT-202 FEATURES 1. 22 Channel – GMRS & FRS version 2. 38 CTCSS code 3. VOX ( 3 Levels of Sensitivity) 4. 10 Group Call Tone Selection 5.
- Page 2 DWT_WT- 202_PMR_User’s Manual V.3 30 Mar., 2004 Battery Installation 1. Press the battery door knob to take off the battery door. 2. Follow “This side up” and +/- direction to install the Li-ION battery pack into the compartment. 3. Replace the battery door. Warning: A.
- Page 3 DWT_WT- 202_PMR_User’s Manual V.3 30 Mar., 2004 Menu Flow chart Menu Main channel CTCSS Call tone VOX sensitivity VOX overtime Note: Press PTT Key to confirm and escape. MAKING COMMUNICATIONS The Radio has 22 main channels & 38 CTCSS code. You can communicate with any other user who is using the same main channel.
- Page 4 DWT_WT- 202_PMR_User’s Manual V.3 30 Mar., 2004 CTCSS code function This function can help you to identify your group of users among the same channel. Only the users with the same CTCSS tone can listen and talk to each other, but all the users on the same channel can listen to the conversation.
- Page 5 DWT_WT- 202_PMR_User’s Manual V.3 30 Mar., 2004 3. Press the “PTT” Key to confirm, the call tone number display will stand. VOX - HANDS-FREE FUNCTION The Radio has a built-in Voice Activated Circuit (VOX) function. You can connect the radio with the earphone for hands-free talking and listening without pressing PTT Key.
- Page 6 DWT_WT- 202_PMR_User’s Manual V.3 30 Mar., 2004 GMRS LICENSE USE OF THIS RADIO WITHIN THE UNITED STATES REQUIRES AN FCC GMRS LICENSE. AN INDIVIDUAL 18 YEARS OF AGE OR OLDER, WHO IS NOT A REPRESENTATIVE OF A FOREIGN GOVERNMENT, IS ELIGIBLE TO APPLY FOR A GMRS SYSTEM LICENSE.
