User's Manual
INTRODUCTION
Congratulations! You have just purchased a remarkable product
in communications. The Zartek Pro is one of the smallest and
lightest two-way radios in the world. This is due to the use of Li-ION battery
technology and micro-circuitry. With the Zartek Pro you can talk instantly to as
large a group as required and as often as you like without airtime charges, giving
you, family, friends, commercial and industrial colleagues many years of free quality
communications. The Zartek Pro uses a Lithium Ion battery (Li-ION), the most
advanced and ecologically friendly rechargeable battery available (most advanced
mobile phones also use a Li-ION battery).
Legislation allows you now to own and use this relatively powerful equipment
without an operator's annual license from ICASA. This applies in most European
countries (using the Pro-8 ) as well as in all SADC (Southern African Development
Community) countries (using the Pro-8 or Pro-5 )
To obtain maximum performance from your personal two-way radio, please
take a few minutes to carefully read this user's manual. The Zartek Pro is a
lightweight, palm-sized wonder communication device, so small you can carry
anywhere and talk to any person who is set on the same channel, as long as they are
within range. The range of the Zartek Pro is anything from 1km indoors to 20kms
outdoors, depending on terrain and environment. The signal will bounce around and
penetrate materials at the speed of light, bearing in mind the greater the barriers the
more attenuation i.e. weakening of the signal.
The Zartek Pro comes in two frequency versions, Pro-5 and Pro-8. The
Pro-8 sits in the 446MHz band of frequencies often called the PMR (Public Mobile
Radio) band. The Pro-8 is pre-programmed with 8 frequencies and is therefore
channel compatible to the Zartek COM8, ZA-708, ZA-705 and other radios also
using this band. The Pro-5 is programmed with 5 frequencies and is therefore
channel compatible to the Zartek ZA-705. The Pro-5 is thus not compatible to the
Pro-8 as they operated in different frequency bands.
MAIN FEATURES
(WT-206 PRO SERIES)
Advertisement
Related Manuals for Zartek Pro5l Pro8
Summary of Contents for Zartek Pro5l Pro8
- Page 1 User’s Manual (WT-206 PRO SERIES) INTRODUCTION Congratulations! You have just purchased a remarkable product in communications. The Zartek Pro is one of the smallest and lightest two-way radios in the world. This is due to the use of Li-ION battery technology and micro-circuitry.
- Page 2 PLL (Phase Lock Loop) Controlled Circuitry Ultra Slim size (19mm) Ultra light weight (67g with battery) Li-ion rechargeable battery 5 or 8 UHF (Ultra High Frequencies) Frequencies 38 Quiet (CTCSS-Continuous Tone Coded Sub-audible Squelch) Codes ...
- Page 3 Slide the battery door on to close. WARNING Make sure the polarity of battery is correct. When the battery is damaged or not working, dispose of it safely. Never discard them or put them close to heat, otherwise, it may explode. This radio is designed to use a 3.7v Li-ION rechargeable battery.
- Page 4 Unlike the direct adaptor, the radio remains ON and does not turn automatically OFF. Messages can be received but not transmitted if the radio is sitting in the charger. To transmit, the radio will have to be removed out of the charger. ...
-
Page 5: Table Of Contents
GENERAL OPERATION Power On/Off the unit Making communication Speak to other radios Listen to other radios Adjusting speaker volume Talk Time-Out Function Talk Range Menu Flow chart Select channel CTCSS code function Sending Call Tones Select Call Tones VOX “Hands-Free Walk & Talk” Stop Watch Lap Time Baby Monitor... -
Page 6: Listen To Other Radios
The radio has 5 or 8 main frequencies (large numbers) & 38 CTCSS codes (small numbers) effectively giving you 190 or 304 channels respectively. You can communicate with any other user who is using the same combination, providing they are within range. (3) SPEAK TO ANOTHER RADIO ... -
Page 7: Menu Flow Chart
Residential & over water 2-4km, Farmland 3-5km, Top of mountain or building (line-of-sight) 10-30km. When you press the PTT talk button a signal is transmitted and the signal floods the area in all sideway directions. The signal travels in 3 different ways: 1) Penetration: The signal can go through materials such as wood, plastic, cement and fabric. - Page 8 This function can help you select your group (38 CTCSS codes) of users on the shared frequency. Only the users with the same CTCSS code can listen and talk to each other. Using this function will improve the privacy of your communication. To select a CTCSS code ...
-
Page 9: Lap Time
Press " " key 5 times to enter the stopwatch mode. Press " " or " " key to start the watch. Press " " or " " key to stop the watch. Press " " key to reset. (15) LAP TIME ... -
Page 10: Keypad Lock
Press PTT button to confirm and return to the main screen or press the" " key once to confirm the selection. After turning on this function the LCD will display the " " icon and automatically turn off at designated time. (19) SCANNING CHANELLS ... -
Page 11: Warning
(23) WARNING Do not operate the radio in hazardous environments, explosion or fire may result. Do not operate the radio near unshielded electrical blasting caps. Under certain conditions, radio can interfere with blasting operations and may cause an explosion. Turn your radio OFF to prevent accidental transmission when in a “blasting area” or in areas posted “Turn your radio off”. - Page 12 This product is warranted by Zartek against manufacturing defects in materials and workmanship under normal use for a 12 month period from date of purchase via our authorized appointed dealers. Manufactured for Zartek of South Africa to meet ICASA technical requirements. For further information contact us via email: info@zartek.co.za or visit our website http://www.zartek.co.za/ AUTHORISED DEALER...
