Summary of Contents for AirLive WL-5470AP
- Page 1 WL-5470AP Wireless Access Point User’s Manual WL5470AP User’s Manual...
- Page 2 OvisLink Corp. 5F., NO.6, Lane 130, Min-Chuan Rd., Hsin-Tien City, Taipei County, Taiwan Declare that the product Wireless AP WL-5470AP is in conformity with In accordance with 89/336 EEC-EMC Directive and 1999/5 EC-R & TTE Directive Clause Description Electromagnetic compatibility and Radio spectrum Matters (ERM);...
- Page 3 [Portuguese] disposições da Directiva 1999/5/CE. aplicables o exigibles de la Directiva 1999/5/CE. ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ OvisLink Corp. ΔΗΛΩΝΕΙ OvisLink Corp izjavlja, da je ta WL-5470AP v skladu Ελληνική [Greek] ΟΤΙ WL-5470AP ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ Slovensko z bistvenimi zahtevami in ostalimi relevantnimi ΟΥΣΙΩΔΕΙΣ...
- Page 4 This device uses software which is partly or completely licensed under the terms of the GNU General Public License. The author of the software does not provide any warranty. This does not affect the warranty for the product itself. To get source codes please contact: OvisLink Corp., 5F, No. 96, Min-Chuan Rd, Hsin-Tien City, Taipei, Taiwan, R.O.C. A fee will be charged for production and shipment for each copy of the source code.
-
Page 5: Fcc Certifications
FCC Certifications This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 6: Ce Mark Warning
CE Statement Hereby, OvisLink Corp. declares that this device is in compliance with the essential requirement and other relevant provisions of the R&TTE Directive 1999/5/EC. CE Mark Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. -
Page 7: Table Of Contents
Table of Contents ................................1 NTRODUCTION ..................................2 EATURES ............................. 3 ARTS AMES UNCTIONS ............................5 ACTORY EFAULT ETTINGS WL-5470AP ................................5 ............................... 6 ARDWARE ONNECTION ........................7 BOUT THE IRELESS PERATION ODES ..............................8 CCESS OINT ) ..........................9... -
Page 8: Introduction
Introduction ． WL-5470AP is world's most popular multi-function access point. It features an impressive total of 8 wireless multi-function modes that are not available in normal access point. In addition, the ACK timeout and RSSI feature makes it suitable for long distance application. From ordinary AP application to Hotspot and WISP usage, you will find the WL-5470AP is the device you want. -
Page 9: Features
Features 4x100Mbps LAN ports for Wireless AP cascade.,2MB flash,16MB SDRAM. TX output power is limited to 20dBm (EU), 23dBm (FCC), up to 25dBm (South America). AP , Client, Bridge ,WDS, Universal mode. WISP Client Router, WISP+ Universal, Gateway mode. Allows WEP 64/128 bit. Support WPA-PSK, WPA2-PSK encryption. -
Page 10: Parts, Names, And Functions
Parts, Names, and Functions 1. Front Panel: LED Indicators Function Color Status Description Power Power is being applied to this product. Green Power indication The WAN port is link. WAN port Green Blinking activity Solid The wireless function is ON. Wireless Wireless Green... - Page 11 2. Rear Panel: Connection Ports Port Functions DC 12V Connects the power adapter plug. LAN 1 LAN 2 Connects inside network group. LAN 3 LAN 4 Connects inside network group or outside internet. Ant. Connects antenna. Table 2: Connection Ports WL5470AP User’s Manual...
-
Page 12: Factory Default Settings
Factory Default Settings Setting Wireless Access Point Device Name WL-5470AP SSID Default value: airlive Channel Default value: 11 in the USA/Canada market; Default value: 13 in the Europe market Default value: Disabled IP Address Default value: 192.168.100. 252 In AP, Client, and GW mode, the default DHCP Server is... -
Page 13: Hardware Connection
Hardware Connection Note: Before you starting hardware connection, you are advised to find an appropriate location to place the Access Point. Usually, the best place for the Access Point is at the center of your wireless network, with line of straight to all your wireless stations. Also, remember to adjust the antenna; usually the higher the antenna is placed the better will be the performance. -
Page 14: About The Wireless Operation Modes
About the Wireless Operation Modes The WL-5470AP v2 device provides all 7 modes of wireless operational applications with: 1 Access Point Mode. 2 Client Mode. 3 Bridge Mode. 4 WDS Mode. 5 Universal Mode. 6 WISP (Client Router) Mode. 7 WISP + Universal Mode. - Page 15 Access Point Mode When acting as an access point (default setting), this device connects all the stations (PC/notebook with wireless network adapter) to a wired network. All stations can have the Internet access if only the Access Point has the Internet connection. See the sample application below. To set the operation mode to “Access Point”, please go to “Mode AP”...
-
Page 16: Other
Client Mode (Infrastructure) If set to Client (Infrastructure) mode, this device can work like a wireless station when it’s connected to a computer so that the computer can send packets from wired end to wireless interface. Refer to the illustration below. This station (AP1 plus the connected computer 1) can associate to another Access Point (AP2), and then can have the Internet access if the other Access Point (AP2) has the Internet connection.
