Tokina atx-i 17-35mm F4 FF Manual

ENGLISH
Part names
❼
❽
❾
❿
❶ Hood Attachment Index
❷ Manual Focusing Ring
❸ Focus Distance Scale
❹ Focus Distance Index
❺ Zoom Ring
How to attach and remove lens
Please follow the camera instruction manual for attaching and removing
the lens.
※Take care to not touch or hit electrical contacts on the mounting face
of the lens while attaching or removing.
Focusing
When the manual focus ring is set to the AF position, the camera focuses
automatically. (Some Nikon cameras have a mode switch. With those
cameras, confirm that the setting is AF. See the camera's user manual for
details.)
When set to manual focus mode, rotate the manual focus ring while
looking through the viewfinder or at the monitor to adjust the focus.
This lens also has a focus aid function to assist with focusing.
Exposure Modes
For the exposure mode settings, follow the applicable instructions
provided in your cameras manual.
One-Touch Controllable Focus-Clutch Mechanism
<How to switch from the Auto focus position to manual
focus position>
The lens focus mode can be switched
between the Auto focus (AF) and
manual focus (MF) Positions at any
time by moving the manual focus ring
forward and backward.
Auto Focus Position
Notes on use of built-in flash
Photography using the camera built-in flash or a compact flash may
cause a portion of the flash light being blocked, which could result in lens
shadow appearing on both sides of the photo. If this occurs, use an
external flash.
17-35mm
❻ Center Index
❼ Auto Focus (AF) Position
❽ Manual Focus (MF) Position
❾ Focal Length Scale
❿ Mount attachment mark
Manual Focus Position
F4 FF
❶
❷
❸
❹
❺
❻
