Tokina VARIFOCAL LENS TVR1016DC Specification

VARIFOCAL LENS
TVR1016DC
SPECIFICATION
MODEL NUMBER
IMAGE FORMAT
FOCAL LENGTH
MAXIMUM APERTURE
APERTURE RATIO
ANGLE
OF VIEW
( )=1/3"
DIMENSIONS
OPERATING TEMPERATURE RANGE
OPERATING HUMIDITY RANGE
CABLE COLOR
WHITE
GREEN
BLACK
RED
4 PIN CONNECTOR
E4 191J 100: 1PCS to lens
f = 10-120mm F 1.6 DC IRIS
M.O.D.
DIAGONAL
HORIZONTAL
VERTICAL
WEIGHT
MOUNT
CONNECTION
DRIVING COIL+
DRIVING COIL
DAMPING COIL+
DAMPING COIL
TOKINA Co.,Ltd.
Security Products Division
120-4 NOZUTA-MACHI,MACHIDA-SHI,
TOKYO, 195-0063 JAPAN
TEL:+81-42-734-8912 FAX:+81-42-735-1463
E-mail:cctv@tokina.co.jp
10 120mm
F1:1.6 2.2
F1:1.6 360
W43.96°(32.73)
W34.95°(26.20)
W26.20°(19.66)
W64.0×H122.5×D55.0mm
10
30
TVR1016DC
1/2inch
0.3m
T3.98°(3.00)
T3.20°(2.40)
T2.40°(1.81)
300g
45
70
C
